Antennas Direct CLEARSTREAM MAX-XR COMPLETE C2M-AC Quick Start Assembly/Installation Instructions

READ BEFORE INSTALLATION:
Before permanently attaching the antenna to any surface, TEST RECEPTION in that area.
move the antenna and rescan for the available channels.
1
FRONT VIEW
Connect the 2pc Dipoles (2).
IMPORTANT: CHECK THE RECEPTION IN THE LOCATION WHERE YOU INTEND TO INSTALL THE ANTENNA PRIOR TO ATTACHING THE MAST TO ANY SURFACE.
Before assembling the Antenna Base
7
8
8
7
4
8
6
5
7
10
Before installing
the antenna on the
Mast (9), adjust the
Mast so it is in a
vertical position. 9
You will need to
adjust the antenna
a er it is mounted
for the best
reception.
13
12
EX: VERTICAL MOUNT
14
13
12
NOTE: Mast is designed to pivot for vertical
or horizontal surfaces.
Mark the Mount Base (13) position on the
desired surface and drill pilot holes, 1 ½"
deep, for each of the 50mm Screws (12).
Place the Sealing Pads (14) over the pilot
holes, and the Mount Base (13) on top of
the Sealing Pads.
TV RECEPTION CAN BE AFFECTED BY OBSTRUCTIONS OR DISTANCE
BETWEEN YOUR HOME AND BROADCAST TOWERS.
Call us toll-free for technical assistance at
or contact support@antennasdirect.com
CLEARSTREAM™ MAX-XR COMPLETE
3
2
5
4
6
7
8
2
2
3
(4) to the Antenna Element (1) make sure the Short Tube is inside the Antenna Base (4).
1
NOTE: You must use the 30 . Coaxial
Cable (16) between the antenna and the
amplifier. You cannot attach the male
connector on the amplifier's coaxial cable
to the antenna or the antenna and
amplifier will not work.
To Antenna
The Jolt Switch gives you control in real time
when managing your TV signals. The simple
ON/OFF switch allows you to bypass
amplification when a TV channel doesn't need
it. The amplifier arrives in the ON position,
increasing TV signals for a clearer picture and
sound. When the switch is OFF, easily bypass
the amplifier while signals are still being
filtered from cellular and FM interference.
Certain TV signals may be strong enough
that an amplifier is not necessary. If a
channel is distorted or pixelated when the
amplifier is ON, it may be over-amplified.
Toggle the switch to the OFF position. You do
not need to rescan your TV for channels unless
you reposition or reconnect your antenna.
1-877-825-5572
Connect the antenna to the TV or converter box and run a full channel scan. If reception is not as desired,
10
15
11
3-WAY SPLITTER
5-900 MHz
9
16
12
13
17
14
18
1
Dipole Fasteners
Make sure the front of
the antenna is facing the
broadcast towers.
17
To Splitter
USB Cable to
Power Supply
17
18
Now that you've installed your antenna, you are ready to scan for
channels. See "Scanning for channels"
Congratulations! You're watching HDTV for FREE!
Welcome to the Antennas Direct cord-cutting family.
FIND TV CHANNELS, AIM YOUR ANTENNA
1) Antenna Element
2) VHF Dipoles
3) 2 - Dipole Fasteners
4) Antenna Base with Short Tube
5) 60mm Bolt
6) 30mm Bolt
7) U-Bolt and Wing Nuts
8) Mast Clamp and Back Plate
9) Mast
10) Mast End Cap
11) 2 - 40mm Hex Bolts and Nuts
12) 4 - 50mm Screws
13) Mount Base
14) 4 - Sealing Pads
15) 3-Way Splitter
16) 30 . Coaxial Cable
17) Jolt Switch 18 dB In-Line Amplifier
with Coaxial Cable and 6 . USB Cable
18) USB Power Adapter (style may vary)
(3) will snap into place.
HDTV
HDTV
15
3-WAY SPLITTER
5-900 MHz
in the troubleshooting guide.
DOWNLOAD OUR FREE APP
HDTV
