EM3396 V2
OEM Scan Engines
User Guide
Version: V1.0.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EM3396 V2 and is the answer not in the manual?

Questions and answers

Related Manuals for Newland EM3396 V2

Summary of Contents for Newland EM3396 V2

  • Page 1 EM3396 V2 OEM Scan Engines User Guide Version: V1.0.5...
  • Page 2 The products depicted in this manual may include software copyrighted by Reg. nr. 17109876 Newland Europe BV or a third party. The user, corporation or individual shall not duplicate, in whole or in part, distribute, modify, decompile, disassemble, decode, reverse engineer, rent, transfer, or sublicense such software without prior written consent from the copyright holders.

  • Page 3: Revision History

    Revision History Version Description Date V1.0.0 Initial release. November 4, 2016 1. Added the Specify Decoding Area (Top, Bottom, Left, Right) feature in Chapter 4. 2. Added Chapter 10 Batch Programming. 3. Changed the range of Decode Session Timeout to 100ms – 3,600,000ms.
  • Page 4 1. Added the Emulate Numeric Keypad 2 feature in Chapter 2. 2. Updated the “Auto Idle” section in Chapter 3. V1.0.5 November 19, 2018 Note: Firmware version V1.05.016 or later is required for the new features above.

  • Page 5: Table Of Contents

    Table Of Contents Revision History ............................... -3- Chapter 1 Getting Started ..........................1 Introduction .............................. 1 About This Guide ............................. 1 Connecting EVK to PC ..........................1 Barcode Scanning ........................... 2 Barcode Programming ..........................2 Factory Defaults ............................3 Custom Defaults ............................3 Inquire Product Information ........................
  • Page 6 Introduction ..........................17 Access the Engine with Your Program ................... 18 Acquire Scanned Data ......................18 Send Data to the Engine ......................18 VID/PID ............................ 19 Chapter 3 Scan Mode ............................20 Batch Mode ............................20 Trigger Mode ............................21 Decode Session Timeout .......................
  • Page 7 Startup Beep ............................35 Good Read Beep for Non-programming Barcode ................. 36 Beep Type............................36 Beep Volume ..........................37 Beep on Unknown Character ........................ 37 Good Read Beep for Programming Barcode ..................38 Good Read LED ............................ 38 Transmit NGR Message ........................39 Edit NGR Message .........................
  • Page 8 1D Symbologies ............................. 54 Code 128 ............................54 Restore Factory Defaults......................54 Enable/Disable Code 128......................54 Set Length Range for Code 128 ..................... 54 GS1-128 (UCC/EAN-128) ......................55 Restore Factory Defaults......................55 Enable/Disable GS1-128 ......................55 Set Length Range for GS1-128 ....................55 AIM-128 ............................
  • Page 9 Add-On Code ........................... 67 Add-On Code Required ......................67 ISBN ..............................68 Restore Factory Default ......................68 Enable/Disable ISBN ....................... 68 Set ISBN Format ........................68 Add-On Code ........................... 69 Add-On Code Required ......................69 UPC-E ............................. 70 Restore Factory Defaults......................70 Enable/Disable UPC-E ......................
  • Page 10 Restore Factory Defaults......................82 Enable/Disable Industrial 2 of 5 ....................82 Set Length Range for Industrial 2 of 5 ..................82 Check Digit Verification ......................83 Standard 2 of 5（IATA 2 of 5） ...................... 84 Restore Factory Defaults......................84 Enable/Disable Standard 25 ....................84 Set Length Range for Standard 25 ..................
  • Page 11 Code 11 ............................96 Restore Factory Defaults......................96 Enable/Disable Code 11......................96 Set Length Range for Code 11 ....................96 Transmit Check Digit ....................... 97 Check Digit Verification ......................97 Plessey ............................98 Restore Factory Defaults......................98 Enable/Disable Plessey ......................98 Set Length Range for Plessey ....................
  • Page 12 Data Matrix............................ 110 Restore Factory Defaults....................... 110 Enable/Disable Data Matrix ....................110 Set Length Range for Data Matrix ..................110 Rectangular Barcode ......................111 Mirror Image .......................... 111 Data Matrix Twin Code ......................112 Character Encoding ....................... 112 Enable/Disable Data Matrix ECI Output ................113 Chinese Sensible Code ........................
  • Page 13 b. Program the Idle Timeout ......................140 c. Program the Image Stabilization Timeout ................140 d. Program the Timeout between Decodes (Same Barcode) ............141 e. Program the Threshold Value of Illumination Change ............. 141 f. Program the Timeout between Decodes ................... 141 g.

  • Page 15: Chapter 1 Getting Started

    Chapter 1 Getting Started Introduction The NLS-EM3396 OEM scan engines (hereinafter referred to as “the EM3396” or “the engine”), armed with the Newland patented , a computerized image recognition system, bring about a new era of 2D barcode scan engines.

  • Page 16: Barcode Scanning

    Enter Setup Barcode Scanning Powered by area-imaging technology and Newland patented technology, the EM3396 features fast scanning and accurate decoding. Barcodes rotated at any angle can still be read with ease. When scanning a barcode, simply center the aiming beam or pattern projected by the EM3396 over the barcode.

  • Page 17: Factory Defaults

    Enter Setup Factory Defaults Scanning the following barcode can restore the engine to the factory defaults. See Appendix 1: Factory Defaults Table for more information. Note: Use this feature with discretion. Restore All Factory Defaults Custom Defaults Custom defaults make it possible to save the frequently-used settings on the engine. Scanning the Save as Custom Defaults barcode can save the current settings as custom defaults.

  • Page 18: Chapter 2 Communication Interfaces

    Enter Setup Chapter 2 Communication Interfaces The EM3396 provides a TTL-232 interface and a USB interface (optional) to communicate with the host device. The host device can receive scanned data and send commands to control the engine or to access/alter the configuration information of the engine via the interface. Power-Saving Mode By default, the engine adopts the Power-Saving Mode to conserve power.

  • Page 19: Ttl-232 Interface

    Enter Setup TTL-232 Interface Serial communication interface is usually used when connecting the engine to a host device (like PC, POS). However, to ensure smooth communication and accuracy of data, you need to set communication parameters (including baud rate, parity check, data bit and stop bit) to match the host device. The serial communication interface provided by the engine is based on TTL-level signals.

  • Page 20: Baud Rate

    Enter Setup Baud Rate Baud rate is the number of bits of data transmitted per second. Set the baud rate to match the Host requirements. ** 9600 1200 19200 2400 38400 4800 57600 14400 115200 ** Exit Setup...

  • Page 21: Parity Check

    Enter Setup Parity Check When the number of data bits is set to 7, you can only select either Even Parity or Odd Parity. The None option will be regarded as Even Parity in this case. ** None Even Parity Odd Parity Data Bit When the number of data bits is set to 7, you can only select either Even Parity or Odd Parity.

