Bluetooth wireless optical mouse and keyboard
Hide thumbs Also See for RF-BTMKY:

Advertisement

Bluetooth Wireless Optical Mouse
and Keyboard
RF-BTMKY
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RF-BTMKY and is the answer not in the manual?

Questions and answers

Summary of Contents for RocketFish RF-BTMKY

  • Page 1 Bluetooth Wireless Optical Mouse and Keyboard RF-BTMKY User Guide...
  • Page 2: Table Of Contents

    Rocketfish RF-BTMKY Bluetooth Wireless Optical Mouse and Keyboard Contents Features................2 Setting up your keyboard and mouse ..... 7 Connecting other Bluetooth devices .....19 Troubleshooting ............20 Legal notices ..............20 Features Package contents Make sure that your package contains: • Keyboard •...
  • Page 3 My Bluetooth Places window. Click the My Bluetooth Places icon on Help Bluetooth Help your Windows desktop. In the window that opens, click , then click Topics . For information on security codes and special instructions on particular Bluetooth devices, see the manufacturer’s documentation. RF-BTMKY...
  • Page 4: System Requirements

    System requirements • A computer with an available USB port • Microsoft® Windows® XP or Windows 2000 operating system Keyboard and mouse components Keyboard top Your keyboard has 103 keys. In addition to the standard keys, your keyboard has a row of hotkeys. Print Insert Delete...
  • Page 5: Keyboard Bottom

    • Hotkeys are disabled while automatically pairing in boot and Windows mode. • Your keyboard enters power-saving mode after being idle for 10 minutes. Keyboard bottom Connect Battery button compartment Connect To check the power status of your keyboard: • Click Start, Control Panel, Keyboard, then click Bluetooth. RF-BTMKY...
  • Page 6: Mouse Top

    Mouse top The mouse LED changes depending on the status of the mouse. • LED red—Batteries are drained. Replace the batteries. • LED flashing green and red—Mouse is pairing.
  • Page 7: Setting Up Your Keyboard And Mouse

    To view more information about your mouse: • Click Start, Control Panel, Mouse, then click Bluetooth. Setting up your keyboard and mouse Installing the keyboard batteries To install the keyboard batteries: Turn your keyboard over so the bottom is facing up. RF-BTMKY...
  • Page 8 Remove the battery compartment cover. Insert two AA batteries into the battery compartment. Make sure that the + and – symbols on the batteries align with the + and – symbols in the battery compartment. Replace the battery compartment cover.
  • Page 9: Installing The Mouse Batteries

    Press the button on top of the mouse to release the battery compartment cover, then remove the cover. Insert two AA batteries into the battery compartment. Make sure that the + and – symbols on the batteries align with the + and – symbols in the battery compartment. RF-BTMKY...
  • Page 10 Replace the battery compartment cover. Installing the Bluetooth software To install the Bluetooth software: Plug your Bluetooth dongle into a USB port on your computer. Insert the provided installation CD into the CD or DVD drive on your computer. The installation program starts automatically and the Welcome screen opens.
  • Page 11 Read the license agreement, click I accept the terms in the license agreement, then click Next. The Destination Folder screen opens. If you want to accept the default installation folder, click Next. The Ready to Install the Program screen opens. RF-BTMKY...
  • Page 12 If you want to change the installation folder, click Change, select the folder you want, then click Next. The Ready to Install the Program screen opens. Click Install. The installation begins. This process may take several minutes. When the installation is complete, the Install Wizard Completed screen opens, but do not click Finish yet.
  • Page 13 When you are prompted to restart your computer, click Yes. Automatically pairing in boot mode (after initial pairing) To automatically pair in boot mode: Make sure that your computer is turned off, then plug the USB Bluetooth dongle into a USB port on your computer. RF-BTMKY...
  • Page 14 Slide the power switch on the bottom of the mouse to turn on the mouse. The Bluetooth connection is established. Turn on your computer. Use the keyboard to open the BIOS Setup utility. See your computer’s documentation for information about opening the BIOS Setup utility. Use the keyboard arrow keys to navigate through the BIOS and to turn on the USB function for the USB keyboard and mouse.
  • Page 15 Pairing button Use the tip of an unfolded paper clip (or similar object without a sharp tip) to gently press the connect button (inside the hole on the back of the keyboard) for two seconds. Keyboard connect button Connect RF-BTMKY...
  • Page 16 Press the button on the USB Bluetooth dongle until the LED begins to flash once every second. This indicates the Bluetooth dongle is searching for devices to pair. While pairing, the mouse LED flashes red and green. USB Bluetooth dongle button Note: If you press the mouse pairing button or the keyboard connect button, the pairing settings are cancelled.
  • Page 17 Follow the on-screen instructions. When configuration is complete, the Select a device dialog box opens and your computer starts searching for Bluetooth devices. Click the device you want to connect, then follow the on-screen instructions. RF-BTMKY...
  • Page 18 Pairing with the Bluetooth software To pair with the Bluetooth software: Press the USB Bluetooth dongle button until the following dialog box opens. When you are prompted to confirm that the correct mouse was found, click Click here with your mouse. The Bluetooth Pairing dialog box opens.
  • Page 19: Connecting Other Bluetooth Devices

    A list of available devices appears. Click on the device you want to use, then follow the on-screen instructions for configuring the device. Enter the Bluetooth security code from the device user manual. RF-BTMKY...
  • Page 20: Troubleshooting

    Troubleshooting • Make sure that your computer meets system requirements. • Make sure that the batteries in the keyboard and mouse are installed correctly. Make sure the + and – symbols on the batteries align with the + and – symbols inside the battery compartments. •...
  • Page 21 (e.i.r.p.) is not more than that permitted for successful communication. Copyright © 2008 Rocketfish. Rocketfish and the Rocketfish logo are trademarks of Best Buy Enterprise Services, Inc. Other brands and product names are trademarks or registered trademarks of their respective holders.
  • Page 23 RF-BTMKY...
  • Page 24 7601 Penn Avenue South, Richfield, MN 55423-3645 USA © 2008 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. All other products and brand names are trademarks of their respective owners.
