Summary of Contents for RocketFish MMORFE4UL
- Page 1 RF-CMBO_10-0213_MAN_V1_English.fm Page 1 Monday, March 29, 2010 9:40 AM 2.4 GHz Wireless Combo RF-CMBO User Guide...
-
Page 2: Table Of Contents
RF-CMBO_10-0213_MAN_V1_English.fm Page 2 Wednesday, March 31, 2010 3:35 PM 2.4 GHz Wireless Combo Contents Important safety instructions ........3 Introduction ..............4 Features................4 Package contents ..........5 System requirements ........... 5 Keyboard top ............5 Keyboard status LED..........7 Keyboard bottom .......... -
Page 3: Important Safety Instructions
RF-CMBO_10-0213_MAN_V1_English.fm Page 3 Wednesday, March 31, 2010 3:35 PM Using the combo driver ..........13 Installing the combo driver ......14 Configuring the mouse ........14 Uninstalling the combo driver......19 Maintaining ..............20 Troubleshooting ............20 Specifications..............20 Legal notices ..............22 One-year limited warranty.........25 Important safety instructions Read these instructions. -
Page 4: Introduction
RF-CMBO_10-0213_MAN_V1_English.fm Page 4 Wednesday, March 31, 2010 3:35 PM Introduction Congratulations on your purchase of a Rocketfish 2.4 GHz Wireless Combo. This guide explains how to correctly operate and get the best performance from your wireless keyboard and mouse. Read this user guide carefully before using your product, then keep it next to your computer for quick reference. -
Page 5: Package Contents
RF-CMBO_10-0213_MAN_V1_English.fm Page 5 Wednesday, March 31, 2010 3:35 PM Package contents Before you start using your keyboard and mouse the first time, verify that your package contains the following: • Keyboard • Laser Mouse • 2.4 GHz receiver • Installation CD •... - Page 6 RF-CMBO_10-0213_MAN_V1_English.fm Page 6 Wednesday, March 31, 2010 3:35 PM Icon Description Previous track button. Press to go to the previous track on a CD or previous chapter on a DVD. Next track button. Press to go to the next track on a CD or next chapter on a DVD. Increase volume button.
-
Page 7: Keyboard Status Led
RF-CMBO_10-0213_MAN_V1_English.fm Page 7 Wednesday, March 31, 2010 3:35 PM Keyboard status LED Color Description The keyboard is turned on and the battery level normal. Green The battery level is low. Flashing red The keyboard is pairing. Flashing red and green Keyboard bottom CONN EC T OF F... -
Page 8: Mouse Top
RF-CMBO_10-0213_MAN_V1_English.fm Page 8 Wednesday, March 31, 2010 3:35 PM Mouse top Item Description Left button Press to perform left-button actions like selecting items or opening programs. Forward button Press to go to the next page in a Web browser. Back button Press to go to the previous page in a Web browser. -
Page 9: Mouse Bottom
RF-CMBO_10-0213_MAN_V1_English.fm Page 9 Wednesday, March 31, 2010 3:35 PM Mouse bottom CONNECT Item Description Laser sensor Detects the mouse movements and sends signals to the computer to move the mouse pointer on the screen. CONNECT button Press to put the mouse in pre-pairing mode. OFF ON switch Slide to turn the mouse on or off. -
Page 10: Setting Up The Keyboard And Mouse
RF-CMBO_10-0213_MAN_V1_English.fm Page 10 Wednesday, March 31, 2010 3:35 PM Setting up the keyboard and mouse Installing keyboard batteries To install keyboard batteries: Remove the battery compartment cover. Insert two AA batteries into the battery compartment. Make sure that the + and – symbols on the batteries align with the + and – symbols in the battery compartment. -
Page 11: Installing The Mouse Batteries
RF-CMBO_10-0213_MAN_V1_English.fm Page 11 Wednesday, March 31, 2010 3:35 PM Installing the mouse batteries To install mouse batteries: Press the tab to release the battery compartment cover, then remove the cover. Pull the receiver out of the battery compartment. RF-CMBO... - Page 12 RF-CMBO_10-0213_MAN_V1_English.fm Page 12 Wednesday, March 31, 2010 3:35 PM Insert two AA batteries into the battery compartment. Make sure that the + and – symbols on the batteries align with the + and – symbols in the battery compartment. Replace the battery compartment cover.
-
Page 13: Setting Up The Keyboard And Mouse
RF-CMBO_10-0213_MAN_V1_English.fm Page 13 Wednesday, March 31, 2010 3:35 PM Setting up the keyboard and mouse To set up the keyboard and mouse: Plug the 2.4 GHz receiver into an available USB port on your computer. Slide the power switch of the mouse to ON, to turn the mouse on. Slide the power switch of the keyboard to ON, to turn the keyboard on. - Page 14 The installation program should start automatically. If it does not start automatically, open Windows Explorer, browse to the CD, then double- click autorun.exe. The Rocketfish Wireless combo screen opens. Click Install Combo Driver. The Welcome screen opens. Click Next. The Start installation screen opens.
