SAUTVS ZP-YJ-030603-018 Install Instructions

Package Contents
Name Spec
Lower Doors 2 pcs
U-Nuts M6
Circular Arc
Washers
Lock Nuts M6
M6*80
Hexagon
M6*50
Socket Screw
M6*40
T-Nuts M6
Metal
2 pcs
Brackets
Seal Gasket 1.5m
Sponge Mat 6mm
with Adhesive *13mm
Tape *1m
1
Image Qty
1 set
2
8
10
4
4
2
6
4
2
1 set
1
Place the U-Nuts on the bracket
of the half door.
Install the metal bracket, and use the M6*40 screws to mount the bracket on
the plastic half door.
Use the M6*80 (pointed by red arrow) and
M6*50 (pointed by yellow arrow) screws to
fix the plastic half door to the door of car as
shown in the figure.
Front Lower Doors for Maverick X3
3
Remove the original small lower
half door from the X3.
5
Close the door and adjust the
clearance between the lower half
door and the body of car, tighten
the screws.
