AEV 56060001AA Installation Manual

Ifs skid plate

Download this manual

IFS SKID PLATE

FOR GM LIGHT DUTY TRUCKS

PLEASE READ ENTIRELY BEFORE YOU START

To guarantee a quality installation, we recommend reading these instructions thoroughly

before beginning any work. These instructions assume a certain amount of mechanical

ability and are not written nor intended for someone not familiar with auto repair.

NOTE: If your vehicle does not contain the holes in the

frame, the supplied riv-nuts must be utilized. Hold the

skid plate into position and mark where the holes must

go on the frame. Drill a 17/32" hole were marked and

insert the correct size riv-nut. You may now proceed

with the installation of your skid plate.

AEV30470AA

Last Updated: 10/10/23

Need help?

Do you have a question about the 56060001AA and is the answer not in the manual?

Page 1 IFS SKID PLATE FOR GM LIGHT DUTY TRUCKS PLEASE READ ENTIRELY BEFORE YOU START To guarantee a quality installation, we recommend reading these instructions thoroughly before beginning any work. These instructions assume a certain amount of mechanical ability and are not written nor intended for someone not familiar with auto repair. NOTE: If your vehicle does not contain the holes in the frame, the supplied riv-nuts must be utilized.
Page 4 A M E R I C A N E X P E D I T I O N V E H I C L E S Install the supplied U-nuts into the frame holes shown (fig. 1). Figure 1 Loosely install the four M8 bolts at each corner of the skid plate (fig. 2). Figure 2 Once all four bolts are installed, tighten to 18 ft-lbs.