  • Page 22: Data Bit & Parity Check

    Enter Setup Data Bit & Parity Check 7 Data Bits/Even Parity 7 Data Bits/Odd Parity ** 8 Data Bits/ No Parity 8 Data Bits/Even Parity 8 Data Bits/Odd Parity Stop Bit ** 1 Stop Bit 2 Stop Bits ** Exit Setup...

  • Page 23: Usb Interface (Optional)

    Enter Setup USB Interface (Optional) USB Enumeration If the engine is connected to the Host via a USB connection, the engine will be enumerated using S/N or “00000000” after power-up. Enumeration using S/N enables the Host to distinguish even between engines of same model.

  • Page 24: Usb Country Keyboard Types

    Enter Setup USB Country Keyboard Types Keyboard layouts vary from country to country. The default setting is U.S. keyboard. ** U.S. Japan Denmark Finland France Turkey_F Italy Norway ** Exit Setup...
  • Page 25 Enter Setup Spain Turkey_Q Austria, Germany Belgium Russia Sweden Portugal ** Exit Setup...

  • Page 26: Beep On Unknown Character

    Enter Setup Beep on Unknown Character Due to the differences in keyboard layouts, some characters contained in barcode data may be unavailable on the selected keyboard. As a result, the engine fails to transmit the unknown characters. Scan the appropriate barcode below to enable or disable the emission of beep when an unknown character is detected.

  • Page 27: Convert Case

    Enter Setup Convert Case Scan the appropriate barcode below to convert barcode data to your desired case. ** No Case Conversion Invert Upper and Lower Case Characters Convert All to Upper Case Convert All to Lower Case Example: When the Convert All to Lower Case feature is enabled, barcode data “AbC” is transmitted as “abc”.

  • Page 28: Emulate Alt+Keypad

    Enter Setup Emulate ALT+Keypad This feature allows any ASCII character (0x00 - 0xFF) to be sent over the numeric keypad no matter which keyboard type is selected. Since sending a character involves multiple keystroke emulations, this method appears less efficient. The following options are available: ...

  • Page 29: Function Key Mapping

    Enter Setup Function Key Mapping When Function Key Mapping is enabled, function characters (0x00 - 0x1F) are sent as ASCII sequences over the keypad. For more information, see Appendix 8: ASCII Function Key Mapping Table. Enable Function Key Mapping ** Disable Function Key Mapping Example: Barcode data 0x16 Enable Function Key Mapping Ctrl+V...

  • Page 30: Emulate Numeric Keypad

    Enter Setup Emulate Numeric Keypad Do Not Emulate Numeric Keypad 1：Sending a number (0-9) is emulated as keystroke(s) on main keyboard. Emulate Numeric Keypad 1：Sending a number (0-9) is emulated as keystroke(s) on numeric keypad. 2：Sending “+”, “-”, “*” and “/” is emulated as keystroke(s) on main Do Not Emulate Numeric Keypad keyboard.

  • Page 31: Usb Com Port Emulation

    Enter Setup USB COM Port Emulation If you connect the engine to the Host via a USB connection, the USB COM Port Emulation feature allows the Host to receive data in the way as a serial port does. A driver is required for this feature. USB COM Port Emulation USB HID-POS Introduction...

  • Page 32: Access The Engine With Your Program

    Enter Setup Access the Engine with Your Program Use CreateFile to access the engine as a HID device and then use ReadFile to deliver the scanned data to the application program. Use WriteFile to send data to the engine. For detailed information about USB and HID interfaces, go to. Acquire Scanned Data After scanning and decoding a barcode, the engine sends the following input report: Byte...

  • Page 33: Vid/Pid

    Enter Setup VID/PID USB uses VID (Vendor ID) and PID (Product ID) to identify and locate a device. The VID is assigned by USB Implementers Forum. Newland’s vendor ID is 1EAB (Hex). A PID is assigned to each interface. Product Interface...

  • Page 34: Chapter 3 Scan Mode

    Enter Setup Chapter 3 Scan Mode Batch Mode If the Batch Mode is enabled, driving the TRIG pin on the host interface connector low activates a round of multiple decode sessions. This round of multiple scans continues until the active trigger signal is no longer present.

  • Page 35: Trigger Mode

    Enter Setup Trigger Mode If the Trigger Mode is enabled, driving the TRIG pin on the host interface connector low activates a decode session. The session continues until the barcode is decoded or decode session timeout expires or the active trigger signal is no longer present. For good read, the engine transmits decoded data via communication port.

  • Page 36: Level Trigger/Pulse Trigger

    Enter Setup Level Trigger/Pulse Trigger Level trigger: Decode session is activated and continued by constant active trigger signal. The decode session ends once the barcode is decoded or decode session timeout expires. Pulse trigger: Decode session is activated by electric pulse of trigger signal. The decode session continues until the barcode is decoded or decode session timeout expires.

  • Page 37: Timeout Between Decodes (Same Barcode)

    Enter Setup Timeout between Decodes (Same Barcode) Timeout between Decodes (Same Barcode) can avoid undesired rereading of same barcode in a given period of time. Disable Timeout between Decodes (Same Barcode): Allow the engine to re-read same barcode. Enable Timeout between Decodes (Same Barcode) & Reset Timeout Off: Do not allow the engine to re-read same barcode before the timeout between decodes (same barcode) expires.

  • Page 38: Sense Mode

    Enter Setup Sense Mode If the Sense Mode is enabled, the engine activates a decode session every time it detects a change in ambient illumination. The decode session continues until the barcode is decoded or the decode session timeout expires. Driving the TRIG pin on the host interface connector low can also activate a decode session.

  • Page 39: Image Stabilization Timeout

    Enter Setup Image Stabilization Timeout This parameter defines the amount of time that the engine waits for the image to stabilize to a point that it can be decoded with more accuracy. It is programmable in 1ms increments from 0ms to 1,600ms. The default setting is 500ms.To learn how to program this parameter, see Appendix 5.

  • Page 40: Timeout Between Decodes (Same Barcode)

    Enter Setup Timeout between Decodes (Same Barcode) Timeout between Decodes (Same Barcode) can avoid undesired rereading of same barcode in a given period of time. Disable Timeout between Decodes (Same Barcode): Allow the engine to re-read same barcode. Enable Timeout between Decodes (Same Barcode) & Reset Timeout Off: Do not allow the engine to re-read same barcode before the timeout between decodes (same barcode) expires.

  • Page 41: Sensitivity

    Enter Setup Sensitivity Sensitivity specifies the degree of acuteness of the engine’s response to changes in ambient illumination. The higher the sensitivity, the lower requirement in illumination change to trigger the engine. You can select an appropriate degree of sensitivity that fits the ambient environment. Medium Sensitivity Low Sensitivity High Sensitivity...

  • Page 42: Continuous Mode

    Enter Setup Continuous Mode This mode enables the engine to scan/capture, decode and transmit over and over again. When the engine is operating in Continuous Mode, barcode reading can be suspended/resumed through control over the trigger signal. When barcode reading is in progress, negating the trigger signal after having maintained it for 30ms or longer will suspend barcode reading;...

