Rugged Ridge OUTLAND AUTOMOTIVE 13213 Series Installation Instructions

Installation instructions ( p/n: 13213.XX – 13210.XX – 13211.XX – 13212.XX)
1976-2006 Jeep® Neoprene Front Seat Covers
Parts included: (1) Front driver's side neoprene seat cover (upper and lower sections).
(2) Front passenger's side neoprene seat cover (upper and lower sections).
Instructions:
Step (1) Set the cover sections out to
identify driver from passenger (a). The
upper sections can be identified by
looking at the slit sewn in for the pull
lever on the side of the seat (if
applicable) for the upper portions. This
slit should be facing towards the door
on each side. The lower sections can be
identified by looking for the slits sewn in
for the seat belt receptacle and the seat
back adjustment lever (b).
Step (2) The process will be easier if you
install the lower portions first. Begin by
opening the flaps on both sides (a).
Step (3) Slide the front of the cover on,
while leaving the straps hanging out of
the front. While pulling the cover to the
back of the seat, make sure to pull the
seat belt receptacle and seat back
release lever through the sewn slits (a,
b). To tighten the fit, the bottom of the
neoprene can be tucked between the
side support and the seat's fabric cover
(c). Pull the straps on the back of the
bottom section through to the back of
the seat (d). Reach under the seat and
attach the buckles on the straps
together. Use the excess strap to pull the
seats tight. Be careful not to over tighten
these straps. There should be an even
surface where the straps lie under the
cover.
Step (1a)
Step (2)
Step (3b)
Step (3d)
Step (1b)
Step (3a)
Step (3c)
Page 1
