Product Name:
SKU #:
Thank you for purchasing this LuxenHöme product. This product has been manufactured with the highest
standards of safety and quality.
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY.
Unpack all parts from the packaging inside the carton to ensure there are no missing or damaged parts. Lay out
all the chair parts on a clean, flat, and soft surface to prevent scratches. Refer to the steps provided as
assembling guide.
Do not attempt to assemble or use the product if any parts are missing or damaged.
CARTON CONTENTS:
Hardware:
Upholstered Club Swivel Chair with Base
WHIF2117
Please save this manual for future reference.
Instruction Manual
Advertisement
Related Manuals for LuxenHome WHIF2117
Summary of Contents for LuxenHome WHIF2117
- Page 1 Please save this manual for future reference. Product Name: Upholstered Club Swivel Chair with Base SKU #: WHIF2117 Thank you for purchasing this LuxenHöme product. This product has been manufactured with the highest standards of safety and quality. PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY.
- Page 2 Instruction Manual Please save this manual for future reference. Product Name: Upholstered Club Swivel Chair with Base SKU #: WHIF2117 Chair Parts: Tools required for assembly: Allen Wrench (if using power tools, use with care)
- Page 3 Instruction Manual Please save this manual for future reference. Product Name: Upholstered Club Swivel Chair with Base SKU #: WHIF2117 Assembly:...
- Page 4 Instruction Manual Please save this manual for future reference. Product Name: Upholstered Club Swivel Chair with Base SKU #: WHIF2117 Step 1 – Connect the Parts (A) and (C) to the Part (B) as shown.
- Page 5 Please save this manual for future reference. Product Name: Upholstered Club Swivel Chair with Base SKU #: WHIF2117 Step 2: Screw the Bolts (Part 2) into the screw holes on the bottoms of the Back frame from step 1 as shown.
- Page 6 Upholstered Club Swivel Chair with Base SKU #: WHIF2117 Step 3: Connect the Assembly from step 2 to the Seat base frame (Part D) with the Bolts M8X60mm (Part 2), the Flat washer (Part 4), the nuts (Part 5) and the Spring washer (Part 6) using the Socket wrench (Part 8).
- Page 7 Product Name: Upholstered Club Swivel Chair with Base SKU #: WHIF2117 Step 4: Attach the Wood leg base (Part E) to the assembly from step 3, using Bolts (Part 3) and Flat Washers (Part 4). Note: Loosely attach the bolts one by one and keep them loose. Do not fully tighten. After all 3 bolts are...
- Page 8 Please save this manual for future reference. Product Name: Upholstered Club Swivel Chair with Base SKU #: WHIF2117 Step 5: Attach the Swivel plate (I) to the Metal leg (J) using Bolts (1), tighten with the M5 Allen Wrench (7).
- Page 9 Please save this manual for future reference. Product Name: Upholstered Club Swivel Chair with Base SKU #: WHIF2117 Step 6: Attach the metal base from step 5 to the assembly from step 4 using Bolts (1) tighten with the M5 Allen Wrench (7).
- Page 10 Instruction Manual Please save this manual for future reference. Product Name: Upholstered Club Swivel Chair with Base SKU #: WHIF2117 Step 7: Put the cloth (F) cover on the chair assembled from step 6 as show then attach the Velcro.
- Page 11 Instruction Manual Please save this manual for future reference. Product Name: Upholstered Club Swivel Chair with Base SKU #: WHIF2117 Step 8: Attach the Seat Cushion into the Seat base then Lay the back cushion on the seat back as shown.
- Page 12 Please save this manual for future reference. Product Name: Upholstered Club Swivel Chair with Base SKU #: WHIF2117 Assembly complete. Take a spin and enjoy！ Warning: DO NOT stand on the chair as this may damage the product and cause serious bodily injury.