  • Page 43: Timeout Between Decodes (Same Barcode)

    Enter Setup Timeout between Decodes (Same Barcode) Timeout between Decodes (Same Barcode) can avoid undesired rereading of same barcode in a given period of time. Disable Timeout between Decodes (Same Barcode): Allow the engine to re-read same barcode. Enable Timeout between Decodes (Same Barcode) & Reset Timeout Off: Do not allow the engine to re-read same barcode before the timeout between decodes (same barcode) expires.

  • Page 44: Chapter 4 Scanning Preferences

    Enter Setup Chapter 4 Scanning Preferences Introduction This chapter contains information as to how to adapt your engine to various applications with preference setting. For instance, to narrow the field of view of the engine to make sure it reads only those barcodes intended by the user.

  • Page 45: Specify Decoding Area

    Enter Setup Specify Decoding Area If Specific Area Decoding is enabled, the engine only reads barcodes that intersect the predefined decoding area. The default decoding area is an area of 40% top, 60% bottom, 40% left and 60% right of the engine’s field of view, as shown in the figure below.
  • Page 46 Enter Setup Top of Decoding Area Bottom of Decoding Area Left of Decoding Area Right of Decoding Area ** Exit Setup...

  • Page 47: Chapter 5 Illumination & Aiming

    Enter Setup Chapter 5 Illumination & Aiming Illumination A couple of illumination options are provided to improve the lighting conditions during every image capture: Normal: Illumination LEDs are turned on during image capture. Always ON: Illumination LEDs keep ON after the engine is powered on. OFF: Illumination LEDs are OFF all the time.

  • Page 48: Aiming

    Enter Setup Aiming When scanning/capturing image, the engine projects an aiming pattern which allows positioning the target barcode within its field of view and thus makes decoding easier. Normal: The engine projects an aiming pattern only during barcode scanning/capture. Always ON: Aiming pattern is constantly ON after the engine is powered on. OFF: Aiming pattern is OFF all the time.

  • Page 49: Chapter 6 Beep & Led Notifications

    Enter Setup Chapter 6 Beep & LED Notifications Startup Beep If startup beep is enabled, the engine will beep after being turned on. ** Enable Startup Beep Disable Startup Beep ** Exit Setup...

  • Page 50: Good Read Beep For Non-Programming Barcode

    Enter Setup Good Read Beep for Non-programming Barcode The engine can provide a PWM output to an external driver circuit to drive a beeper after decoding a non-programming barcode. Scan the appropriate barcode below to enable or disable the emission of good read beep.

  • Page 51: Beep Volume

    Enter Setup Beep Volume ** Loud Medium Beep on Unknown Character Due to the differences in keyboard layouts, some characters contained in barcode data may be unavailable on the selected keyboard (USB HID-KBW). As a result, the engine fails to transmit the unknown characters.

  • Page 52: Good Read Beep For Programming Barcode

    Enter Setup Good Read Beep for Programming Barcode ** Good Read Beep On for Programming Barcode Good Read Beep Off for Programming Barcode Good Read LED ** Good Read LED ON Good Read LED OFF ** Exit Setup...

  • Page 53: Transmit Ngr Message

    Enter Setup Transmit NGR Message Scan a barcode below to select whether or not to transmit a user-defined NGR (Not Good Read) message when a barcode is not decoded. Transmit NGR Message ** Do Not Transmit NGR Message Edit NGR Message To edit an NGR message, scan the Edit NGR Message barcode and the numeric barcodes corresponding to the ASCII values (hex) of desired characters and then scan the Save barcode.

  • Page 54: Chapter 7 Prefix & Suffix

    Enter Setup Chapter 7 Prefix & Suffix In many applications, barcode data needs to be edited and distinguished from one another. Usually AIM ID and Code ID can be used as identifiers, but in some special cases customized prefix and terminating character suffix like Carriage Return or Line Feed can also be the alternatives.

  • Page 55: Global Settings

    Enter Setup Global Settings Enable/Disable All Prefixes/Suffixes Disable All Prefixes/Suffixes: Transmit barcode data with no prefix/suffix. Enable All Prefixes/Suffixes: Allow user to append Code ID prefix, AIM ID prefix, custom prefix/suffix and terminating character to the barcode data before the transmission. Enable All Prefixes/Suffixes Disable All Prefixes/Suffixes Prefix Sequences...

  • Page 56: Custom Prefix

    Enter Setup Custom Prefix Enable/Disable Custom Prefix If custom prefix is enabled, you are allowed to append to the data a user-defined prefix that cannot exceed 11 characters. Enable Custom Prefix ** Disable Custom Prefix Set Custom Prefix To set a custom prefix, scan the Set Custom Prefix barcode and the numeric barcodes representing the hexadecimal values of a desired prefix and then scan the Save barcode.

  • Page 57: Aim Id Prefix

    Enter Setup AIM ID Prefix AIM (Automatic Identification Manufacturers) IDs and ISO/IEC 15424 standards define symbology identifiers and data carrier identifiers. (For the details, see the “Appendix 2: AIM ID Table” section). If AIM ID prefix is enabled, the engine will add the symbology identifier before the scanned data after decoding.

  • Page 58: Modify Code Id

    Enter Setup Modify Code ID Code ID of each symbology can be programmed separately. See the following example to learn how to program a Code ID. Example: Set the Code ID of PDF417 to “p” Check the hex value of “p” in the ASCII Table. (“p”: 70) Scan the Enter Setup barcode.
  • Page 59 Enter Setup Modify AIM-128 Code ID Modify EAN-8 Code ID Modify EAN-13 Code ID Modify UPC-E Code ID Modify UPC-A Code ID Modify ISBN Code ID Modify ISSN Code ID Modify Code 39 Code ID Modify Code 93 Code ID Modify Interleaved 2 of 5 Code ID ** Exit Setup...
  • Page 60 Enter Setup Modify ITF-14 Code ID Modify ITF-6 Code ID Modify Codabar Code ID Modify Industrial 25 Code ID Modify Standard 25 Code ID Modify Matrix 25 Code ID Modify Code 11 Code ID Modify Plessey Code ID Modify MSI/Plessey Code ID Modify GS1 Databar Code ID ** Exit Setup...

  • Page 61: Custom Suffix

    Enter Setup Custom Suffix Enable/Disable Custom Suffix If custom suffix is enabled, you are allowed to append to the data a user-defined suffix that cannot exceed 11 characters. Enable Custom Suffix Disable Custom Suffix Set Custom Suffix To set a custom suffix, scan the Set Custom Suffix barcode and the numeric barcodes representing the hexadecimal values of a desired suffix and then scan the Save barcode.

