Bluetooth Combo
RF-BTCMB02
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KKBBT04 and is the answer not in the manual?

Questions and answers

Related Manuals for RocketFish KKBBT04

Summary of Contents for RocketFish KKBBT04

  • Page 1 Bluetooth Combo RF-BTCMB02 User Guide...

  • Page 2: Table Of Contents

    Bluetooth Combo Contents Important safety instructions ........3 Introduction ..............4 Features................4 Package contents ..........5 System requirements ........... 5 Keyboard top ............6 Keyboard status LED..........7 Keyboard bottom ..........8 Mouse top ..............9 Mouse status LED ..........10 Mouse bottom............10 Setting up the keyboard and mouse......11 Installing keyboard batteries......11...

  • Page 3: Important Safety Instructions

    Installing and using software........18 Installing the software........18 Using the Bluetooth stack for the first time in Windows XP............19 Using the keyboard and mouse.......23 Checking battery status ........23 Changing the low battery alarm settings...25 Adjusting the tilt/scroll wheel ......26 Maintaining ..............28 Troubleshooting ............28 Specifications..............29 Legal notices ..............30...

  • Page 4: Introduction

    To reduce the risk of fire or electric shock, do not expose this device to rain, moisture, dripping, or splashing, and no objects filled with liquids, such as vases, shall be placed on it. Batteries should not be exposed to excessive heat such as sunshine, fire, or the like.

  • Page 5: Package Contents

    USB Bluetooth receiver • Bluetooth specification v1.0, v2.0, and v2.1 compliant • Supports both keyboard and mouse • Supports additional Bluetooth devices Package contents • Keyboard • Laser mouse • USB Bluetooth receiver (inside the mouse battery compartment) • Installation CD including software and User Guide •...

  • Page 6: Keyboard Top

    Keyboard top Note: To use the keyboard hotkeys, you must install the WIDCOMM Bluetooth stack. See “Installing the software” on page 18. Prt Scr Scroll Pause Screen Lock Backspace Insert Home & Lock Page Page Delete Down PgUp Caps Lock "...

  • Page 7: Keyboard Status Led

    Icon Description Status LED. For more information, see “Keyboard status LED” on page 7. E-mail button. Press to open your e-mail program. Sleep button. Press to put your computer in sleep mode. Press again to wake your computer. Home button. Press to go to your home page in a Web browser.

  • Page 8: Keyboard Bottom

    Keyboard bottom CONN EC T OF F Item Description CONNECT button Press to put the keyboard in pre-pairing mode. OFF ON switch Slide to turn the keyboard on or off.

  • Page 9: Mouse Top

    Mouse top Note: To use the mouse hotkey buttons, you must install the WIDCOMM Bluetooth stack. See “Installing the software” on page 18. To use horizontal scrolling, you must install the Bluetooth mouse software. See “Installing the software” on page 18. Item Description Left button...

  • Page 10: Mouse Status Led

    Mouse status LED Color Description The mouse is turned on and the battery level Green normal. The battery level is low. Flashing red The mouse is pairing. Flashing green Mouse bottom CONNECT Item Description Laser sensor Detects the mouse movements and sends signals to the computer to move the mouse pointer on the screen.

  • Page 11: Setting Up The Keyboard And Mouse

    Setting up the keyboard and mouse Installing keyboard batteries To install keyboard batteries: Remove the battery compartment cover. Insert two AA batteries into the battery compartment. Make sure that the + and – symbols on the batteries align with the + and – symbols in the battery compartment.

  • Page 12: Installing The Mouse Batteries

    Installing the mouse batteries To install mouse batteries: Press the tab to release the battery compartment cover, then remove the cover. Pull the receiver out of the battery compartment.
  • Page 13 Insert two AA batteries into the battery compartment. Make sure that the + and – symbols on the batteries align with the + and – symbols in the battery compartment. Replace the battery compartment cover. RF-BTCMB02...

  • Page 14: Pairing The Keyboard And Mouse

    Pairing the keyboard and mouse There are three methods for pairing the keyboard and mouse: • “Automatic pairing in boot mode” on page 14. • “Pairing by using the WIDCOMM Bluetooth stack” on page 15 Automatic pairing in boot mode To pair automatically in boot mode: With your computer turned off, plug the USB Bluetooth receiver into an available USB port.
  • Page 15 Turning on the USB keyboard and mouse settings in BIOS If pairing in boot mode did not work, you may need to turn on the USB keyboard and mouse settings in the BIOS. To turn on the USB keyboard and mouse settings in BIOS: Make sure that the Bluetooth connection has been established before turning on your computer.
  • Page 16 To pair using the Bluetooth stack: Press the CONNECT buttons on the mouse and keyboard to start pairing. Your computer starts to search for all Bluetooth devices. When the mouse is connected, the Confirmation Required message appears.
  • Page 17 Click to confirm that the mouse is connected. When the keyboard is connected, the Bluetooth Security Setup dialog box appears. Use the paired keyboard to type the digits shown on the screen, then press Enter. The keyboard is connected. Note: The keyboard and mouse enter the power saving mode when not used for a period of time.

