Speakman S-2505 Installation, Maintenance & Operation Instructions

S-2505 Installation, Maintenance & Operation Instructions
DESCRIPTION
Speakman polished chrome plated brass 30° flanged shower arm. Drilled for, but less mounting screws.
SPECIFICATIONS
½" NPT FEMALE INLET
½" NPT MALE OUTLET
SHIPPING WEIGHT: 0.7 LBS.
INSTALLATION
Apply pipe thread tape in a clockwise direction to threads of supply nipple. Pipe joint compound may be used
instead of tape. Turning in a clockwise direction, thread the shower arm on to the supply nipple. Tighten & position
with a strap wrench or a pair of soft jaw pliers. Mark and drill holes for mounting screws (not provided). Note: If
necessary, remove shower arm and use proper screw anchors (2) (not provided). Turn the water supply on and
check for leaks. Tighten mounting screws (2).
MAINTENANCE
The gleaming finish of your SPEAKMAN S-2505
shower arm can be cleaned by using mild soap and
warm water. Dry immediately with a soft, clean cloth
for best results.
Product improvements may cause
specification and dimensional
changes without notice.
PO Box 191 Wilmington, DE 19899
SPEAKMAN COMPANY
FLANGED SHOWER ARM
OPTIONS
◊ PBL: Polished Brass Lacquer Finish
SPEAKMAN
Visit us on the web at www.speakmancompany.com
ROUGH-IN MEASUREMENTS
®
Phone: 800-537-2107 Fax: 800-977-2747
09/07
REV 1
92-1811
