  • Page 1 Original operating manual Mechanical mounted seed drill D9 2500 Special D9 3500 Super D9 3000 Special D9 4000 Super D9 3000 Super SmartLearning www.amazone.de...
  • Page 2 Please enter the identification data of the implement here. The identification data is provided on the rating plate.

  • Page 3: Table Of Contents

    Protective devices 4.4.1 Calibration troughs Noise emission data Drivable slope inclination 4.4.2 Chain guard 5.10 Gear oil Warning symbols 4.5.1 Positions of the warning symbols 4.5.2 Structure of the warning symbols MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 4 6.4.4 Bringing the exact following harrow or seed harrow into transport position 107 10 Maintaining the implement 10.1 Cleaning the implement 10.2 Maintaining the implement 10.2.1 Maintenance schedule MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 5 11.1 Lashing the implement 11.2 Loading the implement with a crane 12 Disposing of the implement 13 Appendix 13.1 Bolt tightening torques 13.2 Other applicable documents 14 Lists 14.1 Glossary 14.2 Index MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 7: About This Operating Manual

    WARNING Indicates a possible danger with moderate risk of severe or fatal physical injury. CAUTION Indicates a danger with low risk of minor or moderate physical injury. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 8: Additional Instructions

    CMS-T-005678-B.1 Responses to instructions are indicated by an arrow. Example: 1. Instruction 1 Response to instruction 1 2. Instruction 2 1.2.3.3 Alternative instructions CMS-T-00000110-B.1 Alternative instructions are introduced with the word "or". MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 9: Listings

    1.2.4 Listings CMS-T-000024-A.1 Listings without a mandatory sequence are shown as a list with bullet points. Example: MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 10: Item Numbers In Illustrations

    A list of other applicable documents is provided in the Appendix. 1.4 Digital operating manual CMS-T-00002024-B.1 The digital operating manual and e-learning can be downloaded from the Info Portal on the AMAZONE website. 1.5 Your opinion is important CMS-T-000059-D.1 AMAZONEN-WERKE H. Dreyer &...

  • Page 11: Safety And Responsibility

    2.1.2.1.1 Requirements imposed on the people who work with the implement CMS-T-00002310-C.1 If the implement is used improperly, people can be injured or killed: To prevent accidents due to improper use, every person who works with MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 12 Farmers are categorically familiar with work involving agricultural machines and can instruct agricultural helpers in how to use the machines, if necessary. They can perform specific, simple repairs and maintenance tasks on agricultural machines themselves. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 13 Objects thrown upward by the tractor or implement can hit and injure persons accompanying the driver. Never allow persons to ride on the implement. Never allow people to climb onto the moving implement. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 14 Failure to comply with the technical limits values of the implement can cause accidents and serious personal injury or death. Moreover, the implement can be damaged. The technical limit values are provided in the Technical data. Comply with the technical limit values. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 15 Missing warning symbols increase the risk of serious or fatal injury. Clean dirty warning symbols. Immediately replace any damaged or illegible warning symbols. Affix the intended warning symbols on spare parts. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 16: Recognizing And Avoiding Dangers

    If the universal joint shaft is angled downward excessively: Switch off the universal joint shaft drive. If you do not need the universal joint shaft: Switch off the universal joint shaft drive. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 17 Wait until implement parts that are still moving have come to a complete standstill, before approaching the implement. Do not touch implement parts until after they have come to a complete standstill. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 18: Safe Operation And Handling Of The Implement

    Only couple and transport the implement with suitable tractors. When the implement is coupled on the tractor, ensure that the tractor's connecting device meets the implement requirements. Carefully couple the implement to the tractor. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 19 When driving on roads, there is risk of accident due to uncontrolled lateral movements of the implement Lock the tractor lower links in place for road travel. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 20 Do not use the control computer or control terminal during road travel If the driver is distracted, it can result in accidents and injuries or even death. Do not operate the control computer or control terminal during road travel. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 21: Safe Maintenance And Modification

    Use the control computer or control terminal as intended. Do not open the control computer or control terminal. Do not pull on the lines. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 22 Remove the ignition key and keep it with you. Wait until all parts still in motion after the unit is switched off, have come to a stop and until hot parts have cooled down. Keep away from moving parts. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 23 When repair tasks are performed on the tractor or on a towed or mounted implement, there is a risk of short circuit. Before performing adjustment tasks or maintenance tasks: Disconnect all connections between the control terminal or control computer and the tractor. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 24 If welding tasks are performed on the tractor or on a towed or mounted implement, the control computer or control terminal can be damaged by overvoltage. Before welding: Disconnect all connections between the control terminal or control computer and the tractor. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 25 CMS-T-00002325-B.1 Special equipment, accessories, and spare parts Special equipment, accessories, and spare parts that do not meet AMAZONE requirements can impair the operational reliability of the implement and cause accidents. Only use original parts or parts that meet the AMAZONE requirements.

