Summary of Contents for RocketFish RF-BTCMB02

  • Page 1 Bluetooth Combo RF-BTCMB02 User Guide...
  • Page 2: Table Of Contents

    Bluetooth Combo Contents Important safety instructions ... 3 Introduction ... 4 Features... 4 Package contents ... 5 System requirements ... 5 Keyboard top ... 6 Keyboard status LED... 7 Keyboard bottom ... 8 Mouse top ... 9 Mouse status LED ...10 Mouse bottom...10 Setting up the keyboard and mouse...11 Installing keyboard batteries...11...
  • Page 3: Important Safety Instructions

    Do not use this apparatus near water. Clean only with dry cloth. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. Only use attachments/accessories specified by the manufacturer. RF-BTCMB02...
  • Page 4: Introduction

    To reduce the risk of fire or electric shock, do not expose this device to rain, moisture, dripping, or splashing, and no objects filled with liquids, such as vases, shall be placed on it. Batteries should not be exposed to excessive heat such as sunshine, fire, or the like.
  • Page 5: Package Contents

    • Installation CD including software and User Guide • Batteries for the keyboard and mouse • Quick Setup Guide System requirements • Computer with a USB port • Microsoft Windows® 7, Windows Vista®, Windows® XP with Service Pack 3 or higher RF-BTCMB02...
  • Page 6: Keyboard Top

    Keyboard top Note: To use the keyboard hotkeys, you must install the WIDCOMM Bluetooth stack. See “Installing the software” on page 18. Caps Lock Shift Ctrl Icon Prt Scr Scroll Pause Screen Lock Backspace Insert Home & Page Delete " Enter >...
  • Page 7: Keyboard Status Led

    Refresh Web page button. Press to refresh (reload) a page in a Web browser. Stop Web page button. Press to stop loading a page in a Web browser. Description The keyboard is turned on and the battery level normal. The battery level is low. The keyboard is pairing. RF-BTCMB02...
  • Page 8: Keyboard Bottom

    Keyboard bottom CONN EC T Item CONNECT button OFF ON switch OF F Description Press to put the keyboard in pre-pairing mode. Slide to turn the keyboard on or off.
  • Page 9: Mouse Top

    If you press down on the scroll wheel, a four-way icon appears on the screen. Move the mouse up, down, left, or right to scroll. Status LED. For more information, see “Mouse status LED” on page 10. RF-BTCMB02...
  • Page 10: Mouse Status Led

    Mouse status LED Color Green Flashing red Flashing green Mouse bottom Item Laser sensor CONNECT button OFF ON switch Battery compartment Description The mouse is turned on and the battery level normal. The battery level is low. The mouse is pairing. CONNECT Description Detects the mouse movements and sends signals to the...
  • Page 11: Setting Up The Keyboard And Mouse

    Remove the battery compartment cover. Insert two AA batteries into the battery compartment. Make sure that the + and – symbols on the batteries align with the + and – symbols in the battery compartment. Replace the battery compartment cover. RF-BTCMB02...
  • Page 12: Installing The Mouse Batteries

    Installing the mouse batteries To install mouse batteries: Press the tab to release the battery compartment cover, then remove the cover. Pull the receiver out of the battery compartment.
  • Page 13 Insert two AA batteries into the battery compartment. Make sure that the + and – symbols on the batteries align with the + and – symbols in the battery compartment. Replace the battery compartment cover. RF-BTCMB02...
  • Page 14: Pairing The Keyboard And Mouse

    Pairing the keyboard and mouse There are three methods for pairing the keyboard and mouse: • “Automatic pairing in boot mode” on page 14. • “Pairing by using the WIDCOMM Bluetooth stack” on page 15 Automatic pairing in boot mode To pair automatically in boot mode: With your computer turned off, plug the USB Bluetooth receiver into an available USB port.
  • Page 15 • The USB Bluetooth receiver is plugged into a USB port on your computer. • The mouse is turned on. Note: To start the Bluetooth stack for the first time, see “Using the Bluetooth stack for the first time in Windows XP” on page 19. RF-BTCMB02...
  • Page 16 To pair using the Bluetooth stack: Press the CONNECT buttons on the mouse and keyboard to start pairing. Your computer starts to search for all Bluetooth devices. When the mouse is connected, the Confirmation Required message appears.
  • Page 17 Bluetooth Security Setup dialog box appears. Use the paired keyboard to type the digits shown on the screen, then press Enter. The keyboard is connected. Note: The keyboard and mouse enter the power saving mode when not used for a period of time. RF-BTCMB02...
  • Page 18: Installing And Using Software

