- Page 1 Lighting made better. User Manual LED Exit Sign SKU: EX-RED EX-GRN support @sunco.com (844) 334-9938...
-
Page 2: What's In The Box
What’s in the Box? Exit Sign Components Exit Sign Housing + Panel Canopy Mount Trim Plate Support Connectors Wire Nuts Mounting Screws... -
Page 3: What You Need
What You Need Get Your Gear Drill Pliers Screwdriver Ladder IMPORTANT: Prior to exit sign installation, install junction box in ceiling or wall. When re-lamping, use only lamps specified in the exit sign. Using other lamp types may result in transformer damage or unsafe conditions. The battery in this unit may not be fully charged upon unboxing. -
Page 4: Before You Start
Before You Start Safety Information (Not Included) • Turn off circuit breaker before installing this fixture. • Not compatible with timing devices. • Suitable for use in damp environments at temperatures • All electrical connections must be in accordance with local ranging from 32°F to 104°F. - Page 5 Installation Guide STEP 1 a. Turn off circuit breaker before installation. b. Components are stored inside the exit sign. STEP 2 a. Using a flathead screwdriver, insert into slots on top and pry open the housing of the front side exit sign. Unsnap and pull off faceplate and set aside.
- Page 6 Installation Guide (Cont.) STEP 4 a. Remove canopy mount (b) and mounting hardware from plastic packaging. b. Snap the two support connectors (d) into the canopy mount slots into the back of the canopy mount (b). Note: This should not require a lot of force. STEP 5 a.
- Page 7 Installation Guide (Cont.) STEP 6 a. Connect battery to the PC board by plugging wire into socket. b. Connect exit sign lead wires to AC input leads in junction box (not included) and cap off unused wires with wire nuts (e). - Red to Black (Live) •...
-
Page 8: Product Details
Product Details Wiring Diagram Specifications Voltage 120V-277V Average Lifetime 26280 Hours Wattage 1.6W Lumens Power Factor 0.45 IP Rating IP20 Battery 1.2V1000mah NI-MH Weight Power Source 1.54 lbs Battery Housing Material Amps 20mA Dimmable Warranty 3 Years... -
Page 9: Common Troubleshooting
Common Troubleshooting Feeling in the dark about an issue with your product? No If you still need some assistance, please feel free to contact worries! Our troubleshooting section is here to shed some light us with any questions. Our team of lighting experts are and provide you with easy-to-follow solutions for any problem. - Page 10 Lighting made better. support @sunco.com (844) 334-9938 REV1.0...