  • Page 62: Terminating Character Suffix

    Enter Setup Terminating Character Suffix A terminating character can be used to mark the end of data, which means nothing can be added after it. A terminating character suffix cannot exceed 7 characters. Enable/Disable Terminating Character Suffix To enable/disable terminating character suffix, scan the appropriate barcode below. Enable Terminating Character Suffix Disable Terminating Character Suffix ** Exit Setup...

  • Page 63: Set Terminating Character Suffix

    Enter Setup Set Terminating Character Suffix The engine provides a shortcut for setting the terminating character suffix to CR (0x0D) or CRLF (0x0D,0x0A) and enabling it by scanning the appropriate barcode below. Terminating Character CR (0x0D) Terminating Character CRLF (0x0D,0x0A) To set a terminating character suffix, scan the Set Terminating Character Suffix barcode and the numeric barcodes representing the hexadecimal value of a desired terminating character and then scan the Save barcode.

  • Page 64: Data Packing

    Enter Setup Data Packing Introduction Data packing is designed for a specific group of users who want to have the data packed before transmission. Data packing influences data format, so it is advised to disable this feature when it is not required.
  • Page 65 Enter Setup ** Disable Data Packing Enable Data Packing, Format 1 Enable Data Packing, Format 2 ** Exit Setup...

  • Page 66: Chapter 8 Symbologies

    Enter Setup Chapter 8 Symbologies Global Settings Enable/Disable All Symbologies If the Disable All Symbologies feature is enabled, the engine will not be able to read any non-programming barcodes except the programming barcodes. Enable All Symbologies Disable All Symbologies Enable/Disable 1D Symbologies If the Disable 1D Symbologies feature is enabled, the engine will not be able to read any 1D barcodes.

  • Page 67: Video Reverse

    Enter Setup Video Reverse The Video Reverse feature only applies to 2D barcodes. Regular barcode: Dark image on a bright background. Inverse barcode: Bright image on a dark background. The examples of regular barcode and inverse barcode are shown below. Regular Barcode Inverse Barcode Video Reverse is used to allow the engine to read barcodes that are inverted.

  • Page 68: 1D Symbologies

    Enter Setup 1D Symbologies Code 128 Restore Factory Defaults Restore the Factory Defaults of Code 128 Enable/Disable Code 128 Enable Code 128 Disable Code 128 Set Length Range for Code 128 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 69: Gs1-128 (Ucc/Ean-128)

    Enter Setup GS1-128 (UCC/EAN-128) Restore Factory Defaults Restore the Factory Defaults of GS1-128 Enable/Disable GS1-128 Enable GS1-128 Disable GS1-128 Set Length Range for GS1-128 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 70: Restore Factory Defaults

    Enter Setup AIM-128 Restore Factory Defaults Restore the Factory Defaults of AIM-128 Enable/Disable AIM-128 ** Enable AIM-128 Disable AIM-128 Set Length Range for AIM-128 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 71: Restore Factory Defaults

    Enter Setup EAN-8 Restore Factory Defaults Restore the Factory Defaults of EAN-8 Enable/Disable EAN-8 ** Enable EAN-8 Disable EAN-8 ** Exit Setup...

  • Page 72: Transmit Check Digit

    Enter Setup Transmit Check Digit EAN-8 is 8 digits in length with the last one as its check digit used to verify the integrity of the data. Transmit EAN-8 Check Digit Do Not Transmit EAN-8 Check Digit Add-On Code An EAN-8 barcode can be augmented with a two-digit or five-digit add-on code to form a new one. In the examples below, the part surrounded by blue dotted line is an EAN-8 barcode while the part circled by red dotted line is add-on code.

  • Page 73: Ean-8 Add-On Code Required

    Enter Setup Add-On Code Required When EAN-8 Add-On Code Required is selected, the engine will only read EAN-8 barcodes that contain add-on codes. EAN-8 Add-On Code Required ** EAN-8 Add-On Code Not Required EAN-8 Extension Disable EAN-8 Zero Extend: Transmit EAN-8 barcodes as is. Enable EAN-8 Zero Extend: Add five leading zeros to decoded EAN-8 barcodes to extend to13 digits.

  • Page 74: Restore Factory Defaults

    Enter Setup EAN-13 Restore Factory Defaults Restore the Factory Defaults of EAN-13 Enable/Disable EAN-13 ** Enable EAN-13 Disable EAN-13 Transmit Check Digit Transmit EAN-13 Check Digit Do Not Transmit EAN-13 Check Digit ** Exit Setup...

  • Page 75: Add-On Code

    Enter Setup Add-On Code An EAN-13 barcode can be augmented with a two-digit or five-digit add-on code to form a new one. Enable 2-Digit Add-On Code Disable 2-Digit Add-On Code Enable 5-Digit Add-On Code Disable 5-Digit Add-On Code Enable 2-Digit Add-On Code/ Enable 5-Digit Add-On Code: The engine decodes a mix of EAN-13 barcodes with and without 2-digit/5-digit add-on codes.

  • Page 76: Ean-13 Beginning With 290 Add-On Code Required

    Enter Setup EAN-13 Beginning with 290 Add-On Code Required This setting programs the engine to require an add-on code (2-digit or 5-digit) on EAN-13 barcodes that begin with “290”. The following settings can be programmed: Require Add-On Code: All EAN-13 barcodes that begin with “290” must have a 2-digit or 5-digit add-on code.

  • Page 77: Ean-13 Beginning With 414/419 Add-On Code Required

    Enter Setup EAN-13 Beginning with 414/419 Add-On Code Required This setting programs the engine to require an add-on code (2-digit or 5-digit) on EAN-13 barcodes that begin with a “414” or “419”. The following settings can be programmed: Require Add-On Code: All EAN-13 barcodes that begin with a “414” or “419” must have a 2-digit or 5-digit add-on code.

  • Page 78: Ean-13 Beginning With 977 Add-On Code Required

    Enter Setup EAN-13 Beginning with 977 Add-On Code Required This setting programs the engine to require an add-on code (2-digit or 5-digit) on EAN-13 barcodes that begin with “977”. The following settings can be programmed: Require Add-On Code: All EAN-13 barcodes that begin with “977” must have a 2-digit or 5-digit add-on code.

  • Page 79: Ean-13 Beginning With 979 Add-On Code Required

    Enter Setup EAN-13 Beginning with 979 Add-On Code Required This setting programs the engine to require an add-on code (2-digit or 5-digit) on EAN-13 barcodes that begin with “979”. The following settings can be programmed: Require Add-On Code: All EAN-13 barcodes that begin with “979” must have a 2-digit or 5-digit add-on code.

  • Page 80: Issn

    Enter Setup ISSN Restore Factory Defaults Restore the Factory Defaults of ISSN Enable/Disable ISSN Enable ISSN ** Disable ISSN ** Exit Setup...

