Rola 59506 Manual

Please read all instructions carefully before assembly, installation and/or use of this product.
Plastic
Knob
cross bar
Product Name:
ATTACH MOUNTING CLAMPS
•
Basket
•
•
•
•
Mounting
NOTE: The cargo carrier should not move on cross bars when
Bracket
WARNING: There must be a minimum of ½" of threads engaged on
Spacer
U-Bolt Block
INCORRECT
INCORRECTO
Mounting Hardware Kit
Product Code:
Place mounting bracket on top of spacer block. The square holes
in bracket must engage the squares on spacer block.
Install u-bolt around cross bar and into slots in mounting bracket.
Install plastic knobs onto u-bolts.
Tighten all plastic knobs firmly and evenly.
Make sure installation is secure by pulling side-to-side and fore
and aft on basket.
plastic knobs are tightened properly.
u-bolt on all plastic knobs.
59506
CORRECT / CORRECTO
