- Page 1 Lighting made better. User Manual 2 Head LED Emergency Light SKU: EM_2HFL support@sunco.com (844) 334-9938...
-
Page 2: What's In The Box
What’s in the Box? LED Emergency Light Mounting Screws Wire Nuts Wall Anchors... -
Page 3: Before Your Start
Before Your Start Safety Information To reduce the risk of fire, electric shock, or physical injury: • Turn off circuit breaker before • Not compatible with dimmers. installing this fixture. • Not compatible with timing devices. • Suitable for use in damp •... - Page 4 Installation Guide STEP 1 STEP 2 a. Turn off circuit breaker. a. Thread fixture wires through backplate and connect to building wires. b. Using a flathead screwdriver, pry open triangle slots near the test button to 120V: -Black to Black (Live) -White to remove backplate.
- Page 5 Installation Guide (Cont.) STEP 3 STEP 4 a. Drill into desired mounting pattern a. Attach housing into place starting with indicators from the backplate. the backplate’s bottom side, then the top side (test button side). b. Install mounting screws (A) into drilled mounting hole indicators to install fixture b.
-
Page 6: Product Details
Product Details Specifications Voltage 6000K 120V/277V Wattage Lumens 230LM 2.4W Material Charging Time ABS + PMMA Title 20 Compliance Fire Resistant LED Heads Frequency 60Hz Power Source Battery Weight 1.35lbs Warranty Dimmable 1 Year... -
Page 7: Wiring Diagram
Wiring Diagram Remote capable Regular NOTE: NOTE: Unused input lead must be properly Use 18-22AWG standard insulated with wire nut or other wire to connect remote lamp heads. approved method. - Page 8 Lighting made better. support@sunco.com (844) 334-9938 REV1.0...
