TRAIL CAMERA
RELOCATION KIT
2018+ JEEP WRANGLER & GLADIATOR
PLEASE READ ENTIRELY BEFORE YOU START
To guarantee a quality installation, we recommend reading these instructions thoroughly before
beginning any work. These instructions assume a certain amount of mechanical ability and are not
written nor intended for someone not familiar with auto repair.
TABLE OF CONTENTS
I. Vehicle Preparation II.
Camera Installation
REQUIRED TOOLS
Common Hand Tools including Metric Wrenches or Sockets
Allen Drivers
T-20 Torx driver
Thin needle nose pliers
Center Punch
Sharp Knife or Clippers
It is recommended to purchase the standard Mopar Grill insert (PN:6QN22RXFAB) to
replace the camera mount grill insert.
AEV30441AA Last Updated: 04/29/24
Advertisement
Related Manuals for AEV 12301095AB
Summary of Contents for AEV 12301095AB
- Page 1 TRAIL CAMERA RELOCATION KIT 2018+ JEEP WRANGLER & GLADIATOR PLEASE READ ENTIRELY BEFORE YOU START To guarantee a quality installation, we recommend reading these instructions thoroughly before beginning any work. These instructions assume a certain amount of mechanical ability and are not written nor intended for someone not familiar with auto repair.
-
Page 3: Vehicle Preparation
Remove OEM grill, camera housing, and washer nozzle. NOTE: If camera relocation kit is being installed after AEV bumper, the bumper will need to be almost fully removed/loosened in order to free up enough space to remove grill. Follow bumper installation instruction in reverse order until tube weldment and back side reinforcement brackets are able to be moved out of the way in order to remove the grill. - Page 4 A M E R I C A N E X P E D I T I O N V E H I C L E S Figure 2 Once the grill is loose, lean it forward to access the camera connections. Squeeze the quick connect at the washer nozzle to disconnect it and then disconnect the wiring connector from the grill (fig.
- Page 5 Reinstall the grill onto the vehicle. Snap the bottom clips in, then install the original push-rivets. Install camera into AEV relocation housings. It will only fit 1 way due to the alignment tabs. When looking from the rear of the housing with the mounting tabs facing up, the connector should be on the right hand side. Use the 3 small screws provided in the kit to retain the camera into the housing.
-
Page 6: Camera Installation
A M E R I C A N E X P E D I T I O N V E H I C L E S Cut off 4” of the supplied hose. Insert one end onto the washer nozzle barb fitting, being sure it seats fully. Thin needle nose pliers will help due to the tight clearances. - Page 7 A M E R I C A N E X P E D I T I O N V E H I C L E S Figure 14 Route the camera wiring harness alongside the washer hose (see fig. 13). (Note: MY24+ Be sure the wire extension plugs into the vehicle first, then the original OEM harness connects onto the extension ultimately completing the circuit to the camera.) Also, be sure the straight connector on the washer hose goes on the chassis side and the 90°...
- Page 8 A M E R I C A N E X P E D I T I O N V E H I C L E S Finish the rest of the bumper installation.
