Antennas Direct C2MVJ Quick Start Assembly/Installation Instructions

Advertisement

Quick Links

Connect the antenna to the TV or converter box and run a full channel scan. If reception is not as desired, move the antenna and rescan for the available channels.
1
INDOOR INSTALLATION
Connect coaxial cable
(sold separately)
to the
antenna prior to inserting
the cable into the
Antenna Stand (2).
Follow the instructions in the owner's manual of your TV or converter box to change
the settings from 'CABLE' to 'ANTENNA', 'AIR', or 'BROADCAST'.
Point the front of the antenna in the direction of your TV stations' broadcast towers
and check reception by scanning for channels. If you are not receiving all of the
available channels, move the antenna and rescan.
OUTDOOR INSTALLATION
Required: Coaxial Cable
(sold
separately), Adjustable Wrench, Power Drill, 3/16" Drill Bit,
8 and 10mm Ratcheting Drivers, and a #2 Phillips Screwdriver
To add the
mounting
hardware,
you must
first remove
the long bolt.
Next, follow the
illustrations to
attach the
mounting
hardware to the
antenna.
Follow the instructions in the owner's manual of your TV or converter box to
change the input from 'CABLE' to 'ANTENNA', 'AIR', or 'BROADCAST'.
Point the front of the antenna in the direction of your TV stations' broadcast towers
and check reception by scanning for channels. If you are not receiving all of the
available channels, move the antenna and rescan.
J-MOUNT INSTALLATION
Attach the J-Mount Mast
(3)
to the Mount Base
the Hex Bolts and Nuts (8), as shown above.
Mark the Mount Base
(10)
position on the desired surface
and drill pilot holes, 1" deep, for each of the 50mm
J-Mount Bolts (9).
Place the Sealing Pads
(11)
over the pilot holes, and the
Mount Base
(10)
on top of the Sealing Pads.
Tighten the J-Mount Bolts
(9)
to secure the base to the
surface.
Call to Learn.
Toll-Free Helpline:
Quick Start Assembly/Installation Instructions
CLEARSTREAM 2MAX™
Before beginning assembly, make sure all parts needed are present.
Coaxial cable sold separately.
4
3
2
Raise dipoles
until they click
into place.
2
7
6
7
5
Use the long bolt, removed
from the spine in the
previous step, and the Mast
Clamp Bolt
(5)
to secure the
Back Plate (6).
WALL MOUNT
(10)
with
1-877-825-5572
Technical Assistance is available
and Saturday – Sunday, 10:00 am to 6:00 pm, Central Time.
5
7
The ClearStream 2MAX™ comes with:
1)
6
2)
3)
8
9
4)
5)
6)
7)
10
8)
9)
10)
11
11)
Before permanently attaching the antenna to any surface, TEST
RECEPTION in that area.
HELPFUL TIP: IT'S IMPORTANT TO CHECK THE RECEPTION IN THE
LOCATION WHERE YOU INTEND TO INSTALL THE ANTENNA, PRIOR TO
ATTACHING THE J-MOUNT MAST TO ANY SURFACE.
Before installing the antenna on the J-Mount Mast (3), adjust
the mast, so it is in a vertical position. You will need to adjust
the antenna a er it is mounted for the best reception.
Install the antenna
on the J-Mount
Mast
(3)
by
positioning the Mast
Clamp
(6)
around
the mast. Tighten
the Wing Nuts
(7)
to
secure the antenna
to the mast.
10
9
11
Monday – Friday, 9:00 am to 9:00 pm
ClearStream 2MAX™ Antenna
Indoor Antenna Stand
J-Mount Mast
Mast End Cap
1 - 25mm Mast Clamp Bolt
Mast Clamp and Back Plate
Wing Nuts and U-Clamp
2 - 40mm Hex Bolts and Nuts
4 - 50mm J-Mount Bolts
Mount Base
4 - Sealing Pads
FRONT VIEW
To locate the broadcast towers in your area, go to
antennapoint.com and enter your zip code, or scan the
QR code.
8
10
Raise dipoles
until they click
into place.
4
3
8
