- Page 1 Lighting made better. User Manual 5/6” Selectable Gimbal Downlight SKU: DL_G56-12W-27K_5K support@sunco.com (844) 334-9938...
-
Page 2: What's In The Box
What’s in the Box? Retrofit Downlight Light Fixture TP24 Connector E26 Base... - Page 3 Before You Start Safety Information To reduce the risk of fire, electric shock, or physical injury: • Turn off circuit breaker before installing this fixture. • Use safety precautions and abide by regional and local • This product should be installed by a person familiar with laws or regulations.
- Page 4 Installation Guide STEP 1 a. Turn off circuit breaker before installation. b. Locate the housing and remove the previous fixture. Note: Light fixture may be hot! Allow time for fixture to cool after power is off. STEP 2 a. Determine the size of the opening (5″ or 6″). b.
- Page 5 Installation Guide (Cont.) STEP 4 a. Connect the appropriate adapter with lamp base connector in the housing. Note: The wires may come loose from the connectors. Ensure that they are attached securely. STEP 5 a. Use the switch on the back of the retrofit to select 5000K 4000K one of five color temperatures.
-
Page 6: Product Details
Product Details Recommended Dimmers Brand Model LUTRON AYCL-153P-WH LUTRON DVCL-153P-WH LUTRON MACL-153M-WH PD-6WCL-WH-P LUTRON LUTRON P-PKG1WB-WH LUTRON SCL-153P-WH LEVITON D26HD-2RW CLOUDY BAY CBLD001WHA KASA SMART HS220 Specifications Voltage 120 V Average Lifetime 50,000 Hours Wattage 12 W Lumens 800 lm Efficacy 67 lm/W Moisture Rating... -
Page 7: Common Troubleshooting
Common Troubleshooting Feeling in the dark about an issue with your product? No If you still need some assistance, please feel free to worries! Our troubleshooting section is here to shed some light contact us with any questions. Our team of lighting experts and provide you with easy-to-follow solutions for any problem. - Page 8 Common Troubleshooting Flickering Light is flickering when turning on. Check that fixture wiring connections are secure. Check that the lights on the same circuit are not Light flickering with other lights on the same circuit. overloading the circuit. Light flickering when turned on. Verify fixture compatibility and that it is grounded.
- Page 9 Light Distribution Angle -/+180 -150 -120 AVERAGE BEAM ANGLE (50%): 91.1 DEG C0/180 90.5° C90/270 91.8° UNIT:cd Luminous Intensity Distribution 1 Lighting distribution angle refers to the spread of light An asymmetric lighting distribution angle, also known emitted from a light source. It is an important factor to as beam angle, creates a pattern that focuses light in a consider when selecting a fixture or bulb, as it affects the specific direction.
- Page 10 Lighting made better. support@sunco.com (844) 334-9938 REV1.0...