  • Page 81: Add-On Code

    Enter Setup Add-On Code An ISSN barcode can be augmented with a two-digit or five-digit add-on code to form a new one. Enable 2-Digit Add-On Code Disable 2-Digit Add-On Code Enable 5-Digit Add-On Code Disable 5-Digit Add-On Code Enable 2-Digit Add-On Code/ Enable 5-Digit Add-On Code: The engine decodes a mix of ISSN barcodes with and without 2-digit/5-digit add-on codes.

  • Page 82: Isbn

    Enter Setup ISBN Restore Factory Default Restore the Factory Defaults of ISBN Enable/Disable ISBN ** Enable ISBN Disable ISBN Set ISBN Format ** ISBN-13 ISBN-10 ** Exit Setup...

  • Page 83: Add-On Code

    Enter Setup Add-On Code An ISBN barcode can be augmented with a two-digit or five-digit add-on code to form a new one. Enable 2-Digit Add-On Code Disable 2-Digit Add-On Code Enable 5-Digit Add-On Code Disable 5-Digit Add-On Code Enable 2-Digit Add-On Code/ Enable 5-Digit Add-On Code: The engine decodes a mix of ISBN barcodes with and without 2-digit/5-digit add-on codes.

  • Page 84: Upc-E

    Enter Setup UPC-E Restore Factory Defaults Restore the Factory Defaults of UPC-E Enable/Disable UPC-E Enable UPC-E Disable UPC-E Transmit Check Digit Transmit UPC-E Check Digit Do Not Transmit UPC-E Check Digit ** Exit Setup...

  • Page 85: Add-On Code

    Enter Setup Add-On Code A UPC-E barcode can be augmented with a two-digit or five-digit add-on code to form a new one. Enable 2-Digit Add-On Code Disable 2-Digit Add-On Code Enable 5-Digit Add-On Code Disable 5-Digit Add-On Code Enable 2-Digit Add-On Code/ Enable 5-Digit Add-On Code: The engine decodes a mix of UPC-E barcodes with and without 2-digit/5-digit add-on codes.

  • Page 86: Transmit System Character "0

    Enter Setup Transmit System Character “0” The first character of UPC-E barcode is the system character “0”. Transmit System Character “0” Do Not Transmit System Character “0” UPC-E Extension Disable UPC-E Extend: Transmit UPC-E barcodes as is. Enable UPC-E Extend: Extend UPC-E barcodes to make them compatible in length to UPC-A. Enable UPC-E Extend Disable UPC-E Extend ** Exit Setup...

  • Page 87: Upc-A

    Enter Setup UPC-A Restore Factory Defaults Restore the Factory Defaults of UPC-A Enable/Disable UPC-A Enable UPC-A Disable UPC-A Transmit Check Digit Transmit UPC-A Check Digit Do Not Transmit UPC-A Check Digit ** Exit Setup...

  • Page 88: Add-On Code

    Enter Setup Add-On Code A UPC-A barcode can be augmented with a two-digit or five-digit add-on code to form a new one. Enable 2-Digit Add-On Code Disable 2-Digit Add-On Code Enable 5-Digit Add-On Code Disable 5-Digit Add-On Code Enable 2-Digit Add-On Code/ Enable 5-Digit Add-On Code: The engine decodes a mix of UPC-A barcodes with and without 2-digit/5-digit add-on codes.

  • Page 89: Transmit Preamble Character

    Enter Setup Transmit Preamble Character Preamble characters (Country Code and System Character) can be transmitted as part of a UPC-A barcode. Select one of the following options for transmitting UPC-A preamble to the host device: transmit system character only, or transmit system character and country code (“0” for USA), or transmit no preamble.

  • Page 90: Interleaved 2 Of 5

    Enter Setup Interleaved 2 of 5 Restore Factory Defaults Restore the Factory Defaults of Interleaved 2 of 5 Enable/Disable Interleaved 2 of 5 ** Enable Interleaved 2 of 5 Disable Interleaved 2 of 5 Set Length Range for Interleaved 2 of 5 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 91: Check Digit Verification

    Enter Setup Check Digit Verification A check digit is optional for Interleaved 2 of 5 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. Disable: The engine transmits Interleaved 2 of 5 barcodes as is. Do Not Transmit Check Digit After Verification: The engine checks the integrity of all Interleaved 2 of 5 barcodes to verify that the data complies with the check digit algorithm.
  • Page 92 Enter Setup ITF-14 ITF-14 is a special kind of Interleaved 2 of 5 with a length of 14 characters and the last character as the check character. Restore the Factory Defaults of ITF-14 Disable ITF-14 Enable ITF-14 But Do Not Transmit Check Digit Enable ITF-14 and Transmit Check Digit Note: It is advisable not to enable ITF-14 and Interleaved 2 of 5 at the same time.
  • Page 93 Enter Setup ITF-6 ITF-6 is a special kind of Interleaved 2 of 5 with a length of 6 characters and the last character as the check character. Restore the Factory Defaults of ITF-6 ** Disable ITF-6 Enable ITF-6 But Do Not Transmit Check Digit Enable ITF-6 and Transmit Check Digit Note: It is advisable not to enable ITF-6 and Interleaved 2 of 5 at the same time.

  • Page 94: Matrix 2 Of 5

    Enter Setup Matrix 2 of 5 Restore Factory Defaults Restore the Factory Defaults of Matrix 2 of 5 Enable/Disable Matrix 2 of 5 Enable Matrix 2 of 5 ** Disable Matrix 2 of 5 Set Length Range for Matrix 2 of 5 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 95: Check Digit Verification

    Enter Setup Check Digit Verification Disable Do Not Transmit Check Digit After Verification Transmit Check Digit After Verification ** Exit Setup...

  • Page 96: Industrial 2 Of 5

    Enter Setup Industrial 2 of 5 Restore Factory Defaults Restore the Factory Defaults of Industrial 2 of 5 Enable/Disable Industrial 2 of 5 Enable Industrial 2 of 5 Disable Industrial 2 of 5 Set Length Range for Industrial 2 of 5 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 97: Check Digit Verification

    Enter Setup Check Digit Verification Disable Transmit Check Digit After Verification Do Not Transmit Check Digit After Verification ** Exit Setup...

  • Page 98: Standard 2 Of 5（Iata 2 Of 5

    Enter Setup Standard 2 of 5（IATA 2 of 5） Restore Factory Defaults Restore the Factory Defaults of Standard 25 Enable/Disable Standard 25 Enable Standard 25 Disable Standard 25 Set Length Range for Standard 25 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 99: Check Digit Verification

    Enter Setup Check Digit Verification Disable Transmit Check Digit After Verification Do Not Transmit Check Digit After Verification ** Exit Setup...

  • Page 100: Code 39

    Enter Setup Code 39 Restore Factory Defaults Restore the Factory Defaults of Code 39 Enable/Disable Code 39 ** Enable Code 39 Disable Code 39 Transmit Start/Stop Character Transmit Start/Stop Character Do Not Transmit Start/Stop Character ** Exit Setup...