  • Page 26: Safety Routines

    If there is doubt as to whether the protective devices are properly installed and functional, have the protective devices checked by a qualified specialist workshop. Ensure that the protective devices are properly installed and functional before any activity on the implement. Replace damaged protective devices. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 27 When climbing up and down, never use the control elements as a hand grip. When climbing down, never jump off of the implement. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 28: Intended Use

    The implement is an agricultural machine for flexible or rigid attachment on the liftpack system or the coupling part of a compatible AMAZONE soil tillage implement that meets the technical requirements. The implement is suitable and intended for the metering and spreading of standard seeds.

  • Page 29: Product Description

    4 | Product description Product description CMS-T-00013739-A.1 4.1 Implement overview CMS-T-00013741-A.1 CMS-I-00011809 Seeding coulter Running gear for working on the field Track marker Seed hopper Loading board Trailed tine harrow MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 30: Function Of The Implement

    The harrow covers the seed with soil. The track markers mark the next bout. The track markers are either fastened on the seed drill or on the soil tillage implement. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 31: Special Equipment

    Mounting kit for tramline marker Electronic tramline control Lay shaft Mounting kit for electronic tramline control Electronic control valve and hydraulic kit for electronic tramline control Electronic hectare counter AmaCo Wiring harness AmaLog+ for D9 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 32: Protective Devices

    CMS-I-00009866 4.4.2 Chain guard CMS-T-00015228-A.1 The chain guard 1 prevents contact with the chain drive of the vario gearbox. CMS-I-00009874 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 33: Warning Symbols

    4 | Product description Warning symbols 4.5 Warning symbols CMS-T-00013742-A.1 4.5.1 Positions of the warning symbols CMS-T-00013744-A.1 MD265 MD082 MD078 MD154 MD078 MD155 CMS-I-00011814 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 34 4 | Product description Warning symbols MD094 MD097 MD095 MD102 MD199 MD155 MD078 MD094 MD096 MD155 MD078 CMS-I-00011815 MD084 MD084 MD078 MD078 MD155 CMS-I-00011816 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 35 4 | Product description Warning symbols MD078 MD078 CMS-I-00011817 MD078 MD078 CMS-I-00011818 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 36: Structure Of The Warning Symbols

    MD082 Risk of falling from stepping surfaces and platforms Never allow people to ride on the implement. Never allow people to climb onto the moving implement. CMS-I-000081 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 37 MD095 Risk of accident due to failure to comply with the instructions in the operating manual Before working on or with the implement, read and understand the operating manual. CMS-I-000138 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 38 Danger due to unintentional starting as well as unintentional and uncontrolled movements of the implement Before all tasks, secure the implement against unintentional starting as well as unintentional and uncontrolled movements. CMS-I-00002253 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 39 CMS-I-00000450 MD199 Risk of accident due to excessive hydraulic system pressure Only couple the implement to tractors with a maximum tractor hydraulic pressure of 3,045.79 psi (210 bar). CMS-I-00000486 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 40: Rating Plate On The Implement

    Follow the manufacturer's safety instructions for handling harmful substances. 4.6 Rating plate on the implement CMS-T-00004505-J.1 Implement number Vehicle ID number Product Permissible technical implement weight Model year Year of manufacture CMS-I-00004294 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 41: Lighting And Identification For Road Travel

    4.7.2 Front lighting and identification CMS-T-00013802-A.1 Warning sign Marker lights CMS-I-00011108 NOTE The lighting and identification for road travel may vary depending on the national regulations. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 42: Additional License Plate

    Documents Auxiliary equipment CMS-I-00002306 4.9 Hopper CMS-T-00017804-A.1 The hopper cover 1 of the seed hopper and the roller tarpaulin 2 of the C-Drill hopper protect the contents from water and dust. CMS-I-00012232 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 43: Fill Level Indicator

    The height of the fill level sensor can be adjusted in the empty seed hopper, and it is selected according to the type of seed. CMS-I-00011275 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 44: Metering System

    A guide funnel 1 routes the seed directly behind the coulter tip 2 . The pivoting coulter support 3 prevents clogging of the coulter outlet when the seed drill is set down. CMS-I-00005985 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 45: Band Sowing Shoe

