XGS-ONU-25-20NI CONFIGURATION GUIDE
XGS-ONU-25-20NI
Configuration Guide
XGS- ONU-2 5 - 20 NI
www.fs.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XGS-ONU-25-20NI and is the answer not in the manual?

Questions and answers

Related Manuals for FS XGS-ONU-25-20NI

Summary of Contents for FS XGS-ONU-25-20NI

  • Page 1 XGS-ONU-25-20NI CONFIGURATION GUIDE XGS-ONU-25-20NI Configuration Guide XGS- ONU-2 5 - 20 NI www.fs.com...

  • Page 2: Table Of Contents

    4. Mirror function --------------------------------------------------------------------------------------------------------- 30 5 .Common service debug information --------------------------------------------------------------------- 30 5. 1 Check general traffic configure ---------------------------------------------------------------------------------- 30 5.2 Check detail traffic configure --------------------------------------------------------------------------------- 31 5.3 Check IPTV configure ----------------------------------------------------------------------------------------- 31 5.4 Check traffic PM --------------------------------------------------------------------------------------------------- 32 www.fs.com...

  • Page 3: Introduction

    Section 2 : Provide the way to change local access settings Section 3 : List the most common commands Section 4 : Explain local software image upgrade and switch Section 5 : Provide the way to OMCI mib command Section 6 : Common service debug information www.fs.com...

  • Page 4: How To Telnet

    PC connection ont port 1 with cable ， The manager IP Addr is : 1 9 2 . 1 6 8 . 1 0 0 . 1 Steps 1 Set local IP address manually on laptop Steps 2 Ping Default Gateway IP 192.168.100.1 Note: If you need the account and password, please contact FS. www.fs.com...
  • Page 5 XGS-ONU-25-20NI CONFIGURATION GUIDE Steps 3 telent to ONT, username is “xxxxxx” . Steps 4 The password is “xxxxxx” . Steps 5 Input “enable” to enter configure mode www.fs.com...

  • Page 6: Ont Local Commands

    XGS-ONU-25-20NI CONFIGURATION GUIDE 2. Ont local commands Here we list the most common commands for testing and troubleshooting. 2 .1 Hardware and Software information 2.1.1 Software version The command to check ont version [ Command] / system/ ontver Example: # ONT>/ system/ontver OntSwVer : R4.4.20.016...

  • Page 7: Stopreboot Command

    XGS- ONU-2 5 - 2 0 NI CONFIGURATION GUIDE 2.1.3 Stopreboot command When ont abnormal, ont reboot all the time, the command can interrupt to reboot [ Command] # ONT/ system/ misc> stopreboot Example: # ONT/ system/ misc> stopreboot Stop reboot command OK www.fs.com...

  • Page 8: Optics Parameters

    XGS-ONU-25-20NI CONFIGURATION GUIDE 2.2 Optics Parameters 2 . 2 . 1 Optics monitoring information To check optics monitor info [ Command] / system/ misc/ show trans state Example: # ONT/ system/ misc> show trans state Power : 3V3 (3 .3) Temperature : 45.0 C...

  • Page 9: Traffic Table

    XGS-ONU-25-20NI CONFIGURATION GUIDE TO1: 80000 TO2: eqd: 617219 Serial Number( vendor code) : GPON Serial Number( sn) : 2 2 7 0 0 0 fe Password: 41 42 43 44 45 46 47 48 49 4a Registration ID: 0x44454641554c54000000000000000000000000000000000000000000000000 0000000000 ------------------------- INFO END -------------------------- # ONT/traffic/ pon>...

  • Page 10: Service Connection

    XGS-ONU-25-20NI CONFIGURATION GUIDE 2.3.4 Service Connection The check service connection info about bridge port [ Command] / traffic/ omci/ show connection all Example: # ONT/ traffic/ omci> show connection all ---------------------- Connection ID = 0 ---------------------- Completed = 1, Bridge Id = 0x0a01, valid = 1...
  • Page 11 XGS-ONU-25-20NI CONFIGURATION GUIDE Service Connection( Debug Mode) This command show the configuration of EMR from MEC [ Command] / traffic/ omci/ debug/ showemrcfg [ Connection ID] Example: # ONT/ traffic/ omci/ debug> showemrcfg 0 Connection ID = 0 UNI Configuration: <...

  • Page 12: Performance Counters

    XGS-ONU-25-20NI CONFIGURATION GUIDE < Ds Flow Id = 1, Us Flow Id = 1, Serv Type = ETH | > ** Vlan Op: US MODE: Replace VID with the old PRI OLD (0x2BE, ALL_ PRI) -> NEW (0x2BE, ALL_ PRI) DS MODE: Replace VID with the old PRI OLD (0x2BE, ALL_ PRI) ->...

