AEV PROCAL SNAP User Manual

Hide thumbs Also See for PROCAL SNAP:

Advertisement

Table of Contents

USER GUIDE
AEV30348AE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PROCAL SNAP and is the answer not in the manual?

Questions and answers

Related Manuals for AEV PROCAL SNAP

Summary of Contents for AEV PROCAL SNAP

  • Page 1 USER GUIDE AEV30348AE...
  • Page 2 1. INSTRUMENT CLUSTER DISPLAY CONTROL BUTTONS 2. INSTRUMENT CLUSTER DISPLAY 3. CRUISE CONTROL BUTTONS 4. STEREO DISPLAY 5. OBDII PORT 6. ENGINE START/STOP BUTTON NOTE: This illustration may not exactly represent your vehicle. Access to each of these components is required to use this product.
  • Page 3 Cruise Control Layout 4-BUTTON 5-BUTTON SET + CANC SET - NOTE: Your vehicle will be equipped with one of two cruise control button layouts. Refer to the specific style of switches in your vehicle for all functions of this product.
  • Page 4 OVERVIEW The AEV ProCal SNAP is an easy-to-use electronic recalibra- tion module designed for Jeep JL Wrangler, Gladiator, and RAM Trucks. It allows recalibration of your vehicle parame- ters such as tire size, axle gear ratios, and additional configu- rable paramaters. After connecting the device to the OBDII diagnostic port, input numerical values using the stereo’s...
  • Page 5 Press 2 times to put into the Insert ProCal SNAP into the “RUN” position. OBDII port. NOTE: The ProCal SNAP must be paired to a vehicle before it will recalibrate any settings. Once completed, the ProCal SNAP will be permanently locked to this vehicle.
  • Page 6 BRAKE light on the CRUISE ON/OFF button until speedometer. the vehicle honks. HONK! HONK! HONK! When the pairing process is complete, the horn will sound quickly 3 times. Your ProCal SNAP is now paired and ready to recalibrate your vehicle.

  • Page 7: Setting Equalizer

    SETTING EQUALIZER Adjust the stereo’s AUDIO SETTINGS to the values you wish to set (be sure the stereo source is set to AM/FM). Always enter the values in order: Bass, Mid, Treb. regardless of their order or orientation on the equalizer. •...
  • Page 8 EXAMPLE: TIRE SIZE To recalibrate Tire Size: Begin by physically measuring your tire diameter IN INCHES ACTUAL MEASURMENT TO THE NEAREST 10th IN. from the ground to the top of front tire with the vehicle level and on the ground. –...
  • Page 9 Insert ProCal SNAP into light on the SNAP. the OBDII port. PRESS and HOLD the combination below for 3 SECONDS. Programming is complete when the horn sounds twice. Shut o vehicle. Unplug ProCal SNAP and store in vehicle. SET + CANC BRAKE PEDAL...

  • Page 10: Programming Steps

    PROGRAMMING STEPS – – – Press RUN Twice Adjust EQ levels Insert ProCal SNAP SET + CANC BRAKE PEDAL SET- Turn Vehicle OFF Remove ProCal SNAP Press Brake Pedal and Designated Button NOTE: Repeat this process for EACH programming change.
  • Page 11 AXLE RATIO Example: 4.10:1 Axle Bass:4 Mid: 1 Treb: 0 The physical ratio of gears in your SET + di erential. Do not modify unless you have changed gears. Note for 4xe CANC owners: Do not program gear ratios over 4.50:1 even if your physical ratio is larger.

  • Page 12: Additional Functions

    ADDITIONAL FUNCTIONS SET + CANC BRAKE PEDAL SET- Press RUN Twice Insert ProCal SNAP Press Brake Pedal, Pull High Beam, Designated Button CLEAR DTC CODES SET + To clear DTC Codes, follow steps above then additionally press and hold the RESUME (RES) on the cruise CANC control switches.

  • Page 13: View Settings

    Instrument Cluster Display Control Buttons to navigate to AUDIO. The display will cycle through showing the current values for Tire Diameter, Axle Ratio, Tire Pressure Threshold (Front and Rear), 4Low Ratio, and the ProCal SNAP part number. ERRATA AND NOTES The ProCal SNAP may not honk when clearing codes if •...

  • Page 14: Diagnostic Codes

    DIAGNOSTIC CODES BLINKING GREEN: ProCal SNAP ready to pair SOLID GREEN: ProCal SNAP paired and ready SLOW PULSING ORANGE: Waiting for vehicle ignition to be turned to RUN. SLOW PULSING BLUE: Inserted into incorrect vehicle. FAST PULSING ORANGE: No connection. Check that the harness is properly installed.

  • Page 15: Troubleshooting

    AEV Support with the information shown. Q: What if I don’t have a factory stereo? A: It may be possible for aftermarket head units to work with the ProCal SNAP, but it is highly unlikely. AEV Customer Support: (248) 926-0256 tech@aev-conversions.com...
  • Page 16 A E V - C O N V E R S I O N S . C O M ©2022 American Expedition Vehicles...
