PSUPS20A12CR
v.1.3
PSUPS 13,8V/12V/20A/2x17Ah
Buffer power supply for up to 16 HD cameras and DVR
with recorder space
EN
Edition: 7 from 17.02.2020
Supercedes the edition: 6 from 02.07.2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSUPS20A12CR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pulsar PSUPS20A12CR

Summary of Contents for Pulsar PSUPS20A12CR

  • Page 1 PSUPS20A12CR v.1.3 PSUPS 13,8V/12V/20A/2x17Ah Buffer power supply for up to 16 HD cameras and DVR with recorder space Edition: 7 from 17.02.2020 Supercedes the edition: 6 from 02.07.2018...

  • Page 2: Table Of Contents

    PSUPS20A12CR Features:  DC 13,8 V uninterruptible power supply of HD cameras  battery output protection against short circuit  DC 12 V uninterruptible power supply of the recorder and reverse polarity connection  LED indication  fitting battery 2x17Ah/12 V ...

  • Page 3: Technical Description

    PSUPS20A12CR 1. Technical description. 1.1. General description. A buffer PSU is intended for an uninterrupted supply to CCTV system devices requiring stabilized voltage of 12 V DC (+/-15%). The PSU has two circuits: first 1x5 A/12 V DC for supplying the recorder and 16x0,8 A/13,8 V DC for both cameras.
  • Page 4 PSUPS20A12CR 1.3. Description of PSU components. Table 1. Description of components and connectors module LB8 Component no. Description [Fig. 2] F1÷F8 glass fuses L1÷L8 LED voltage indication at the outputs AUX1 ÷ AUX8 independently protected outputs IN1-, IN2- power supply inputs of the fuse module Table 2.
  • Page 5 PSUPS20A12CR Fig.4. The view of the PSU.

  • Page 6: Specifications

    PSUPS20A12CR 1.4. Specifications: - electrical specifications (tab.4) - mechanical specifications (tab.5) - operation safety (tab.6) - operating specifications (tab.7) Table 4. Electrical specifications. PSU type A (EPS - External Power Source) Mains supply ~200-240 V; 50Hz Current consumption 1,5 A PSU’s power...
  • Page 7 PSUPS20A12CR Table 5. Mechanical specifications. Dimensions W=420, H=535, D+D =193+14 [+/- 2mm] =425, H =540 [+/- 2mm] The dimensions of the =380, H =320, D =65 [+/- 2mm] recorder compartment The dimensions of the 380 x 340 x 175 mm (WxHxD) max...

  • Page 8: Installation

    PSUPS20A12CR 2. Installation. 2.1 Requirements. The buffer PSU is to be mounted by a qualified installer, holding relevant permits and licenses (applicable and required for a given country) for 230 V interference and low-voltage installations. The unit should be mounted in confined spaces, in accordance with the 2nd environmental class, with normal relative humidity (RH=90% maximum, without condensation) and temperature from -10°C to +40°C.

  • Page 9: Operating Status Indication

    PSUPS20A12CR 3. Operating status indication. The PSU is equipped with two diodes on the front panel: RED LED:  on – The PSU supplied with 230 V voltage  off – no 230 V mains supply GREEN LED: ...
  • Page 10 CAUTION! The power supply unit is adapted for cooperation with the sealed lead-acid batteries (SLA). After the operation period they must not be thrown but recycled according to the applicable law Pulsar sp. j. Siedlec 150, 32-744 Łapczyca, Polska Tel. (+48) 14-610-19-40, Fax. (+48) 14-610-19-50 e-mail: biuro@pulsar.pl,...
