Rugged Ridge 13214.01 Manual

2007-Current Jeep® Wrangler JK-Neoprene Front Seat Covers 2-door and 4-door (front seats only)
Parts included:
(1) Front driver's side seat cover - with head rest
(1) Front passenger's side seat cover - with head rest
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE YOU BEGIN.
Step 1. Slide, and tilt back of seat forward.
Step 2. Remove head rest.
Step 3. Place upper cover over top of seat.
Pull all the way down as shown.
Step 4. The neoprene cover has two holes
located on top. Push the fabric down
and under plastic head rest lock tabs
mounted into top of seat.
Step 5. Fish front ap through gap between the
upper and lower seat sections. This is a
tight t. Folding seat forward may help.
Step 6. Pull rear ap tight and attach to the front
ap using attached Velcro. Adjust cover for
proper t.
Step 7. Side ABS air bag cover should slipped
under cover as shown. Install head
rest cover and attach velcro to secure.
Step 8. Place driver's side lower cover onto seat.
Fish rear buckles through gap between the
upper and lower seat. This is a tight t. Folding
the seat forward
Rev. 12/10
460 HORIZON DR. SUITE 400 | SUWANEE, GA 30024 | PHONE: 770-614-6101 | FAX: 770-614-6069 | info@omix-ada.com
Page 1 of 2
IS-NFSC-02
13214.01 13215.01
13214.09 13215.09
13214.53 13215.53
13215.04
SB