    Installing and using software Installing the software To use the keyboard and mouse hotkey buttons, you must install the software on the included CD. To install the software: Plug the USB Bluetooth receiver into a USB port on your computer. Insert the included CD in the disc drive.
  • Page 19: Using The Bluetooth Stack For The First Time In Windows Xp

    Features. In Windows XP, click Start, Settings, Control Panel, then click Add/Remove Programs. Click Rocketfish Bluetooth Combo in the program list, then click Uninstall (Windows Vista or Windows 7)or Remove (Windows XP). A confirmation message appears. Click Yes to uninstall or No to cancel.
  • Page 20 Follow the on-screen instructions to complete the configuration. When the Bluetooth configuration is complete, the Bluetooth Device Selection dialog box appears and the computer starts searching for Bluetooth devices. Click on the device you want to connect with, then follow the on-screen instructions to enable the selected device.
  • Page 21 Click the device list to open the list of Bluetooth devices, then click the type of device you want to search for. The detected devices are displayed. Click a device, then follow the on-screen instructions to connect to the device. RF-BTCMB02...
  • Page 22 Setting up Bluetooth in Windows Vista or Windows 7 To set up Bluetooth stack in Windows Vista or Windows 7: Double-click the Bluetooth Settings screen opens. Click the Devices tab, then click Add. The Add Bluetooth Device Wizard starts. Click My device is set and ready to be found, then click Next. Select the device(s) you want to enable, then click Next.
  • Page 23: Using The Keyboard And Mouse

    To check the keyboard battery status: • Click Start, Control Panel, Keyboard, then click Bluetooth. The Keyboard Properties dialog box opens with the Bluetooth tab on top. The remaining battery power level is shown. RF-BTCMB02...
  • Page 24 To check the mouse battery status: • Click Start, Control Panel, Mouse, then click Bluetooth. The Mouse Properties dialog box opens with the Bluetooth tab on top. The remaining battery power level is shown.
  • Page 25: Changing The Low Battery Alarm Settings

    Click Low Battery Alarm. The Low Battery Alarm dialog box opens. Change the settings you want, then click OK. You can change the level at which you want the alarm to occur and turn the audio and visual notifications on or off. RF-BTCMB02...
  • Page 26: Adjusting The Tilt/Scroll Wheel

    Adjusting the tilt/scroll wheel Your mouse comes with an advanced scroll wheel that lets you scroll horizontally as well as vertically.
  • Page 27 • Scroll one screen per notch—Scrolls the entire window when the scroll wheel is moved one notch. To set the horizontal scroll speed, move the Horizontal Scroll slider toward Slow or Fast, or click Use Default to restore the factory settings. Click OK. RF-BTCMB02...
  • Page 28: Maintaining

    Maintaining To clean your Bluetooth keyboard and mouse, wipe them with a soft, lint-free cloth slightly moistened with water. Troubleshooting If you have any problems with your Bluetooth keyboard or mouse, check the following: • Make sure that your computer meets the system requirements. •...
  • Page 29: Specifications

    AA x 2 EMI, ESD, RS, EFT, FCC, IC, BQB, WHQL Keyboard 1.14 × 19.8 × 8.35 inches (29 x 503 x 212 mm) 31.75 oz. (900 g) (without battery) 104-key standard key with 18-multimedia hot keys AA x 2 RF-BTCMB02...
  • Page 30: Legal Notices

    Legal notices FCC Part 15 This device complies with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 31 This Class B digital apparatus complies with Canadian ICES-003. RSS 310 statement To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication. RF-BTCMB02...
  • Page 33: One-Year Limited Warranty

    Product is determined to be defective by an authorized Rocketfish repair center or store personnel, Rocketfish will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced under this warranty become the property of Rocketfish and are not returned to you.
  • Page 34 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2009 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
  • Page 35 7601 Penn Avenue South, Richfield, MN 55423-3645 USA © 2009 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. All other products and brand names are trademarks of their respective owners.
