PSBOC15512110
v.1.0
PSBOC 13,8V/11A/OC
Caged, switched mode, buffer power supply unit
EN
Edition: 2nd (19th July 2012)
Supersedes edition: 1st (10th Mar 2012)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSBOC15512110 and is the answer not in the manual?

Questions and answers

Related Manuals for Pulsar PSBOC15512110

Summary of Contents for Pulsar PSBOC15512110

  • Page 1 PSBOC15512110 v.1.0 PSBOC 13,8V/11A/OC Caged, switched mode, buffer power supply unit Edition: 2nd (19th July 2012) Supersedes edition: 1st (10th Mar 2012)

  • Page 2: Table Of Contents

    PSBOC15512110 Features: • • 13,8VDC/11A uninterrupted supply FAC technical output indicating AC power loss • • wide range of supply voltage 176÷264VAC FPS technical output indicating PSU failure • • high efficiency 83% FLB technical output indicating battery low •...

  • Page 3: Block Diagram

    PSBOC15512110 1.2 Block diagram. (fig.1). Fig.1. Block diagram of the PSU. 1.3 Description of PSU components and connectors. Table 1. Elements of the PSU (see fig. 2). Element no. Description LED indicating presence of AC power LED indicating presence of DC power LED indicating correct battery voltage FAC- AC absence technical output –...

  • Page 4: Specifications

    PSBOC15512110 Fig. 2. The view of the PSU. 1.4 Specifications: - electrical specifications (tab.2) - mechanical specifications (tab.3) - operation safety (tab.4) - operating specifications (tab.5) Electrical specifications (tab. 2). Mains supply 176 ÷ 264V AC Current consumption 1,4A@230VAC max.

  • Page 5: Installation

    PSBOC15512110 Temperature characteristics. Chart 1. Acceptable output current from the PSU depending on ambient temperature. Mechanical specifications (tab. 3). Enclosure dimensions 199x 110x 50 +23 [mm] (LxWxH) [mm] (+/- 2) Net/gross weight 0,76kg / 0,82kg power supply, technical outputs: Φ0,63÷2,5 I/O PCB : Φ0,41÷1,63...

  • Page 6: Installation Procedure

    PSBOC15512110 2.2. Installation procedure. 1. Before installation of the power supply unit, make sure that 230VAC power if cut off. 2. Mount the unit in the intended location. 3. Connect the 230VAC power cables. Connect the PE cable (yellow-green) to an appropriate PSU terminal (marked with - earth symbol).

  • Page 7: Operating Status Indication

    PSBOC15512110 3. Operating status indication. 3.1 LED indication The PSU is equipped with 3 LEDs on the PCB board: - red LED (Fig.2, element 1) normal status (AC power): permanently illuminated. AC power absence is indicated by the AC diode going out.
  • Page 8 WEEE separately. GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a two-year warranty for the equipment, starting from the initial product date of purchase placed on the receipt.
