- Page 1 80mm Thermal Receipt Printer Driver installation instructions V1.0...
-
Page 2: Windows Driver Installation
1.Windows Driver installation 1.1 Run to install the printer driver. The dialog box shown in the figure below pops up: Select the installation language and click “OK”, as shown in the figure above. 1.2 The dialog box shown in the figure below pops up; click “Install”, as shown in the figure above. - Page 3 1.3 Then the dialog box shown in the figure below pops up: Select the corresponding printer model and port, and then click “Install” as shown in the figure below: a. 58mm Series: Driver for 58mm Series b. 80mm Series: Driver for general 58mm Series c.
- Page 4 d. Finally, click “Finish ” as shown in the figure below.
- Page 5 At this point, the printer driver is installed. 2. Set and Test the Printer 2.1 Set Printer Properties After installing the printer driver, view “Start”-> “Control Panel”-“Printer and Fax”-> “Printer Properties” of 80mm Series Printer. The "Printer Properties" window will pop up, as shown in the figure below:...
- Page 6 2.2 Print Test Page via Serial Port Select “Port” as shown in the figure above. As shown in the figure below: Select the corresponding serial port (take COM1 as an example), select COM1, and then select the configuration port. The following dialog box appears: Set the value of bits per second to be the same as the printer baud rate.
- Page 7 After settings are completed, click “OK” to save the settings. Back to the "Printer Properties" window, select “Apply”, as shown in the figure below:...
- Page 8 After the serial port configuration is completed, select “General”, as shown in the figure below: Select “Print Test Page”. If the test page can be successfully printed, it means the printer has been connected to the PC and configured correctly, and the printer port can be used normally.
- Page 9 2.3 Print Test Page via USB Port Select “USB001 USB Virtual Printer Port”, as shown in the figure below: Then select “Apply ” as shown in the figure above:...
- Page 10 Then select “General” as shown in the figure below: Select “Print Test Page (T)”. If the test page can be successfully printed, it means the printer has been connected to the PC and configured correctly, and the printer port can be used normally.
- Page 11 2.4 Print Test Page via Network Port Open the Printer Properties Select “Add Port ” as shown in the figure above. Select “New Port ...”, as shown in the figure above.
- Page 12 Select “Next ”, as shown in the figure above Then enter “192.168.1.87” after the “Printer Name or IP address ”, and then select “Next ”, as shown in figure above...
- Page 13 Then select “Next”, as shown in figure above Then select “Finish”, that is, a standard TCP/IP port is added.
- Page 14 Select “ ”, then select “Apply ” as shown in the figure above, select “General” as shown in the figure below.
- Page 15 Select “Print Test Page”. If the test page can be successfully printed, it means the printer has been connected to the PC and configured correctly, and the printer port can be used normally.
- Page 16 2.5 Print Test Page via Parallel Port Select a port among “LPT1: Printer Port, LPT2: Printer Port, LPT3: Printer Port”. The port connected with a parallel port line should be selected. Take “LPT1: Printer Port” as an example below. Select “Apply”, as shown in the figure above.
- Page 17 Select “General”, as shown in the figure below. Select “Print Test Page ”. If the test page can be successfully printed, it means the printer has been connected to the PC and configured correctly, and the printer port can be used normally.
- Page 18 2.6 Diffusion knife and Cashbox Settings 2.6.1 Select the Printer Properties, and click “Print Preference Pages”...
- Page 19 2.6.2 The driver has been set to automatically cut paper and open the Cashbox by default. If you need to change the settings, please follow the instructions below: Select “Paper/Quality”, choose whether to cut paper in the “Paper Source” option, for example Report (Cut) is automatic paper cutting, the diffusion knife will automatically cut the paper after the test page is printed.
- Page 20 2.7 Voice Function The function only supports some models. 2.7.1 Select the Printer Properties, and click “Device Settings”...
- Page 21 2.7.2 Click the Voice Function, select the ringtone to be set, and click "Apply".
- Page 22 2.7.3 Click "General" and select “Print Test Page”, and there will be voice when printing.
