TRUCK LUGGAGE EXPEDITION ASSEMBLY INSTRUCTIONS
1) Assemble clamps
with bracket.
3) Assemble tubes
5) Mount rod on to bracket.
Secure with hook.
by TruXedo, Inc.
P.O. Box 1078, 2209 Kellen Gross Dr., Yankton, SD 57078
Phone: 877- 878-9336 • Fax: (605) 664-9304 www.truxedo.com
Press Button Down
and align with hole.
2) Mount bracket on to truck.
Insert hook and chord through
these holes.
4) Insert through loops.
P/N 1117899 Rev. B
Advertisement
Related Manuals for TruXedo Expedition
Summary of Contents for TruXedo Expedition
- Page 1 Press Button Down and align with hole. 5) Mount rod on to bracket. Secure with hook. by TruXedo, Inc. P.O. Box 1078, 2209 Kellen Gross Dr., Yankton, SD 57078 Phone: 877- 878-9336 • Fax: (605) 664-9304 www.truxedo.com P/N 1117899 Rev. B...
- Page 2 NOTE: The chords should be pulled tight to keep the sides tight NOTE: Place driver and passenger brackets the same distance from the front bulkhead by TruXedo, Inc. P.O. Box 1078, 2209 Kellen Gross Dr., Yankton, SD 57078 Phone: 877- 878-9336 • Fax: (605) 664-9304 www.truxedo.com P/N 1117899 Rev. B...
