2007-08 Jeep® Wrangler JK - Neoprene Rear Seat Covers
Parts included:
(1) Rear top cover
(1) Rear bottom cover
(2) Head Rest Covers
NOTE:
Instructions:
Step (1) Remove rear headrest from
seat. The headrest can be
removed by pressing the
two buttons located on the top
of the seat.
Step (2) Slip upper seat cover over
rear seat. Note location
of headrest mounting holes.
Slip lower Velcro strip
between the upper and
lower portions of the seat
and secure. Connect zipper
and close.
Step (3) Push seat cover over headrest
mounting plates. Secure under
plastic caps as shown.
Step (4) Adjust upper seat cover as
needed for proper fitment.
Step (5) Slip lower cover over seat
bottom and slide back clips
and straps through the gap
between the top section and
the lower seat section.
Fold and touble the seat so
that front to rear straps can
be secured.
Step (6) With seat folded forward
loosen staps and attach front
strap to back clip. Repeat for all
three locations.
Installation instructions
2-Door Rear Seats
Please read instructions before installing
P/N: 13265.01
Step(1)
Step (2)
Step (3)
13265.04
13265.09
13265.53
Advertisement
Related Manuals for Rugged Ridge OUTLAND 13265.01
Summary of Contents for Rugged Ridge OUTLAND 13265.01
- Page 1 P/N: 13265.01 Installation instructions 13265.04 2007-08 Jeep® Wrangler JK - Neoprene Rear Seat Covers 13265.09 2-Door Rear Seats 13265.53 Parts included: (1) Rear top cover (1) Rear bottom cover (2) Head Rest Covers NOTE: Please read instructions before installing Instructions: Step(1) Step (1) Remove rear headrest from seat.
- Page 2 Step (6) Step (7) With straps attached carefully pull straps to thighten. NOTE: DO NOT OVER TIGHTEN Damage to seat cover may result. Step (8) Slide side clips between the seat and the fenderwell and secure. Fold seat back down and check fitment of cover noting carseat attachment Step (9)
- Page 3 LIMITED 90 DAY WARRANTY that should the product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 90 DAYS from the date of original purchase, such such defects will be repaired or replaced or credited at the Company’s sole option. To obtain repair or replacement within the terms of this Warranty, the product is to be delivered with proof of warranty coverage (e.g.
