TRANSFER CASE SKID

FOR GM LIGHT DUTY TRUCKS

PLEASE READ ENTIRELY BEFORE YOU START

To guarantee a quality installation, we recommend reading these instructions thoroughly

before beginning any work. These instructions assume a certain amount of mechanical

ability and are not written nor intended for someone not familiar with auto repair.

NOTE: If your vehicle does not contain the holes in the

frame, the supplied riv-nuts must be utilized. Hold the

skid plate into position and mark where the holes must

go on the frame. Drill a 17/32" hole were marked and

insert the correct size riv-nut. You may now proceed

with the installation of your skid plate.

AEV30471AA

Last Updated: 10/10/23

Need help?

Do you have a question about the 56060002AA and is the answer not in the manual?

Page 1 TRANSFER CASE SKID FOR GM LIGHT DUTY TRUCKS PLEASE READ ENTIRELY BEFORE YOU START To guarantee a quality installation, we recommend reading these instructions thoroughly before beginning any work. These instructions assume a certain amount of mechanical ability and are not written nor intended for someone not familiar with auto repair. NOTE: If your vehicle does not contain the holes in the frame, the supplied riv-nuts must be utilized.
Page 4 A M E R I C A N E X P E D I T I O N V E H I C L E S 1. Install four M8 U-Nuts onto the transfer case skid (fig. 1). Figure 1 2.
Page 5 A M E R I C A N E X P E D I T I O N V E H I C L E S Install nine M10 U-nuts into the frame locations shown (fig. 3). Figure 3 Use the supplied M10 bolts to install the skid plate onto the frame (fig. 4). Tighten to 40 ft-lbs Figure 4...
