Product Overview
L3 Hardened Grade Managed 16-port 100/1000Base-SFP + 4-port 10GBase-SFP + 8-port
10/100/1000Base-SFP or 10/100/1000Base-TX Combo Optical Ethernet Switch. This switch is highly
flexible and anti-EMI. -40°~ 75°C operating temperature rang and 8KV Ethernet surge protection can
adapt to a harsh outdoor environment and ensure product reliability.
Product Features
16 x 100/1000Base-SFP + 4 x 10GBase-SFP + 8 x 10/100/1000Base-SFP or 10/100/1000Base-TX
Combo
Support Auto-MDIX, and Full/Half Duplex self-negotiation mode
Provide SC/FC/ST/LC interface fiber port, Support single/dual fiber transmission
Support 10K bytes jumbo frame, compatible with various extension protocols
8K MAC address table
Support IEEE802.3az Energy Efficient Ethernet technology
Electric 8KV surge protection, easy to use in outdoor environment
Complete status indicators, working state at a glance
Power input polarity protection design, no worry about wrong operation
Rugged metal housing, IP40 protection, fan-less design
Installation method: RACK
Package Content
Managed Ethernet Switch x 1
AC Power Cable x 1
Mounting Accessory x 1
Quick Installation Guide
IES82162XMH-S-RP
Quick Installation Guide
IES82162XMH-S-RP / version 1.0
OT Systems Ltd. | www.ot-systems.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the IES82162XMH-S-RP and is the answer not in the manual?

Questions and answers

Summary of Contents for OTS IES82162XMH-S-RP

  • Page 1 Quick Installation Guide IES82162XMH-S-RP / version 1.0 Quick Installation Guide IES82162XMH-S-RP Product Overview L3 Hardened Grade Managed 16-port 100/1000Base-SFP + 4-port 10GBase-SFP + 8-port 10/100/1000Base-SFP or 10/100/1000Base-TX Combo Optical Ethernet Switch. This switch is highly flexible and anti-EMI. -40°~ 75°C operating temperature rang and 8KV Ethernet surge protection can adapt to a harsh outdoor environment and ensure product reliability.
