INSTRUCTION GUIDE FOR:
FPE END SUPPORT KIT SYSTEM
ROLA FPE END SUPPORTS
59972
PAGE 1
PAGE 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 59972 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rola 59972

  • Page 1 INSTRUCTION GUIDE FOR: FPE END SUPPORT KIT SYSTEM ROLA FPE END SUPPORTS 59972 PAGE 1 PAGE 1...
  • Page 2 Damage to your vehicle, your cargo or any person or property is excluded. • Maximum roof loads = weight of the cross bars + accessories + the weight of the load carried. Maximum load is defined by ROLA or the Manufacturer- use which ever is lower.
  • Page 3 Users are responsible for understanding and obeying government laws where they drive. • Do NOT use ROLA cross bars and accessories for purposes other than what they are intended for or exceeding stated load limits. Failure to do so will voidall warranties.
  • Page 4: Prior To Assembly

    No product modifications are allowed- this will void all warranties. • Check that the maximum load is not exceeded. Use the ROLA load limit or the vehicle’s load limit- which ever is lower. Max. roof load = Cross bar weight + Accessory carrier + Load carried.
  • Page 5: Parts List

    INSTALLATION INSTRUCTIONS NOTE: Use this instruction guide and the crossbar Instructions to set up your ROLA cross bars. PARTS LIST 4 End Supports PAGE 5...
  • Page 6 PARTS NOT INCLUDED IN THIS KIT Complete your vehicle Cross Bar System with our recommended Fit Kit and Rails Kit. ROLA Rails Extended Kit- RE43, RE47, RE53, RE60 ROLA Fit Kit- unique to vehicle application ROLA One Key Lock Core System...
  • Page 7 INSTALLATION INSTRUCTIONS Fig. A Under-cover strips 1.  Remove Rola RE cross bars from the carton. Slide out the outer under-cover strips. Fig. A 2.  Slide the positioning slider inward. The slider will be positioned after the crossbar assembly is on the vehicle. Fig. B Fig.
  • Page 8 Fig. A Fig. A Tip: place bar upside down for easier handling of parts 5.  Follow your specific ROLA Fit Kit details to access your vehicle’s fixed points. Fig. B Fig. B Door Style Cover Style 6.  Still following your specific Fit Kit directions, attach the mounting set screws into the vehicle’s fixed points.
  • Page 9 INSTALLATION INSTRUCTIONS 7.  Follow the Fit Kit instructions to attach the gasket pads to the correct cross bar positions. 8.  Clean and dry the roof area where the cross bars install and install fixed point set screw. 9.  Carefully position the cross bars over the fixed point set screws and spacer tube (if required). Once on the car, position the rails to have equal amounts of overhang per side.
  • Page 10 INSTALLATION INSTRUCTIONS Fig. A 10.  Position and tighten the cross bar assemblies over the fixed point set screws. Follow the fit kit instructions for complete installation instructions. Fig. A and Fig. B. CAUTION: be sure to read your fit kit instructions Fig.
  • Page 11 If any looseness is detected, review the installation steps and redo until completely firm. Fig. C Store your ROLA torque wrench in the vehicle’s glove box or some other safe storage place. CAUTION: Check the tensioning bolt torque reading Fig.
  • Page 12 Remove the quarter turn lock plugs from the covers (push out from the inside) Fig. A Fig. B Insert the Rola Control Key into the lock core then slide the core into the covers. Hold back the core and remove the control key Fig. B Fig.
  • Page 13: Additional Installation Instructions

    ADDITIONAL INSTALLATION INSTRUCTIONS Removing the cross bar from the vehicle: Door   S tyle   Cover   S tyle   Installing ROLA T-bolts: For accessories requiring a T-bolt PAGE 13...
  • Page 14 RE-S3001 BUFFER STRIP RE-S3002 UNDER-COVER RE-S3003 POSITION SLIDER RE-S3004 END CAP RE-S3005 ¼ TURN PLUG FP-S3006 FP ROLA WRENCH DF-S3009 DFE/FPE DOOR FP-S3007 FP ALLEN (M4) WRENCH FP-S3010 FP HARDWARE KIT PAGE 14 Accept no compromises, choose only quality roof racks and cargo carriers.