  • Page 101: Set Length Range For Code 39

    Enter Setup Set Length Range for Code 39 Set the Minimum Length Set the Maximum Length Check Digit Verification Disable Transmit Check Digit After Verification Do Not Transmit Check Digit After Verification Enable/Disable Code 39 Full ASCII The engine can be configured to identify all ASCII characters by scanning the appropriate barcode below. ** Enable Code 39 Full ASCII Disable Code 39 Full ASCII ** Exit Setup...

  • Page 102: Enable/Disable Code 32

    Enter Setup Enable/Disable Code 32 Code 32 is a variant of Code 39 used by the Italian pharmaceutical industry. Scan the appropriate bar code below to enable or disable Code 32. Code 39 must be enabled and Code 39 check digit verification must be disabled for this parameter to function.

  • Page 103: Transmit Code 32 Check Digit

    Enter Setup Transmit Code 32 Check Digit Code 32 must be enabled for this parameter to function. ** Do Not Transmit Code 32 Check Digit Transmit Code 32 Check Digit Transmit Code 32 Start/Stop Character Code 32 must be enabled for this parameter to function. ** Do Not Transmit Code 32 Start/Stop Character Transmit Code 32 Start/Stop Character ** Exit Setup...

  • Page 104: Codabar

    Enter Setup Codabar Restore Factory Defaults Restore the Factory Defaults of Codabar Enable/Disable Codabar ** Enable Codabar Disable Codabar Set Length Range for Codabar Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 105: Check Digit Verification

    Enter Setup Check Digit Verification Disable Transmit Check Digit After Verification Do Not Transmit Check Digit After Verification Transmit Start/Stop Character Transmit Start/Stop Character Do not Transmit Start/Stop Character ** Exit Setup...

  • Page 106: Start/Stop Character Format

    Enter Setup Start/Stop Character Format You can choose your desired start/stop character format by scanning the appropriate barcode below. ** ABCD/ABCD as the Start/Stop Character ABCD/TN*E as the Start/Stop Character Start/Stop Character in Uppercase Start/Stop Character in Lowercase ** Exit Setup...

  • Page 107: Code 93

    Enter Setup Code 93 Restore Factory Defaults Restore the Factory Defaults of Code 93 Enable/Disable Code 93 ** Enable Code 93 Disable Code 93 Set Length Range for Code 93 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 108: Check Digit Verification

    Enter Setup Check Digit Verification Disable Do Not Transmit Check Digit After Verification Transmit Check Digit After Verification ** Exit Setup...

  • Page 109: Gs1-Databar (Rss)

    Enter Setup GS1-Databar (RSS) Restore Factory Defaults Restore the Factory Defaults of GS1-Databar Enable/Disable GS1 Databar ** Enable GS1-DataBar Disable GS1-DataBar Transmit Application Identifier “01” Transmit Application Identifier “01” Do Not Transmit Application Identifier “01” ** Exit Setup...

  • Page 110: Code 11

    Enter Setup Code 11 Restore Factory Defaults Restore the Factory Defaults of Code 11 Enable/Disable Code 11 ** Enable Code 11 Disable Code 11 Set Length Range for Code 11 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 111: Transmit Check Digit

    Enter Setup Transmit Check Digit Transmit Check Digit ** Do Not Transmit Check Digit Check Digit Verification Disable One Check Digit, MOD11 Two Check Digits, MOD11/MOD11 Two Check Digits, MOD11/MOD9 One Check Digit, MOD11 (Len<=10) One Check Digit, MOD11 (Len<=10) Two Check Digits, MOD11/MOD11 (Len>10) Two Check Digits, MOD11/MOD9 (Len>10)

  • Page 112: Plessey

    Enter Setup Plessey Restore Factory Defaults Restore the Factory Defaults of Plessey Enable/Disable Plessey ** Enable Plessey Disable Plessey Set Length Range for Plessey Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 113: Check Digit Verification

    Enter Setup Check Digit Verification Disable Do Not Transmit Check Digit After Verification Transmit Check Digit After Verification ** Exit Setup...

  • Page 114: Msi-Plessey

    Enter Setup MSI-Plessey Restore Factory Defaults Restore the Factory Defaults of MSI-Plessey Enable/Disable MSI-Plessey ** Enable MSI-Plessey Disable MSI-Plessey Set Length Range for MSI-Plessey Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 115: Transmit Check Digit

    Enter Setup Transmit Check Digit Transmit Check Digit Do Not Transmit Check Digit Check Digit Verification Disable One Check Digit, MOD10 Two Check Digits, MOD10/MOD10 Two Check Digits, MOD10/MOD11 ** Exit Setup...

  • Page 116: Jan

    Enter Setup JAN Code for Magazines Japanese Article Number (JAN) is a barcode standard compatible with the EAN. JAN barcodes for magazines are EAN-13 barcodes starting with a “491” and containing a 5-digit add-on code. Scan the appropriate barcode below to enable or disable JAN barcodes for magazines. Enable JAN Code for Magazines ** Disable JAN Code for Magazines ** Exit Setup...

  • Page 117: Jan Code For Books

    Enter Setup JAN Code for Books JAN barcodes for books include an ISBN barcode starting with a “978” and an EAN-13 barcodes starting with a “191” or “192”. When left on the default setting (Disable JAN Code for Books), the engine treats the ISBN and EAN-13 barcodes as single barcodes.

  • Page 118: 2D Symbologies

    Enter Setup 2D Symbologies PDF 417 Restore Factory Defaults Restore the Factory Defaults of PDF 417 Enable/Disable PDF 417 ** Enable PDF 417 Disable PDF 417 Set Length Range for PDF 417 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 119: Pdf 417 Twin Code

    Enter Setup PDF 417 Twin Code PDF417 twin code is 2 PDF417 barcodes paralleled vertically or horizontally. They must both be either regular or inverse barcodes. They must have similar specifications and be placed closely together. There are 3 options for reading PDF417 twin codes: Single PDF417 Only: Read either PDF417 code.

  • Page 120: Enable/Disable Pdf417 Eci Output

    Enter Setup Enable/Disable PDF417 ECI Output Disable PDF417 ECI Output Enable PDF417 ECI Output ** Exit Setup...

  • Page 121: Qr Code

    Enter Setup QR Code Restore Factory Defaults Restore the Factory Defaults of QR Code Enable/Disable QR Code ** Enable QR Code Disable QR Code Set Length Range for QR Code Set the Minimum Length Set the Maximum Length Micro QR Enable Micro QR ** Disable Micro QR ** Exit Setup...

  • Page 122: Qr Twin Code

    Enter Setup QR Twin Code QR twin code is 2 QR barcodes paralleled vertically or horizontally. They must both be either regular or inverse barcodes. They must have similar specifications and be placed closely together. There are 3 options for reading QR twin codes: Single QR Only: Read either QR code.

  • Page 123: Enable/Disable Qr Eci Output

    Enter Setup Enable/Disable QR ECI Output Disable QR ECI Output Enable QR ECI Output ** Exit Setup...

