L2+ Hardened Grade Managed 8-port 10/100/1000Base-TX + 2-port 100/1000Base-SFP + 2-port
RS485/422/232 Contact Closure Ethernet Switch with Redundant DC Power Inputs
The Managed PoE Industrial Switch with 8-Port 10/100/1000Base-TX + 2 x RS485/422/232 and
2xGigabit uplink ports provide stable and reliable Ethernet transmission. It concurrently converts RS-
232/422/485 connections to Ethernet connections, allowing for seamless communication between
traditional serial-based devices such as PLC, meters, sensors, and barcode readers to an IP-based
Ethernet device. Moreover, It can supply power to PD terminal equipment such as wireless AP,
webcam, VoIP, and visual intelligent building intercom through network cable and meet the network
environment that needs a high-density PoE/PoE+/PoE++ power supply.
Package Content
⚫
Managed PoE Switch x 1
⚫
DIN-Rail Clip x 1
⚫
Wall-Mount Kits x 2
⚫
Cable DB9 female to RJ45 x 1
⚫
Quick Installation Guide x 1
◎
Keep power off during installation
◎
use Antistatic Wrist Strap correctly
◎
Make sure using correct power supply, voltage must match
◎
Make sure enough power supply from PSU that will not overload
Quick Installation Guide
IES8222MCH-S-DR
Read Before Install
Quick Installation Guide
IES8222MCH-S-DR / version 1.0
OT Systems Ltd. | www.ot-systems.com