    3 shape the seed furrow that the spreading material is dropped into. The depth control disks and depth control wheel 1 limit the placement depth and clean the cutting disks. Coulter pressure and placement depth can be adjusted. CMS-I-00004578 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 46: Trailed Tine Harrow

    The harrow fastening has an integrated reverse safety. When driving in reverse the harrow bar turns upward so that the harrow tines are not damaged. When driving forward, the exact following harrow tines return to working position. CMS-I-00011203 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 47: Exact Following Harrow

    CMS-I-00011244 Use the setting lever 3 to set the pressing force of the press rollers or to completely disable the bar with the press rollers. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 48: Tramline Marker

    When driving on roads, the track markers of the D9 4000 Super seed drill must be tilted towards the center of the implement so that the permissible transport height is not exceeded. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 49: Seed Drill Wheel Mark Eradicator

    CMS-I-00012259 4.22 Road safety bars CMS-T-00007937-C.1 The road safety bars 1 cover the tines of the exact following harrow or seed harrow during road travel to protect against injury or damage. CMS-I-00005527 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 50: Technical Data

    22.24 in (56.5 cm) 5.2 Hopper volume CMS-T-00013839-A.1 D9 2500 Special D9 3000 Special Seed hopper (without extension) 95.1 gal (360 l) 118.88 gal (450 l) Seed hopper (with extension) 224.55 gal (850 l) MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 51: Coulters

    4.72 in (12 cm) 4.72 in (12 cm) 5.4 Permissible mounting categories CMS-T-00013846-A.1 Three-point mounting frame Category 2 5.5 Permissible payload CMS-T-00011018-E.1 Permissible payload for operation Permissible payload W lb ( kg) MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 52: Forward Speed

    The workplace-related emission sound pressure level is lower than 70 dB(A), measured in operating status at the ear of the tractor driver with the cab closed. The emission sound pressure level mainly depends on the vehicle used. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 53: Drivable Slope Inclination

    Wintal UG22 WTL-HM, factory-provided FUCHS Renolin MR5 VG22 5.11 Wheel bolt tightening torques CMS-T-00017797-A.1 Tires Self-locking hex nut Tightening torque 180/90-16 10.0/75-15 M12 strength class 10 DIN 6927 66.38 ft-lb (90 Nm) 31x15.50-15 (MITAS) MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 54: Preparing The Implement

    Permissible total weight of rear-mounted implement or rear lb ( kg) ballast Distance between the center of gravity of the front-mounted ft ( m) implement or the front ballast and the center of the front axle MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 55: Calculating The Required Tractor Characteristics

    T b 0,2 T b Vmin Vmin Vmin CMS-I-00000513 2. Calculate the actual front axle load. × × - × G a b T b G c + d Vtat Vtat Vtat CMS-I-00000516 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 56 ( kg) lb ( kg) ≤ ≤ Front axle load lb ( kg) lb ( kg) lb ( kg) ≤ ≤ Rear axle load lb ( kg) lb ( kg) lb ( kg) MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 57: Coupling The Implement

    The tractor control unit is used in different activation types, depending on the hydraulic function: CMS-I-00000121 Activation type Function Symbol Latching Permanent oil circulation Oil circulation until action is Momentary executed Free oil flow in the tractor control Floating unit MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 58 Mount the supplied coupling sleeve on the pressureless hydraulic oil return. 1. Depressurize the hydraulic system between the tractor and the implement using the tractor control unit. 2. Clean the hydraulic plug connectors. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 59 1. Plug in the plug connector of the ISOBUS line 1 or the control computer line 2 . 2. Route the ISOBUS cable with sufficient freedom of movement and without chafing or pinching points. CMS-I-00006891 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 60: Coupling The Implement To A Rotary Harrow Or A Rotary Cultivator

    Couple the implement as specified in the operating manual of the rotary harrow or in the operating manual of the rotary cultivator. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 61: Preparing The Implement For Use