  • Page 124: Data Matrix

    Enter Setup Data Matrix Restore Factory Defaults Restore the Factory Defaults of Data Matrix Enable/Disable Data Matrix ** Enable Data Matrix Disable Data Matrix Set Length Range for Data Matrix Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 125: Rectangular Barcode

    Enter Setup Rectangular Barcode ** Enable Rectangular Barcode Disable Rectangular Barcode Mirror Image ** Decode Mirror Images Do Not Decode Mirror Images ** Exit Setup...

  • Page 126: Data Matrix Twin Code

    Enter Setup Data Matrix Twin Code Data Matrix twin code is 2 Data Matrix barcodes paralleled vertically or horizontally. They must both be either regular or inverse barcodes. They must have similar specifications and be placed closely together. There are 3 options for reading Data Matrix twin codes: Single Data Matrix Only: Read either Data Matrix code.

  • Page 127: Enable/Disable Data Matrix Eci Output

    Enter Setup Enable/Disable Data Matrix ECI Output Disable Data Matrix ECI Output Enable Data Matrix ECI Output ** Exit Setup...

  • Page 128: Chinese Sensible Code

    Enter Setup Chinese Sensible Code Restore Factory Defaults Restore the Factory Defaults of Chinese Sensible Code Enable/Disable Chinese Sensible Code Enable Chinese Sensible Code ** Disable Chinese Sensible Code Set Length Range for Chinese Sensible Code Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 129: Enable/Disable Chinese Sensible Code Eci Output

    Enter Setup Enable/Disable Chinese Sensible Code ECI Output Disable Chinese Sensible Code ECI Output Enable Chinese Sensible Code ECI Output ** Exit Setup...

  • Page 130: Chapter 9 Image Control

    Enter Setup Chapter 9 Image Control Image Flipping The user may get reversed images when the engine is installed in non-standard ways. When it happens, image flipping can be used to right the “wrong”. The following figures illustrate standard image and three flipped images. ...

  • Page 131: Flip

    Enter Setup Flip ** Do Not Flip Flip Vertically Flip Horizontally Flip Horizontally and Vertically Flip Vertically Flip Vertically Do Not Flip Vertically Flip Horizontally Flip Horizontally Do Not Flip Horizontally ** Exit Setup...

  • Page 132: Chapter 10 Batch Programming

    Enter Setup Chapter 10 Batch Programming Introduction Batch programming enables users to integrate a batch of commands into a single batch barcode. Listed below are batch programming rules: 1. Command format: Command + “=” + Parameter Value. 2. Each command is terminated by a semicolon (;). Note that there is no space between a command and its terminator semicolon.

  • Page 133: Create A Batch Command

    Enter Setup Create a Batch Command A batch command may contain a number of individual commands each of which is terminated by a semicolon (;). Command Structure: Command (+ “=” + Parameter Value) 4 command syntaxes are described as below: 1.

  • Page 134: Create A Batch Barcode

    Enter Setup Create a Batch Barcode Batch barcodes can be produced in the format of PDF417, QR Code or Data Matrix. Example: Create a batch barcode for Illumination Always On, Sense Mode, Decode Session Timeout = 2s: 1. Input the following commands: 0200010;0302010;0313000=2000;...

  • Page 135: Use Batch Barcode

    Enter Setup Use Batch Barcode To put a batch barcode into use, scan the following barcodes. (Use the example above.) Enter Setup Enable Batch Barcode Batch Barcode Exit Setup ** Exit Setup...

  • Page 136: Chapter 11 Troubleshooting

    Chapter 11 Troubleshooting Problem: Barcodes cannot be read. Solution: 1. Find out the barcode type and verify that the barcode type is enabled. If the barcode parameters include check digit verification, select the Disable option. 2. If you do not know the barcode type, enable all symbologies. 3.
  • Page 137 Problem: Illumination and aiming beams are OFF. Solution: 1. Verify that the engine is properly powered up. 2. Send “?” to the engine. If the engine returns a reply of “!”, then send programming commands to turn on illumination and aimer. Problem: Carriage Return/Line Feed settings.

  • Page 138: Appendix

    Appendix Appendix 1: Factory Defaults Table Parameter Factory Default Remark Programming Barcode Disabled Barcode Programming Do not send Programming Barcode Data Communication Settings Power-Saving Mode Normal Mode: TTL-232 & USB Enabled (Only TTL-232 supported) supported 9600 Baud Rate None Parity Check TTL-232 Data Bit Stop Bit...
  • Page 139 Parameter Factory Default Remark Applicable to Trigger mode, Sense 3,000ms mode, Continuous mode. Decode Session Timeout 100~3,600,000ms; 0: Infinite. 500ms 0~1,600ms Image Stabilization Timeout Applicable to Sense mode and 1000ms Continuous mode. Timeout between Decodes Sense Mode 0~65,535ms Pause after good read Operation after Good Read Disabled Timeout between Decodes...
  • Page 140 Do not transmit NGR (Not Good Read) Message None...
  • Page 141 Parameter Factory Default Remark Prefix & Suffix Prefix Sequence Custom Prefix+Code ID+AIM ID Disabled Custom Prefix None AIM ID Prefix Disabled Code ID Prefix Disabled Disabled Custom Suffix None Enabled Terminating Character Suffix 0x0D Carriage Return Data Packing Disable Data Packing Image Control Image Flipping Do not flip...
  • Page 142 Parameter Factory Default Remark Symbologies Video Reverse Disabled Applicable to all symbologies. Code 128 Enabled Code 128 Maximum Length Minimum Length （ ） GS1-128 UCC/EAN-128 Enabled GS1-128 Maximum Length Minimum Length AIM-128 Enabled AIM-128 Maximum Length Minimum Length EAN-8 Enabled EAN-8 Transmit Check Digit...
  • Page 143 Parameter Factory Default Remark ISSN Disabled ISSN Disabled 2-Digit Add-On Code Disabled 5-Digit Add-On Code Not required Add-On Code ISBN ISBN Enabled ISBN-13 ISBN Format Disabled 2-Digit Add-On Code Disabled 5-Digit Add-On Code Not required Add-On Code UPC-E Enabled UPC-E Transmit Check Digit Disabled...
  • Page 144 Parameter Factory Default Remark ITF-14 Enabled ITF-14 Do not transmit Check Digit 出 Matrix 2 of 5 Disabled Matrix 2 of 5 Enabled Check Digit Verification Do not transmit Check Digit Maximum Length Minimum Length Industrial 2 of 5 Enabled Industrial 2 of 5 Disabled Check Digit Verification...
  • Page 145 Parameter Factory Default Remark Codabar Enabled Codabar Disabled Check Digit Verification Do not transmit Check Digit Do not transmit Start/Stop Character ABCD/ABCD Start/Stop Character Format Maximum Length Minimum Length Code 93 Enabled Code 93 Enabled Check Digit Verification Do not transmit Check Digit Maximum Length Minimum Length...
  • Page 146 Parameter Factory Default Remark JAN Code for Magazines Disabled JAN Code for Books Disabled Require Concatenation (for JAN Code for Books) Disabled Barcode Separator (for JAN Code for Books) Disabled PDF 417 Enabled PDF 417 2710 Maximum Length Minimum Length Read single PDF417 only PDF 417 Twin Code Default Character...

