Delta 101 RS5701W Manual

single bike horizontal
wall mount rack
Assembly instructions
Locate stud beneath wallboard.
1
Mark position on wall at desired height.
Assemble front plate and arms against
2
back plate to a secure t.
Mount securely to wall.
3
(screws should be in
center of wall stud)
IMPORTANT SAFETY NOTE
Beware of drilling into electrical wire
or pipes within wall!
WARNING
Do not exceed maximum total weight limit of 22kg/50lbs. Incorrect wall mounting could result in items falling and injury
to persons. Avoid mounting in a position where personal injury could result from walking into protruding rack.
RS5701W
WALLBOARD
Assembly video
Visit designbydelta.com/downloads
STUD
