READ BEFORE INSTALLATION:
Before attaching the antenna to any surface, TEST RECEPTION in that area.
desired, move the antenna and rescan for the available channels.
SET UP THE ANTENNA:
Make sure the antenna
is facing the broadcast
towers.
3
NOTE:
Coaxial Cable
antenna and the amplifier.
You cannot attach the male
connector on the amplifier's
coaxial cable to the antenna
or the antenna and amplifier
will not work.
TV RECEPTION CAN BE AFFECTED BY OBSTRUCTIONS OR DISTANCE
BETWEEN YOUR HOME AND BROADCAST TOWERS.
Call us toll-free for technical assistance at
or contact
support@antennasdirect.com
Connect the antenna to the TV or converter box and run a full channel scan. If reception is not as
Attach the antenna to a wall or non-metallic surface using the the included push-pins in the small holes at the
top of the antenna or on a window using the hook & loop tabs.
Clean any surface and allow to air-dry before using the hook & loop tabs.
care when removing.
The Jolt Switch gives you control in real time when managing your
TV signals. The simple ON/OFF switch allows you to bypass
amplification when a TV channel doesn't need it. The amplifier
arrives in the ON position, increasing TV signals for a clearer picture
and sound. When the switch is OFF, easily bypass the amplifier while
signals are still being filtered from cellular and FM interference.
Certain TV signals may be strong enough that an amplifier is not
necessary. If a channel is distorted or pixilated when the amplifier is
ON, it may be over-amplified. Toggle the switch to the OFF position.
You do not need to rescan your TV for channels unless you reposition
or reconnect your antenna.
You must use the 12 .
(3)
between the
Now that you've installed your antenna, you are ready to scan for channels. See
Congratulations! You're watching HDTV for FREE! Welcome to the Antennas Direct cord-cutting family.
1-877-825-5572
Antenna Input
5
ANT-IN
4
When using the
USB port on the
back of your TV, the
Jolt Switch In-Line
Amplifier only
draws power when
the TV is on.
The ClearStream FLEX comes with:
1)
ClearStream FLEX Antenna
2)
Hook & Loop Tabs and Push Pins
3)
12 . Coaxial Cable
4)
Jolt Switch 18dB In-Line Amplifier with
Coaxial Cable and 6 . USB Cable
The adhesive is strong - please take
To Antenna
USB Port
Pr
Pb
Y
USB
R
L
CVBS
HDMI
TV or Converter Box
"Scanning for channels"
in the troubleshooting guide.
FIND TV CHANNELS, AIM YOUR ANTENNA
DOWNLOAD OUR FREE APP
To TV
USB Cable
to TV or
Power
Adapter
If you do not have
the option of using a
USB port on the TV
for power, you can
plug the amplifier
into a standard USB
power adapter (not
included).
