Summary of Contents for LuxenHome WHIF2350
- Page 1 Sideboard Cabinet WHIF2350...
- Page 2 Hey, there Un pack all parts from the packaging inside the carton to ensure there are no missing or damaged parts. Lay out all the parts on a clean,flat, and soft surface to prevent scratches. Refer to the steps provided asassembling guide.
- Page 3 Middle support Right side panel Left shelf panel Right shelf panel Left side panel panel Bottom panel Lower back panel Connecting strip Upper back panel Top panel First on the left First on the right Second on the left Second on the right door panel door panel door panel...
- Page 4 X 12+2 X 12+2 X 16+2 X 32+3 M3.5 x 14mm M5 x 40mm M7 x 39mm M15 x 12mm M8 x 30mm X 20+3 Metal Plate Adjustable foot nail Middle Leg Handle with screws M4 x 14mm X 16+2 Hinge Hinge M8 x 50mm...
- Page 6 M7 x 39mm Insert qucikfit screws (A) and wooden dowels (C) into parts 1, 2 and 3 as shown. Cx12 M8 x 30mm Insert wooden dowels (C) and (O) into parts 4 and 5 as shown. M8 x 30mm M8 x 50mm...
- Page 7 Insert cam locks (B) to part 4.Turn cam locks clockwise to tighten,attach parts 1 and 4. Attach parts 2 to part 4 using screws (E) as shown. M15 x 12mm M5 x 40mm Step 4 Insert cam locks (B) to part 5. Attach parts 3 and 5 to parts 1, 2 and 4 as shown. Turn cam locks clockwise to tighten.
- Page 8 Step 5 Gx20 Attach (H) to parts 6 using screws (G) as shown. M4 x 14mm Step 6 Attach part 6 to parts 1, 2 and 3 using screws (P) as shown. M5 x 50mm...
- Page 9 Step 7 Attach the legs (K) to the four corners of part 6 by screwing it into (H). Screw center leg (J) directly to part 6. Add adjustable foot nail(I) to Leg (J) ,screw it on until secure as shown. Jx 1 Step 8 Carefully flip the cabinet right side up.
- Page 10 Step 9 Insert quickfit screws (A) into part 10, Fix wall brackets (Q) on part 10 as shown. M7 x 39mm Warning : To avoid scratch , palce the panels on clean and soft surface. Step 10 Insert cam locks (B) into parts 1, 2 and 3. Fit part 10 to parts 1, 2 and 3.Turn cam locks clockwise to tighten as shown.
- Page 11 Step 11 Fix handles (F) to doors 11 and 12 using screws (F) as shown. Fix hinges (L) to doors 11 and 12 using screws (D) as shown. M3.5 x 14mm F x2 L x4 Step 12 Fix handles (F) to doors 13 and 14 using screws (F) as shown. Fix hinges (M) to doors 13 and 14 using screws (D) as shown.
- Page 12 Step 13 Put the cabinet backwards down carefully. Fix doors 12 and 13 to the assembled unit using hinges (L) and (M) with screws (D) as shown. M3.5 x 14mm Step 14 Fix doors 11 and 14 to the assembled unit using hinges (L) and (M) with screws (D) as shown.
- Page 13 Step 1 Nx16 Carefully flip the cabinet right side up. Secure backing panels 7 and 9 by fixing wedges (N) using screws (N) and (R) as shown. ATTENTION PLEASE Please ensure the structure is straight and level and all panels are at right angles before installing hardware (N).
- Page 14 Step 1 Adjust the door up and down by loosening and tightening the screws in the vertical position. Adjust the door front and back with the left screw in the horizontal position. Adjust the door left and right with the right screw in the horizontal position.
- Page 15 Step For additional stability, secure the cabinet to the wall using the restraint kit included.
- Page 16 VOILA! DO NOT climb, sit, or stand on the Cabinet as this may damage the product and cause serious bodily injury.
- Page 17 Something not right Things to do to expedite the process...