  • Page 147: Appendix 2: Aim Id Table

    Appendix 2: AIM ID Table Symbology AIM ID Remark Standard EAN-13 EAN-13 EAN-13 + 2/5-Digit Add-On Code Standard EAN-8 ]E4…]E1… EAN-8 EAN-8 + 2-Digit Add-On Code ]E4…]E2… EAN-8 + 5-Digit Add-On Code Standard UPC-E UPC-E UPC-E + 2/5-Digit Add-On Code Standard UPC-A UPC-A UPC-A + 2/5-Digit Add-On Code...
  • Page 148 Symbology AIM ID Remark Code 93 Standard Code 93 MOD11; transmit check digit MOD11/MOD11; transmit check digit Code 11 Do not transmit check digit after verification No check digit verification GS1-DataBar (RSS) Standard GS1-DataBar Plessey Standard Plessey MOD10; transmit check digit MOD10;...

  • Page 149: Appendix 3: Code Id Table

    Appendix 3: Code ID Table Symbology Code ID Code 128 GS1-128(UCC/EAN-128) AIM-128 EAN-8 EAN-13 ISSN ISBN UPC-E UPC-A Interleaved 2 of 5 ITF-6 ITF-14 Matrix 2 of 5 Industrial 2 of 5 Standard 2 of 5 Code 39 Codabar Code 93 Code 11 Plessey MSI-Plessey...

  • Page 150: Appendix 4: Ascii Table

    Appendix 4: ASCII Table Char (Null char.) (Start of Header) (Start of Text) (End of Text) (End of Transmission) (Enquiry) (Acknowledgment) (Bell) (Backspace) (Horizontal Tab) (Line Feed) (Vertical Tab) (Form Feed) (Carriage Return) (Shift Out) (Shift In) (Data Link Escape) (XON) (Device Control 1) (Device Control 2) (XOFF) (Device Control 3)
  • Page 151 Char (Request to Send) (Unit Separator) (Space) (Exclamation Mark) " (Double Quote) (Number Sign) (Dollar Sign) (Percent) & (Ampersand) (Single Quote) (Left / Opening Parenthesis) (Right / Closing Parenthesis) (Asterisk) (Plus) (Comma) (Minus / Dash) (Dot) (Forward Slash) (Colon) (Semi-colon) <...
  • Page 152 Char > (Greater Than) (Question Mark) (AT Symbol) (Left / Opening Bracket) (Back Slash) (Right / Closing Bracket)
  • Page 153 Char (Caret / Circumflex) (Underscore) (Grave Accent) (Left/ Opening Brace) (Vertical Bar) (Right/Closing Brace) (Tilde) (Delete)

  • Page 154: Appendix 5: Parameter Programming Examples

    Appendix 5: Parameter Programming Examples The following examples show you how to program parameters by scanning programming barcodes. a. Program the Decode Session Timeout Example: Set the decode session timeout to 1500ms Scan the Enter Setup barcode. Scan the Decode Session Timeout barcode. (See the “Decode Session Timeout” section in Chapter 3) Scan the numeric barcodes “1”, “5”, “0”...

  • Page 155: Program The Timeout Between Decodes (Same Barcode)

    d. Program the Timeout between Decodes (Same Barcode) Example: Set the timeout between decodes (same barcode) to 1000ms Scan the Enter Setup barcode. Scan the Timeout between Decodes (Same Barcode) barcode. (See the “Timeout between Decodes (Same Barcode)” section in Chapter 3) Scan the numeric barcodes “1”, “0”, “0”...

  • Page 156: Program The Decoding Area

    g. Program the Decoding Area Example: Set the decoding area to 20% top, 80% bottom, 20% left and 80% right. Scan the Enter Setup barcode. Scan the Specific Area Decoding barcode. (See the “Specific Area Decoding” section in Chapter 4) Scan the Top of Decoding Area barcode.

  • Page 157: Program The Terminating Character Suffix

    i. Program the Terminating Character Suffix Example: Set the terminating character suffix to 0x0D Scan the Enter Setup barcode. Scan the Set Terminating Character Suffix barcode. (See the “Set Terminating Character Suffix” section in Chapter 6) Scan the numeric barcodes “0” and “D”. Scan the Save barcode.

  • Page 158: Program The Length Range (Maximum/Minimum Lengths) For A Symbology

    l. Program the Length Range (Maximum/Minimum Lengths) for a Symbology Note: If minimum length is set to be greater than maximum length, the engine only decodes barcodes with either the minimum or maximum length. If you only want to read barcodes with a specific length, set both minimum and maximum lengths to be that desired length.

  • Page 159: Program The Custom Inter-Keystroke Delay

    n. Program the Custom Inter-keystroke Delay Example: Set the inter-keystroke delay to 5ms Scan the Enter Setup barcode. Scan the Custom Delay barcode. (See the “Inter-Keystroke Delay” section in Chapter 2) Scan the numeric barcodes “0” and “5”. Scan the Exit Setup barcode. (If you still need to program other parameter/feature, skip this step.) o.

  • Page 160: Appendix 6: Digit Barcodes

    Appendix 6: Digit Barcodes...

  • Page 162: Appendix 7: Save/Cancel Barcodes

    Appendix 7: Save/Cancel Barcodes After reading numeric barcode(s), you need to scan the Save barcode to save the data. If you scan the wrong digit(s), you can either scan the Cancel barcode and then start the configuration all over again, or scan the Delete the Last Digit barcode and then the correct digit, or scan the Delete All Digits barcode and then the digits you want.

  • Page 163: Appendix 8: Ascii Function Key Mapping Table

    Appendix 8: ASCII Function Key Mapping Table ASCII Function ASCII Value (HEX) No Function Key Mapping Function Key Mapping (Null char.) Null Ctrl+@ Keypad Enter Ctrl+A (Start of Header) Caps Lock Ctrl+B (Start of Text) Ctrl+C (End of Text) Null Ctrl+D (End of Transmission) CTRL...
  • Page 164 ASCII Function Key Mapping Table (Continued) The function key mappings of the last five characters in the previous table differ from one keyboard layout to another. Function Key Mapping Country/ Keyboard Layout United States Ctrl+[ Ctrl+\ Ctrl+] Ctrl+6 Ctrl+- Belgium Ctrl+[ Ctrl+<...

  • Page 165: Appendix 9: Code Pages List

    Appendix 9: Code Pages List Numeric Barcode Needed Code Page Windows 1252 (Latin I) Windows 1251 (Cyrillic)
