- Page 1 M1-STP Smart Peristaltic Pump User Manual A0 2023-03-24 Kamoer Fluid Tech (Shanghai) Co., Ltd. www.kamoer.com...
-
Page 2: Table Of Contents
Catalog Product overview ..........................4 1.1 Introduction ..........................4 1.2 Feature Highlights ........................4 1.3 Applications ..........................4 1.4 Part Names ............................5 Touch screen control ...........................6 2.1 System menu ..........................6 2.2 Continuous mode .........................7 2.3 Quantitative mode ........................7 2.4 Pump head calibration .......................10 2.5 Current ............................ -
Page 3: Quality Assurance
Quality Assurance 1. Warranty conditions The free service during the warranty period is only valid under normal use and maintenance according to the user manual, and all man-made failures or damages are not covered by the warranty. Users please keep the purchase invoice and user manual well, so that you can get satisfactory after-sales service in time. -
Page 4: Product Description
7) Negligent handling, modification or repair by personnel not authorized by the company (please do not disassemble or repair without authorization); 8) Failure or damage caused by use outside the applicable occasion; 9) Damage caused by force majeure, etc.; 10) Consumable and wearing parts ( such as pump pipes, connecting pipes, etc.); 11) The warranty period has expired. -
Page 5: Component Names
Pet: Aquarium titration 1.4 Component names 1. Color LCD display 2. Pump head 3. Buttons Menu: Click to enter the menu, or return to the previous menu from the submenu -: Click to decrease the amount or the menu is up ... -
Page 6: Touch Screen Control
2.Touch Screen Control 2.1 System menu Enter the system menu by pressing the menu button. In the system menu, select continuous mode or quantitative mode to return to the working mode. 1. Continuous mode, click the setting button to enter continuous mode 2. -
Page 7: Continuous Mode
2.2 Continuous mode The operation characteristic of the continuous mode is that after the operation is triggered, the pump will run continuously until it is triggered again to stop, and the pump can also be started and stopped by the foot switch. 1. - Page 8 1. Running direction: the running direction of the pump, switch the direction through the direction button 2. Start and stop: control the start and stop of the pump, by controlling the inner diameter of the start and stop 3. Quantitative: Quantitative working mode 4.
- Page 9 2.3.2 Quantitative mode modification Modify quantitation settings Under the quantitative mode setting menu, enter the modification parameters (volume, time, number of turns) by pressing Modify Quantitative Use the + and - buttons to adjust, press the setting button to take effect, and press the menu button to return to the upper menu.
-
Page 10: Pump Head Calibration
2 .4 Pump Head Calibration If you want to make the flow parameters displayed by the equipment more accurate, you need to perform flow calibration on the pump. The process is to prepare a graduated cylinder, let the pump run for a period of time, and input the liquid that the pump has run for this period of time into the program to complete the calibration function. -
Page 11: Power-On State
1. Current menu: Press the SET button to return to the previous menu 2. Current number: display the current current 3. Setting: Press the setting button to take effect of the current current 4. Menu: Press the menu button to return to the previous menu 2.6 Power-on state The power-on status function is a function to set the status of the device when it is powered on. -
Page 12: Appendix
Address: Building 4, No. 79, Xiangjing Road, Songjiang District, Shanghai Website: www.kamoer.com Kamoer, Kamoer words and icons are registered trademarks of Kamoer Fluid Tech (Shanghai) Co., Ltd. The company reserves the right to improve and change product appearance and technical specifications without prior notice.
