TOYOTA
LANDCRUISER
Preparation
Part Number:
PT949-76221 (Dashcam)
Dashcam Kit Contents
Item #
Quantity Reqd.
1
1
2
1
3
1
4
1
5
1
6
2
7
1
Y-Harness Kit Contents
Item #
Quantity Reqd.
1
2
2
4
Additional Items Required for Installation
Item #
Quantity Reqd.
1
1
Conflicts
N/A
Recommended Tools
Personal & Vehicle
Protection
Seat Protection
Dash Protection
Temperature Gauge
Special Tools
GX24-0009
Install Aid
Note: RHS VERSION
Installation Tools
Panel Tool
Socket Wrench
Torque Wrench
Hooked Panel Tool
Needle Nose Pliers
Special Chemicals
VDC Approved Cleaner
General Applicability
All Models
Recommended Sequence of Application
Item #
Accessory
1
Dashcam (PT949-76221)
2
Issue: E 10/01/2024
2024 -
Description
Dashcam Main Unit
SD Card Holder
SD Card (16 GB)
Window Mounting Plate
Foam Tape
Cable Ties
Quick Start Guide
Description
Foam Tape
Cable Ties
Description
PT949-76221 (Dashcam Unit)
Notes
Notes
For Port Installations Only
Check for RHS version,
order new one if required.
The legacy part number
PT949-IAD0Y is also valid
and can be used.
Notes
With 10 mm Socket
With 10 mm Socket
For Sun Visor Clip Removal
Notes
To Clean Windshield
*Mandatory
Page 1 of 15 pages
DASHCAM
Legacy Part Numbers:
Vehicle Service Parts
Item #
Quantity Reqd.
1
Up to 2 pcs
2
3
4
Kit Service Parts
(may be required in future)
Item #
Part Number
1
PT949-76220-AA
2
PT949-60220-AB
3
PT949-60220-AC
4
PT949-08210-AD
Legend
STOP: Damage to the vehicle may occur. Do not
proceed until process has been complied with.
OPERATOR SAFETY: Use caution to avoid risk of
injury.
CAUTION: A process that must be carefully observed
to reduce the risk of damage to the accessory/vehicle
and to ensure a quality installation.
TOOLS & EQUIPMENT: Used in Figures calls out the
specific tools and equipment recommended for this
process.
REVISION MARK: This mark highlights a change in
installation with respect to previous issue.
SAFETY TORQUE: This mark indicates that torque is
related to safety.
REGULATORY MARK: This mark indicates the
component is related to regulatory compliance.
(Digital Video Recorder)
PT949-76220 (Dashcam)
(may be required for reassembly)
Description
Roof Console BLUE Clips if
damage occurs during removal.
P/N: 90467-10167
Description
Camera Unit + SD
SD Card 16GB Industrial
SD Card Holder Assembly
Window Plate with Tape
Advertisement
Related Manuals for Toyota PT949-76221
Summary of Contents for Toyota PT949-76221
- Page 1 Additional Items Required for Installation Item # Quantity Reqd. Description STOP: Damage to the vehicle may occur. Do not PT949-76221 (Dashcam Unit) proceed until process has been complied with. OPERATOR SAFETY: Use caution to avoid risk of Conflicts injury. CAUTION: A process that must be carefully observed...
-
Page 2: Disconnect Battery
Vehicle Disassembly/Reassembly (panel removal, part storage, etc.). Electrical Component Disassembly/Reassembly (battery disconnection, connector removal, etc.). • Please see your Toyota dealer for a copy of this document. 1. Disconnect Battery (a) Protect the fender/bumper before starting. (b) The engine components and coolant may be hot. -
Page 3: Vehicle Protection
TOYOTA LANDCRUISER 2024 - DASHCAM (Digital Video Recorder) Procedure 2. Kit Preparation (a) Check the Dashcam Kits for missing contents or damage. (b) Confirm Camera Angle Position – 5 visible recessed lines should be seen below the lens with the camera held in the as-installed orientation. - Page 4 TOYOTA LANDCRUISER 2024 - DASHCAM (Digital Video Recorder) Procedure 4. Install Windshield Base Plate STOP: The front windshield must be at least 50°F (10°C). (a) On the passenger’s side of the vehicle, using window cleaner and a lint free cloth, clean the windshield area next to the TSS cover.
- Page 5 TOYOTA LANDCRUISER 2024 - DASHCAM (Digital Video Recorder) Procedure For Dealer Installations / No 3D Hard Template Available: (g) Using scissors, cut the paper template as indicated. For PPO Installations, please use the 3D hard template provided. (h) Referencing the TSS cover on the...
- Page 6 TOYOTA LANDCRUISER 2024 - DASHCAM (Digital Video Recorder) Procedure 6. Remove Roof Map Light Console (a) Remove the roof console by first moving the mirror down for clearance (Fig. 6-1), then by pulling down firmly on the forward edge (towards the front of the vehicle).
- Page 7 TOYOTA LANDCRUISER 2024 - DASHCAM (Digital Video Recorder) Procedure 7. Route the Dashcam Harness through the Headliner (a) From the Passenger side of the vehicle, feed the Dashcam’s pigtail harness up into the headliner, directly above the Dashcam mounting plate fixed to the windshield.
- Page 8 TOYOTA LANDCRUISER 2024 - DASHCAM (Digital Video Recorder) Procedure 8. Fitting the Dashcam to Base Plate NOTE: The Hang Tag that is attached to the Dashcam is only to be removed by the end user. As the camera turns on with ignition,...
- Page 9 TOYOTA LANDCRUISER 2024 - DASHCAM (Digital Video Recorder) Procedure (a) Hook the Dashcam wire extension cover hooks into the leading edge of the headliner. (Fig. 8-5) Fig. 8-5 (b) Swing the Dashcam unit up towards the base plate. Check for alignment of the 4 T-hooks.
- Page 10 TOYOTA LANDCRUISER 2024 - DASHCAM (Digital Video Recorder) Procedure 9. Connect the Power Harness (a) Locate the Dashcam Pre-wire harness connector secured on the Passenger’s side of the Map Light Console opening. It is the white 5-pin connector that will appear to be unused.
- Page 11 TOYOTA LANDCRUISER 2024 - DASHCAM (Digital Video Recorder) Procedure 10. Route / Bundle Wire Harness (a) Confirm that the Dashcam Pigtail Harness securely fitted pre-wire connector. Ensure that the Pre-wire connector is still securely mounted in its original location on the headliner plastic frame.
- Page 12 TOYOTA LANDCRUISER 2024 - DASHCAM (Digital Video Recorder) Procedure 11. Reinstall Sun Visor Clips (a) Insert the clip bases on both sides of the map light console, they should snap securely into place. (Fig. 11-1 L) (b) Insert the visor clips by placing them in the correct orientation and pushing them directly up into the bases.
- Page 13 TOYOTA LANDCRUISER 2024 - DASHCAM (Digital Video Recorder) Procedure 13. Reconnect Vehicle Battery (a) Reconnect the Negative Battery Cable Torque Wrench and replace the cover trim if necessary. (b) Torque to 5.4 N•m (48 in•lbsf) (c) CAUTION: Do not touch the positive terminal with any tool.
- Page 14 DASHCAM (Digital Video Recorder) Procedure Page 14 of 15 pages Issue: E 10/01/2024...
- Page 15 TOYOTA LANDCRUISER 2024 - DASHCAM (Digital Video Recorder) Checklist - these points MUST be checked to ensure a quality installation. Check: Look For: Accessory Function Checks Verify parts. Removed items have been discarded & Vehicle Startup replaced items are in place.
