SAUTVS ZP-YJ-030507-020 Manual

Combination Roof for Polaris Ranger XP 1000
4 Doors
ZP-YJ-030507-020
BEFORE YOU BEGIN
Read these instructions and check to be sure all parts and tools are accounted for. Please retain
these installation instructions for future reference.
IMPORTANT
The Roof is exclusively designed for your vehicle. Please read the installation instructions
thoroughly before beginning. Installation is easier if the vehicle is clean and free of debris. For your
safety, and to ensure a satisfactory installation, perform all installation steps correctly in the
sequence shown.
INSTALLATION INSTRUCTIONS
Note: Shift vehicle transmission into "PARK".
Turn key to "OFF" position and remove from
vehicle.
Pictures of products and accessories
1 2
3 4
1. First, get the adhesive sponge pad from the
accessories package, and stick it on the edges
of the four pieces of the roof (stick to the
opposite edge), then assemble the separate
parts together and fix them with screws. As
shown in picture:
Note: When assembling, first fix Part No. 1 and
No. 2, Part No. 3 and No. 4, don't screw the
joint points between Part No.2 and No.3.
