AEV 56060004AA Installation Manual

Rear diff slider

Download this manual

REAR DIFF SLIDER

FOR GM LIGHT DUTY TRUCKS

PLEASE READ ENTIRELY BEFORE YOU START

To guarantee a quality installation, we recommend reading these instructions thoroughly

before beginning any work. These instructions assume a certain amount of mechanical

ability and are not written nor intended for someone not familiar with auto repair.

AEV30473AA

Last Updated: 08/31/23

Need help?

Do you have a question about the 56060004AA and is the answer not in the manual?

Page 1 REAR DIFF SLIDER FOR GM LIGHT DUTY TRUCKS PLEASE READ ENTIRELY BEFORE YOU START To guarantee a quality installation, we recommend reading these instructions thoroughly before beginning any work. These instructions assume a certain amount of mechanical ability and are not written nor intended for someone not familiar with auto repair. AEV30473AA Last Updated: 08/31/23...
Page 4 A M E R I C A N E X P E D I T I O N V E H I C L E S Put the U-Bolts around the rear differential and loosely install the M8 nuts. Figure 1 Place the clamp over the rear differential ensuring that the tabs face the rear of the vehicle Figure 2...
Page 5 A M E R I C A N E X P E D I T I O N V E H I C L E S Install the two M10 bolts into the differential clamp. Tighten these to 40 ft-lbs. Figure 3 Tighten the nuts on the U-bolts to 18 ft-lbs.