    50 oz (50 g) 1.76 oz (50 g) (cereals) (cereals) Normal seed Open Triticale Normal seed 3/4 open Barley Normal seed Open Wheat Normal seed 3/4 open Spelt Normal seed Open Oats Normal seed Open MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 62 Oilseed (wet Normal seed / 3/4 open dressed) fine seed Red clover Fine seed 3/4 open Soya Normal seed 3/4 open Sunflower Normal seed 3/4 open Vetches Normal seed 3/4 open MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 63 NOTE This adjustment influences the seed rate. Calibrate the seed rate after the adjustment. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 64 4. Lift the seed drill far enough that the seeder wheels can turn freely. CMS-I-00011387 5. Insert the calibration crank with the carrier socket 1 into the squared tube 2 in the right seed drill wheel. CMS-I-00011388 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 65 10. Re-attach the calibration troughs. 6.3.2.3 Mounting the bean seed metering wheels CMS-T-00017233-A.1 To seed beans, the seed metering wheel combinations of normal seed metering wheel and fine seed metering wheel must be swapped. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 66 This adjustment influences the seed rate. Calibrate the seed rate after the adjustment. 1. Take off the calibration troughs 1 . CMS-I-00011386 2. Detach the tension springs 1 from the lay shaft pivot bearings 2 . CMS-I-00011654 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 67 The solenoid (if present) is swung down together with the lay shaft. CMS-I-00011656 4. Open the seeding shaft press bearing 1 . CMS-I-00011657 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 68 11. In the seeding shaft spur gear 2 unscrew the grub screw 1 . 12. Pull all seed metering wheel combinations and the seeding shaft spur gear off of the seeding shaft. CMS-I-00011662 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 69 23. Hook in the tension springs on the lay shaft pivot bearings. CMS-I-00011664 24. Re-attach the calibration troughs. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 70 The bottom flap lever adjusts the bottom flap shaft. The bottom flap lever can engage in 8 positions in a group of holes. NOTE This adjustment influences the seed rate. Calibrate the seed rate after the adjustment. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 71 NOTE This adjustment influences the seed rate. Calibrate the seed rate after the adjustment. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 72 NOTE The tramline counter should not show "0" when calibrating. If it does, seed will not be conveyed by the tramline seed metering wheels, or a wrong gearbox setting will be determined. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 73 CMS-I-00011826 To swing down the funnel rail: Grasp the funnel rail 2 handles 1 and pull it down. CMS-I-00011827 4. Take off the calibration troughs 1 . CMS-I-00011386 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 74 To arrest the gearbox adjustment lever: Turn the arrest knob clockwise. 9. Take the calibration crank 1 out of the holder 10. Lift the seed drill far enough that the seeder wheels can turn freely. CMS-I-00011387 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 75 1/10 ac (1/10 ha). CMS-I-00011875 12. Turn the seed drill wheel in the direction indicated by the arrow until the seed drops out of all seed housings and into the calibration troughs. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 76 16. Read out the gearbox setting 4 for the desired application rate 3 on the circular slide rule. 17. Place the gearbox adjustment lever on the scale value determined on the circular slide rule. 18. Recalibrate. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 77 To unlock the funnel rail: Pull the spring-loaded levers 1 forward on both sides of the implement. CMS-I-00011826 To swing down the funnel rail: Grasp the funnel rail 2 handles 1 and pull it down. CMS-I-00011827 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 78 Fine seed metering wheels Bean seed metering wheels CMS-I-00011868 7. Set the gearbox adjustment lever on the required value specified in the table. To arrest the gearbox adjustment lever: Turn the arrest knob clockwise. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 79 1/10 ac (1/10 ha). CMS-I-00011875 12. Turn the seed drill wheel in the direction indicated by the arrow until the seed drops out of all seed housings and into the calibration troughs. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 80 16. Read out the gearbox setting 4 for the desired application rate 3 on the circular slide rule. 17. Place the gearbox adjustment lever on the scale value determined on the circular slide rule. 18. Recalibrate. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 81 CMS-I-00011826 To swing down the funnel rail: Grasp the funnel rail 2 handles 1 and pull it down. CMS-I-00011827 3. Take off the calibration troughs 1 . CMS-I-00011386 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 82 Seed metering wheels Gearbox position Normal seed metering wheels Fine seed metering wheels CMS-I-00012270 Bean seed metering wheels To arrest the gearbox adjustment lever: Turn the arrest knob clockwise. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 83 6 | Preparing the implement Preparing the implement for use 9. Take the calibration crank 1 out of the holder CMS-I-00011387 10. Insert the calibration crank 1 into the square tube 2 . CMS-I-00012271 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 84 Depending on the calibration area selected: Multiply the collected seed quantity by the factor "40" or "10". The later application rate ( lb/ac ( kg/ha)) has been calculated. CMS-I-00011884 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 85: Adjusting The Fill Level Sensor

    To adjust the seed level such that when the level underranged the operator, will be prompted to top-up seed: Move the fill level sensor 1 upwards or downwards. 3. Tighten the wing nut. CMS-I-00011372 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 86: Filling The Hopper

