Pulsar PS-604812 Quick Start Manual


power output 1,2A//48÷ 53V DC

universal AC input voltage range 85÷264V

high efficiency 81%

LED optical signalisation
1. Technical description.
1.1. General description.
The power supply unit is intended for the feeding of alarm system equipments, which require 48V DC supply voltage
and current load I=1,2A. The design enables simple changing of the output voltage, within the range of 48V÷53V DC, using a
potentiometer. The power supply unit is protected against short-circuit, overload and overvoltage.
1.2.Technical parameters.
Supply voltage
Current consumption
Supply power
Efficiency
Output voltage
Output current t
AMB
Output current t
AMB
Voltage adjustment range
Ripple voltage
Short-circuit protection SCP
Overload protection OLP
Surge protection
Overvoltage protection OVP
Optical signalisation
Operation conditions
Dimensions
Net/gross weight
Protection class PN-EN 60950-1:2007
Connectors
Electrical strength of insulation:
- between input (network) circuit and output circuits of
power-supply (I/PO/P)
- between input circuit and PE protection circuit (I/P-
FG)
- between output circuit and PE protection circuit
(O/P-FG)
Insulation resistance:
- between input circuit and output or protection circuit
Storage temperature
Vibrations and impulse waves during transport
* In order to extend the life of the power supply, the load current of 0,9A is recommended.
*
See graph 1.
PS 48V/1,2A enclosed switch mode power supply
Features of the power supply unit:
*
<30°C
=40°C
PS-604812
Edition: 2 from 01.03.2018
Supersedes edition: 1 from 06.12.2016

protections:

SCP short-circuit protection

overvoltage OVP

overvoltage protection

overload (OLP)

warranty – 2 year from the production date
85 ÷ 264V AC, 120 ÷ 370V DC
0,6A@230V AC max.
60W max.
81%
48V DC
1,2 A - see graph 1.
0,9 A - see graph 1.
48V ÷ 53V DC
150mV p-p max.
electronic, automatic recovery
105 ÷ 150% of power supply, automatic recovery
varistors
>60V (automatic return)
green LED – presence of DC voltage
2-nd enviromental class, temperature: -10
relative humidity 20%...90%, without condensation
L=159, W=97, H=38 [+/- 2mm]
0,48kg / 0,5kg
I (first) – requires a protective conductor (PE)
power-supply:Φ0,63-2,50 (AWG 22-10)
outputs: Φ0,63-2,50 (AWG 22-10)
3000 V/AC min.
1500 V/AC min.
500 V/AC min.
100 MΩ, 500V DC
-20ºC...+60ºC
according to PN-83/T-42106
1
EN
PL
o o
C ÷ +40
C
