Rugged Ridge 13236.01 COV-A Installation Instructions

Universal Front Cargo Seat Cover Installation Instruction
Content: (1) 2 pcs Cargo Seat Cover
1. Attach rear cover to
front cover buy
looping the top two
strap through buckles
as shown. Do Not
tighten at this time.
5. Adjust side straps to
center cover over front
and back of seat.
9. Pull sides around
seat base and attach
retainer hooks to
suitable points
under seat base.
Rev. 1 (11/11/09)
(7) Cargo Cover Storage Bags
2. If equipped, head rest
should be raised or
removed.
6. If seat is equipped with
side air bags make sure
straps are clear of
deployment zone.
10. Test all seat
functions. Hooks
and straps should
not effect seat
movement.
13236.01 COV-A
Front Cargo Seat Cover (Black)
13236.04 COV-B
Front Cargo Seat Cover (Tan)
3. Slip cover over
top of seat. Pull down
into position. Straps
should be placed
above and below
lever if equipped.
7. Attach top Velcro
strap and front
hold down strap to
back cover.
11. Inspect and make
any final adjustments
needed.
PG.1
4. Slide front hold down
strap between upper
and lower seat
sections. Reclining
the seat will ease
strap installation.
8. Secure all upper
seat straps at this
time making sure
cover is centered.
12. Attach Cargo bags
as desired.