    1. Lower the implement. 2. Swing out the loading board steps. To open the seed hopper: Grasp the handle 1 and pull the hopper cover upward. CMS-I-00012085 4. Pour seed into the hopper. CMS-I-00012088 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 87 To fill the hopper with fertilizer: Pour fertilizer into the hopper chamber 1 via the charging sieve. To fill the hopper with seed: Pour seed into the hopper container 2 . CMS-I-00012084 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 88: Adjusting Coulter Pressure And Placement Depth

    CMS-T-00017760-A.1 Coulter pressure is centrally adjusted with the calibration crank. 1. Take the calibration crank 1 out of the holder CMS-I-00011387 2. Fit the calibration crank 1 onto the spindle nut CMS-I-00012145 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 89 Bring the "blue." tractor control unit into float position Charge the tractor control unit "blue" with pressure. Each bore of the hole group is marked with a number. The higher the number on the bore where the pin CMS-I-00012168 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 90 Move the coulter stop 2 to the right To reduce both the coulter pressure and the placement depth: Move coulter stop 2 to the left. To fix the coulter stop in position: CMS-I-00012193 Tighten the nuts 1 . MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 91 "Checking the placement depth". 4. If the desired placement depth has not yet been reached, the coulter pressure must also be adjusted, see "Manual coulter pressure adjustment" or "Hydraulic coulter pressure adjustment". MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 92: Adjusting The Exact Following Harrow Or The Trailed Tine Harrow

    Move the holding arm 4 downward. 5. Mount the bolts 3 . 6. Mount the washers 2 . 7. Mount and tighten washers and nuts 1 . 8. Repeat the procedure on the opposite side. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 93 When the tractor control unit is activated, the harrow pressure increases, and the lever rests on the upper pin. 1. Bring control valve "blue" into float position. 2. Switch off the tractor engine. 3. Apply the parking brake. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 94 9. Bring control valve "blue" into float position. CMS-I-00011913 6.3.6.2.2 Manually adjusting the harrow pressure CMS-T-00017494-A.1 1. Take the calibration crank 1 out of the holder CMS-I-00011387 2. Insert the calibration crank 1 into the guide tube CMS-I-00011929 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 95: Adjusting The Roller Harrow

    To change the pitch of the harrow tines: Peg the linch pin 2 underneath the link 1 . CMS-I-00005161 To check the adjustment: Sow 98.43 ft (30 m) at working speed and check the work pattern. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 96 To check the adjustment: Sow 98.43 ft (30 m) at working speed and check the work pattern. 6.3.7.3 Adjusting roller contact pressure CMS-T-00017530-A.1 1. Swing the levers 1 on both sides upward. CMS-I-00011948 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 97 CMS-I-00011954 3. Secure both setting levers with linch pins 1 . CMS-I-00011955 6.3.7.4 Lifting out the roller harrow CMS-T-00017531-A.1 To de-tension the locking pin: Pull the setting lever 1 slightly downward. CMS-I-00011954 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 98 3. Swing the lever 1 downward. CMS-I-00011957 4. Move the setting lever 1 in the direction of the arrow until it engages. 5. Repeat the procedure on the second setting lever. CMS-I-00011956 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 99: Adjusting The Tramlines

    6.3.8.2 Graphically determining the tramline spacing CMS-T-00017819-A.1 The graphic shows examples for creating tramlines. A: Working width of the seed drill B: Tramline spacing (working width of the cultivating implement) C: tramline control D: tramline counter MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 100 6 | Preparing the implement Preparing the implement for use CMS-I-00012248 See the graphic for the required values. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 101 Depending on the wheelmark width, a different number of tramline metering wheels are mounted next to each other. Depending on the track width, the tramline metering wheels mounted next to each other are positioned differently. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 102 6 | Preparing the implement Preparing the implement for use 1. Take off the calibration troughs 1 . CMS-I-00011386 2. Detach the tension springs 1 from the lay shaft pivot bearings 2 . CMS-I-00011654 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 103 The solenoid (if present) is swung down together with the lay shaft. CMS-I-00011656 To mark the tramline seed metering wheels: Clip a fine seed metering wheel brush 1 on each tramline seed housing. CMS-I-00011643 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 104 CMS-I-00012068 The hex socket bolt 1 must be visible on the fine seed metering wheel. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 105: Operating One-Sided Switching