  • Page 18: Installing And Using Software

    Installing and using software Installing the software To use the keyboard and mouse hotkey buttons, you must install the software on the included CD. To install the software: Plug the USB Bluetooth receiver into a USB port on your computer. Insert the included CD in the disc drive.

  • Page 19: Using The Bluetooth Stack For The First Time In Windows Xp

    Features. In Windows XP, click Start, Settings, Control Panel, then click Add/Remove Programs. Click Rocketfish Bluetooth Combo in the program list, then click Uninstall (Windows Vista or Windows 7)or Remove (Windows XP). A confirmation message appears. Click Yes to uninstall or No to cancel.
  • Page 20 Follow the on-screen instructions to complete the configuration. When the Bluetooth configuration is complete, the Bluetooth Device Selection dialog box appears and the computer starts searching for Bluetooth devices. Click on the device you want to connect with, then follow the on-screen instructions to enable the selected device.
  • Page 21 Connecting to other Bluetooth devices in Windows XP Note: You must install the software on the included CD in order to connect to other Bluetooth devices. To connect to other Bluetooth devices: Make sure that the USB Bluetooth receiver has been plugged in to your computer.
  • Page 22 Setting up Bluetooth in Windows Vista or Windows 7 To set up Bluetooth stack in Windows Vista or Windows 7: Double-click the Bluetooth icon in the system tray. The Bluetooth Settings screen opens. Click the Devices tab, then click Add. The Add Bluetooth Device Wizard starts.

  • Page 23: Using The Keyboard And Mouse

    Using the keyboard and mouse Checking battery status Note: You must install the software on the included CD and pair the keyboard and mouse before you can check battery status. To check the keyboard battery status: • Click Start, Control Panel, Keyboard, then click Bluetooth. The Keyboard Properties dialog box opens with the Bluetooth tab on top.
  • Page 24 To check the mouse battery status: • Click Start, Control Panel, Mouse, then click Bluetooth. The Mouse Properties dialog box opens with the Bluetooth tab on top. The remaining battery power level is shown.

  • Page 25: Changing The Low Battery Alarm Settings

    Changing the low battery alarm settings To change the low battery alarm settings: Open the Keyboard Properties dialog box or the Mouse Properties dialog box. For instructions, see “Checking battery status” on page 23. Click Low Battery Alarm. The Low Battery Alarm dialog box opens. Change the settings you want, then click OK.

  • Page 26: Adjusting The Tilt/Scroll Wheel

    Adjusting the tilt/scroll wheel Your mouse comes with an advanced scroll wheel that lets you scroll horizontally as well as vertically.
  • Page 27 To adjust the tilt/scroll wheel: Right-click the Mouse icon in the system tray, then click Adjust Property. The Bluetooth Mouse Property dialog box opens. To set the vertical scroll speed, click one of the following, then click OK. • Scroll x line(s) per notch—Sets the number of lines to scroll when the scroll wheel is moved one notch.

  • Page 28: Maintaining

    Maintaining To clean your Bluetooth keyboard and mouse, wipe them with a soft, lint-free cloth slightly moistened with water. Troubleshooting If you have any problems with your Bluetooth keyboard or mouse, check the following: • Make sure that your computer meets the system requirements. •...

  • Page 29: Specifications

    Specifications Mouse Keyboard Mouse: 1.7 × 4.9 × 2.88 inches 1.14 × 19.8 × 8.35 inches (43.28 x 124.57 x 73.2 mm) (29 x 503 x 212 mm) Dimensions H × L × W Dongle: 0.18 × 0.75 × 0.53 inches (4.5 x 19.15 x 13.55 mm) 1200 DPI @ 10 inch/sec Resolution...

  • Page 30: Legal Notices

    Legal notices FCC Part 15 This device complies with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 33: One-Year Limited Warranty

    Product is determined to be defective by an authorized Rocketfish repair center or store personnel, Rocketfish will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced under this warranty become the property of Rocketfish and are not returned to you.
  • Page 34 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2009 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
  • Page 35 7601 Penn Avenue South, Richfield, MN 55423-3645 USA © 2009 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. All other products and brand names are trademarks of their respective owners.
