Rugged Ridge 11425.03 Manual

Contents:
1. Gas Door (1)
2. Self Tapping Screws (4)
3. Keys (2) *
*Note - Only on Locking Models
1. Install the Fuel hatch cover over the existing fuel filler trim. Make sure the door opens level.
2. Start one of the included screws applying force while turning. This will start the screw into the plastic.
Working in an X pattern, start the remaining screws. Once all screws are started, tighten them in an
X pattern.
Jeep JK Wrangler Gas Door
®
Figure 1a
11425.03 - JK Gas Door, Chrome
11425.04 - JK Gas Door, Chrome, Locking
11425.05 - JK Gas Door
11425.06 - JK Gas Door, Locking
Page 1 of 2
Figure 1b
Figure 2b