    15. Re-attach the calibration troughs. 6.3.9 Operating one-sided switching CMS-T-00017623-A.1 With the coupling for one-sided shut-off, the left half of the seeding shaft can be shut-off and seed delivery to the coulters can be interrupted. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 106 6 | Preparing the implement Preparing the implement for use 1. Take off the calibration troughs 1 . CMS-I-00011386 2. Detach the tension springs 1 from the lay shaft pivot bearings 2 . CMS-I-00011654 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 107 The solenoid (if present) is swung down together with the lay shaft. CMS-I-00011656 4. Pull the coupling 1 to the left side. CMS-I-00012037 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 108: Preparing The Track Marker For Operation

    4. Make the same adjustment for the opposite side of the implement. To check the adjustment, drive for 98.43 ft (30 m) at working speed and CMS-I-00001074 then check the work pattern. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 109: Adjusting The Seed Drill Wheel Mark Eradicator

    2. Set the desired working depth of the seed drill wheel mark eradicator. 3. Tighten the bolt. 4. Lock the bolt with a lock nut 2 . CMS-I-00012260 6.3.12 Adjusting the spring suspended wheel mark eradicator CMS-T-00017787-A.1 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 110: Adjusting The Reinforced Tractor Wheel Mark Eradicator

    5. Pivot tractor wheel mark eradicator to the left or right. 6.3.13 Adjusting the reinforced tractor wheel mark eradicator CMS-T-00017785-A.1 6.3.13.1 Adjusting the track width of the wheel mark eradicator CMS-T-00008981-B.1 1. Pull the linch pin 1 . CMS-I-00008365 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 111 6.3.13.2 Adjusting the wheel mark eradicator to the track width CMS-T-00008985-D.1 1. Unscrew the nuts 2 on both sides of the wheel mark eradicator holder. 2. Bring the wheel mark eradicator 1 into the desired lateral position. 3. Tighten nuts. CMS-I-00008363 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 112: Preparing The Implement For Road Travel

    4. Remove the pin 1 . 5. Fold the track markers 2 towards the center of the implement. To fix the track marker in the position: Insert pin 1 in bore 3 . CMS-I-00012203 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 113: Locking The Track Marker

    The outer harrow elements can exceed the permissible transport width in road transport. To avoid exceeding the permitted transport width, the exact following harrow or seed harrow must be brought into transport position before road transport. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 114: Attaching The Road Safety Bars On The Exact Following Harrow

    2. Slide the road safety bars 1 over the tines. 3. Secure the road safety bars with the tensioners 4. Check for firm seat. If the tensioners do not provide enough tension, guide the tensioners through the tine coils. CMS-I-00005185 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 115: Using The Implement

    1. Remove the road safety bars 1 from the exact following harrow. CMS-I-00007544 2. Turn the road safety bars 2 by 180°; place them on top of each other on the holders 1 . CMS-I-00007545 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 116: Bringing The Exact Following Harrow Or Seed Harrow Into Working Position

    3. Tighten the bolt 2 with the universal operating tool. 4. Make the same adjustment on the other side of the implement. To check the adjustment: Sow 98.43 ft (30 m) at working speed and check the work pattern. CMS-I-00004674 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 117: Unfolding The Tramline Marking Device On The Exact Following Harrow

    2 . To unlock the track marker: Remove the linch pin 1 . 3. Insert the linch pin in the bore 3 4. Repeat the procedure on the second track marker. CMS-I-00012121 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 118: Unfolding Track Markers

    7.6 Using the implement CMS-T-00008414-A.1 1. Align the implement parallel to the ground. 2. Lower the implement onto the field. 3. Bring the hydraulics of the 3-point power lift into float position. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 119: Checking The Placement Depth

    CMS-I-00003257 7.8 Turning on headlands CMS-T-00008416-A.1 NOTE When the implement is lifted, the metering unit is switched off. To prevent transverse loads when turning on headlands, Lift out the implement. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 120 7 | Using the implement Turning on headlands To prevent implement damage: Pay attention to obstacles when turning. If the direction of the implement is the same as the direction of travel: Lower the implement. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 121: Rectifying Faults

