- Page 1 Columbia Bachelor Chest SKU WHIF2251 60 min. assembly 2 person C:\Users\Nur Salam\Downloads\TIME.png A S S E M B L Y I N S T R U C T I O N S * The estimated assembly time may vary depending on the individual.
-
Page 2: Tools Required
Hey,there Now is assembly time! Thank you for purchasing this LuxenHome product. This product has been manufactured with the highest Deeeeeep breathe..and again..standards of safety and quality. Tools ready, Easy peasy! PLEA E READ ALL IN TRU TION... - Page 3 Furniture components: 1 Top Panel x1 2 Bottom Panel x1 3 Side Panel (L) x1 4 Side Panel (R) x1 5 Back Support & Internal Support Panel x3 6 Back Mdf Board (A) x2 7 Back Mdf Board (B) x1 8 Leg Panel x1 1st Drawer Face Panel x1 2nd &...
- Page 4 Step 1 HARDWARE : A Cam Pin x8 COMPONENTS : 1 Top Panel x1 2 Bottom Panel x1 Installation Cam Pin: Please insert the screw on panel using a screwdriver. Step 2 HARDWARE : F1 Drawer Slide 12" CL x5 F2 Drawer Slide 12"...
- Page 5 Step 3 HARDWARE : Cam Pin x6 B Cam Lock x8 C Wood Dowel M8x30MM x8 COMPONENTS : 3 Side Panel (L) x1 4 Side Panel (R) x1 Installation Cam Pin: Installation Wood Dowel: Please insert the screw As Shown, Please using the hammer to insert on panel using a screwdriver.
- Page 6 Step 5 HARDWARE : A Cam Pin x10 G1 Pvc Handle x5 G2 Screw M4x28MM x5 COMPONENTS : 1st Drawer Face Panel x1 2nd & 4th Drawer Face Panel x2 3th Drawer Face Panel x1 12 5th Drawer Face Panel x1 Installation Cam Pin: Please insert the screw on panel using a screwdriver.
- Page 7 Step 7 Installation: HARDWARE : As shown, the head of minifix housing goes into the open mouth of the mini fix bolt. I Allen Key x1 Use Allen Key then turn the minifix housing so it tightens over the mini fix bolt. COMPONENTS : 2 Bottom Panel x1 Step 8...
- Page 8 Step 9 COMPONENTS : 6 Back Mdf Board (A) x2 7 Back Mdf Board (B) x1 Installing the Back MDF Board: Insert MDF Board: Slide the MDF Board into the panel. Step 10 HARDWARE : I Allen Key x1 Installation: COMPONENTS : As shown, the head of minifix housing goes into the open mouth of the mini fix bolt.
- Page 9 Step 11 HARDWARE : J1 Stub x6 J2 Screw M3x20MM x6 Installation Screw: Please insert (J1) inside the groove fasten it with screw (J2). Step 12 HARDWARE : J Screw M3.5x16MM x16 Installation Screw: Please insert the screw (J) on panel using a screwdriver. Please save this manual for future reference.
- Page 10 Step 13 HARDWARE : E Screw M4x38MM x30 COMPONENTS : 13 Drawer Side Panel (L) x5 14 Drawer Side Panel (R) x5 15 Drawer Back Panel x5 16 Drawer Support Panel x5 17 Drawer Mdf Board x5 Installation Screw: Please insert the screw (E) on panel using a screwdriver.
- Page 11 Step 14 HARDWARE : I Allen Key x1 COMPONENTS : 1st Drawer Face Panel x1 2nd & 4th Drawer Face Panel x2 3th Drawer Face Panel x1 12 5th Drawer Face Panel x1 Installation: As shown, the head of minifix housing goes into the open mouth of the mini fix bolt.
- Page 12 Step 15 HARDWARE : F1 Drawer Slide 12" DL x5 F2 Drawer Slide 12" DR x5 F3 Screw M3.5x12MM x30 # Make sure the non- Touch wheeled part of the drawer is touching the front of the drawer. # Screws in holes a, b and c.
- Page 13 Step 16 COMPONENTS : 1st Drawer Face Panel x1 2nd & 4th Drawer Face Panel x2 3th Drawer Face Panel x1 12 5th Drawer Face Panel x1 Step 17 Please save this manual for future reference.
- Page 14 VOILA! Now enjoy. Warning !!! DO NOT stand or climb on this chest as they may cause damage to the product and cause serious bodily injury. Please save this manual for future reference.
- Page 15 If you experience any dissatisfaction, feel free to contact us immediately. Our in-house customer care team will respond ASAP. customerservice@luxenhome.com · Things to do to Get response within 24 hrs expedite the process 909.548.6688...
- Page 16 Happy with our product? Leave us a review Share with others It really help us as a small business Our customers look for REAL stuff Find the product you purchased on · Follow us on IG @luxen.home our website (tip: search by SKU) ·...
