AEV 10308306AA Installation Manual

Front splash guards

Download this manual

FRONT SPLASH GUARDS

FOR RAM TRUCKS WITH FACTORY FENDER FLARES

PLEASE READ ENTIRELY BEFORE YOU START

To guarantee a quality installation, we recommend reading these instructions thoroughly

before beginning any work. These instructions assume a certain amount of mechanical

ability and are not written nor intended for someone not familiar with auto repair.

REQUIRED TOOLS

Automotive Lift or Jack

Common Hand Tools

Drill

5/16" and 1/4" Drill Bits

AEV30461AA

Last Updated: 12/07/22

Need help?

Do you have a question about the 10308306AA and is the answer not in the manual?

Page 1 FRONT SPLASH GUARDS FOR RAM TRUCKS WITH FACTORY FENDER FLARES PLEASE READ ENTIRELY BEFORE YOU START To guarantee a quality installation, we recommend reading these instructions thoroughly before beginning any work. These instructions assume a certain amount of mechanical ability and are not written nor intended for someone not familiar with auto repair. REQUIRED TOOLS Automotive Lift or Jack Common Hand Tools...
Page 3 1/4” Remove the plastic guards shown and discard (fig. 2). Figure 1 Figure 2 Drill out four 5/16” holes and four 1/4” holes along the bolt pattern in the AEV Front Splash Guard (fig. 3). 1/4” 5/16” 1/8” Figure 3 Use the four factory bolts removed in step 3 to loosely install the Splash Guard onto the vehicle along the inner holes.
Page 4 A M E R I C A N E X P E D I T I O N V E H I C L E S Using the Splash Guard as a template, drill the innermost hole to 5/16” into the wheel liner (fig. 5). Drill the outer three holes to 1/4”...