    In this process the shear bolt was damaged. The lighting for road travel has a Lamp or lighting supply line is Replace the lamp. malfunction. damaged. Replace the lighting supply line. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 122 See page 120 not reach the desired working replaced, the working depth of depth. the soil tillage implement must be corrected. The wheel mark eradicator holders are too high above the soil MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 123 1. Remove nuts 1 . 2. Dismount bolts 5 and plates 2 . 3. Replace harrow tines 3 and 4 . 4. Mount plates and bolts. 5. Mount and tighten washers and nuts. CMS-I-00004677 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 124 Follow the instructions below, when a harrow tine is worn. 1. Remove nut 3 . 2. Dismount the plate 2 . 3. Replace harrow tines 1 . 4. Mount the plate. 5. Mount and tighten the nut. CMS-I-00005330 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 125 7. Mount and tighten the nut. Arm of the track marker shears off CMS-T-00017672-A.1 Required shear bolt M6 x 90 (strength 8.8) If the shear bolt has completely broken away: Replace shear bolt 1 . CMS-I-00012045 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 126 5. Remove the locking pins. 6. Dismount the wheel mark eradicator. CMS-I-00003340 7. Unscrew and dismount the nuts of the clamp connection 2 . 8. Dismount the wheel mark eradicator holder 1 . CMS-I-00003338 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 127 14. Bring the wheel mark eradicator into the desired position. 15. Peg the wheel mark eradicator in position with the locking pin 2 . 16. Secure the locking pin with the linch pin 3 . CMS-I-00003339 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 128: Parking The Implement

    Advance the tramline counter. If the seed drill is equipped with a control terminal and the electronically regulated seed rate adjustment: See the operating manual for the control computer for additional settings. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 129 19. Empty the calibration troughs. 20. Repeat the steps until the seed housings are completely emptied. 21. Clean hopper chambers and seed housings. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 130: Uncoupling An Implement Coupled As A Solo Implement

    CMS-T-00005795-D.1 There must be enough space between the tractor and implement so that the supply lines can be uncoupled without obstructions. Move the tractor an adequate distance away from the implement. CMS-I-00004045 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 131: Uncoupling The Hydraulic Hose Lines

    1. Unplug the plug connector of the ISOBUS line 1 or the control computer line 2 . 2. Protect the plug with a dust cap. 3. Hook-in the plug connector on the hose cabinet. CMS-I-00006891 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 132: Uncoupling The Power Supply

    Uncouple the implement as specified in the instructions provided in the operating manual of the rotary harrow or in the operating manual of the rotary cultivator. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 133: Maintaining The Implement

    11.81 in (30 cm) between the high- pressure nozzle and the implement. Do not exceed maximum water pressure of 1,740.45 psi (120 bar). Clean the implement with a high-pressure cleaner or a hot water high-pressure cleaner. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 134: Maintaining The Implement

    Every 100 operating hours / Every 12 months Checking the gear oil level See page 134 Every 500 operating hours / Every 3 months Checking the home position of the bottom flaps See page 137 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 135: Checking Rotec Depth Control

    RoTeC depth control disk or RoTeC depth control wheel. 6. Mount the lever 2 with the bolt 1 on the new RoTeC depth control disk or RoTeC depth control wheel 4 . MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 136: Wheels

    Dismount the bolt 2 and dispose of it. 4. Replace the worn furrow former 1 . CMS-I-00004667 NOTE The bolts for the furrow formers are coated and they must not be reused. 5. Mount a new bolt 2 . MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 137: Checking The Cutting Disks

    After the first 50 operating hours As needed 1. Lower the implement. 2. Swing out the loading board steps. To open the seed hopper: Grasp the handle 1 and pull the hopper cover upward. CMS-I-00012085 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 138: Cleaning The C-Drill Hopper

    6. Swing up the loading board steps. CMS-I-00012089 10.2.6 Cleaning the C-Drill hopper CMS-T-00017733-A.1 INTERVAL After the first 50 operating hours As needed 1. Lower the implement. 2. Swing out the loading board steps. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 139 4. Clean seed hopper 2 and fertilizer hopper 1 . CMS-I-00012084 5. Close the hopper with the roller tarpaulin. 6. Use the rubber straps to fix the roller tarpaulin in place on both sides. 7. Swing up the loading board steps. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 140: Checking The Gear Oil Level

    10.2.8 Top up gear oil CMS-T-00017681-A.1 INTERVAL As needed To top-up gear oil: Open the oil filler neck 1 . 2. Top up gear oil. 3. Close the oil filler neck 1 . CMS-I-00012050 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 141: Checking The Top Link Pin And Lower Link Pin

    2. Checking the hydraulic hose lines for leaks. 3. Retighten loose threaded connections. Hydraulic hose lines must not be more than 6 years old. 4. Check the manufacturing date 1 . CMS-I-00000532 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 142: Checking The Furrow Former On The Ws Drag Coulter

    Set the angle B to 40 degrees. If the indicated dimension on a furrow former is less than 0.55 in (14 mm), Replace the furrow former. CMS-I-00006340 To replace the furrow former: Unscrew bolt 1 . CMS-I-00006341 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 143: Checking The Home Position Of The Bottom Flaps

    1. Pull the linch pin 2 . 2. Press the bottom flap lever 1 to the left and place it on value 1 in the hole group. 3. Secure the position with the linch pin. CMS-I-00011668 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 144: Checking The Coulter On The Spring Suspended Tractor Wheel Mark Eradicator

    10.2.13 Checking the coulter on the spring suspended tractor wheel mark eradicator CMS-T-00017793-A.1 INTERVAL Every 50 operating hours Every 3 months If the coulter foot is damaged or severely worn: Replace the coulter foot. CMS-I-00012222 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 145: Check The Coulter On The Reinforced Tractor Wheel Mark Eradicator

    Every 50 operating hours Every 3 months If the distance between the coulter tip and the tool carrier is less than 0.59 in (15 mm), replace the wheel mark eradicator coulter 1 . CMS-I-00008741 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 146 To replace the coulter on the wheel mark eradicator: Remove nuts 2 . 3. Dismount bolts 1 . 4. Replace coulter 3 . 5. Mount the bolts 1 . 6. Mount the nuts 2 . CMS-I-00008740 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 147: Loading The Implement

    11 | Loading the implement Loading the implement CMS-T-00017782-A.1 11.1 Lashing the implement CMS-T-00017784-A.1 The implement has lashing points for securing the load. CMS-I-00012212 CMS-I-00012211 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 148 11 | Loading the implement Lashing the implement CMS-I-00012210 CMS-I-00012209 1. Only attach the slings at the marked positions. 2. Carefully secure the implement on the transport vehicle. CMS-I-00000450 MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 149: Loading The Implement With A Crane

    Depending on the implement equipment, the lashing points for the sling gear may vary. 1. Fasten the appropriate number of sling gear elements specified for the equipment. 2. Slowly lift the implement. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 150: Disposing Of The Implement

    2. Return batteries to the distributor Dispose of batteries at a collection point. 3. Take recyclable materials to recycling points. 4. Treat operating materials like hazardous waste. WORKSHOP TASK 5. Dispose of coolant. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 151: Appendix

    (210 Nm) (250 Nm) 154.89 ft-lb 221.27 ft-lb 261.83 ft-lb (210 Nm) (300 Nm) (355 Nm) 0.94 in (24 mm) 165.95 ft-lb 232.33 ft-lb 280.27 ft-lb M16x1.5 (225 Nm) (315 Nm) (380 Nm) MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 152 6.2 ft-lb (8.4 Nm) 178.49 ft-lb (242 Nm) 15.05 ft-lb (20.4 Nm) 252.25 ft-lb (342 Nm) 30.02 ft-lb (40.7 Nm) 346.65 ft-lb (470 Nm) 52 ft-lb (70.5 Nm) 434.42 ft-lb (589 Nm) MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 153: Other Applicable Documents

    13 | Appendix Other applicable documents 13.2 Other applicable documents CMS-T-00014245-A.1 Tractor operating manual Soil tillage implement operating manual AmaLog software operating manual MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 154: Lists

    Tractor In this operating manual, the designation tractor is always used, even for other agricultural towing machines. Implements are mounted on the tractor or towed by the tractor. MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

  • Page 155: Index

    Bringing the wheel mark eradicator into parking position determine graphically Tramline spacing Digital operating manual Cabinet for connection lines Documents Position Drivable slope inclination calibrating Fertilizer metering unit Metering unit Seed metering unit emptying Hopper Seed housings MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 156 Lower link pin Gear oil checking GewindePack Description manual adjustment Central coulter pressure and placement depth 82 Hopper Metering unit Description calibrating emptying Description Hydraulic adjustment Setting values Coulter pressure or placement depth MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 157 Road safety bars Seed metering unit attaching on the exact following harrow calibrating Description Seed metering wheel combinations for normal seed removing or fine seed Roller contact pressure adjusting adjusting Setting values selecting MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 158 Description Position Working speed securing unfolding Workshop task unlocking WS drag coulter Tractor Description calculating the required tractor characteristics Trailed harrow tines Adjust by dismounting the pins MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...
  • Page 160 AMAZONEN-WERKE H. DREYER SE & Co. KG Postfach 51 49202 Hasbergen-Gaste Germany +49 (0) 5405 501-0 amazone@amazone.de www.amazone.de MG7735-EN-US | A.1 | 16.12.2024 | © AMAZONE...

This manual is also suitable for:

D9 3500 superD9 3000 specialD9 4000 superD9 3000 super

Table of Contents