  • Page 13: Ethernet Service

    XGS-ONU-25-20NI CONFIGURATION GUIDE --------------port 65534 flow 0030---------------- RX GEM frames 153448 RX GEM bytes 196619932 Tx GEM frames Tx GEM bytes # ONT/ traffic/ pon> 2.4 Ethernet service 2.4 . 1 UNI port information To check Ethernet port physical link [ Command] # ONT/ traffic/ eth>show pack...

  • Page 14: Igmp Information

    XGS-ONU-25-20NI CONFIGURATION GUIDE EmrMcastGemVlanOp En : 1 g EmrSaveConnItemEn g EmrMcastCrossVlanEn : 1 EmrUniExtractPriMatch : 1 EMR_ DRV_ PACK_ DUMP_ITEM _EN : 0 ** * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * # ONT/traffic/ eth>...
  • Page 15 XGS-ONU-25-20NI CONFIGURATION GUIDE QQIC( ms) LMQI( ms) MaxResp( ms) v2DefCfg 2 125000 1000 10000 v2RunCfg 0 v3DefCfg 2 125000 1000 10000 v3RunCfg 2 125000 10000 v3GSCfg 0 index Group(all 11 ) | portmask | age (sec) [000] ff02:0000:0000:0000:0000:0000:0000:000c 0x0000000b IP...
  • Page 16 XGS-ONU-25-20NI CONFIGURATION GUIDE Rx MLDV1Join Tx MLDV1Join Tx MLDV1done Rx MLDV2Join Tx MLDV2Join Rx MLDV2done Tx MLDV2done TxV2Join RxV3Join TxV3Join RxV3Leave GroupErr # ONT/ traffic/ eth>show IGMP uni To check IGMP all UNI configuration [ Command] / traffic/ eth/ show igmp uni Example: # ONT/ traffic/ eth>...

  • Page 17: Performance Counter

    XGS-ONU-25-20NI CONFIGURATION GUIDE l port 3 | maxGroup 128 | curGroup 8 | aclNum 0 | maxBw 0 | exceedDeny 0 | curBw 0 l port 4 | maxGroup 128 | curGroup 0 | aclNum 0 | maxBw 0 | exceedDeny 0...
  • Page 18 XGS-ONU-25-20NI CONFIGURATION GUIDE impaired blocks : 0x00000000 tx packets : 0x00000000 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
  • Page 19 XGS-ONU-25-20NI CONFIGURATION GUIDE ALU pm data me id: 0xffff lost DS packets : 0x00000000 lost US packets : 0 x000 00 00 0 rx packets : 0x00000000 blocks : 0x00000000 tx blocks : 0x00000000 impaired blocks : 0 x00 0 0 0 0 0 0...

  • Page 20: System Log

    XGS-ONU-25-20NI CONFIGURATION GUIDE UNI slot 10 port 1 PM == = = = = = Counters for phyport[4 ] = = = = = = = ifInOctets 48139 ifInUcastPkts ifIn MulticastPkts ifOutOctets 37430 ifOutUcastPkts Tx Pkts64Octets Tx Pkts65 to127 Octets...
  • Page 21 XGS-ONU-25-20NI CONFIGURATION GUIDE c7f3e0f4 28 pmr_ handler_gpo 58 9 4 rcv MEC_MSG_ACTIVATE_ PACK, result = 0 4 state transtion: 1 --> 3 event[assign c7f3e6c7 29 pmr_ event_ corti 30 3 onu_id message] 4 report state transtion: In it --> c7f3e6c7...

  • Page 22: Pon Manager Driver

    XGS-ONU-25-20NI CONFIGURATION GUIDE c8008d91 3e pmr_handler_gpo 663 4 rcv PON_ MSG_CFG_ DS_ FLOW act Rem, result = 1 c8008dcd 3e pmr_handler_gpo 663 4 rcv PON_ MSG_CFG_ DS_ FLOW act Add, result = 0 c8 0 08dce 3e pmr_handler_gpo 689 4 rcv PON_ MSG_CFG_ US_ FLOW act...

  • Page 23: Misc Manager

    XGS-ONU-25-20NI CONFIGURATION GUIDE c7f3 d3c4 25 pmr_pack_cortin 396 4 serial number: 46 54 52 30 20 21 07 14 c7f3d3c4 25 pmr_pack_cortin 421 4 passward: 00 00 00 00 00 00 00 00 00 00 28 pmr_ pack_ cortin 44 1...

  • Page 24: Downstream Ploam

    XGS-ONU-25-20NI CONFIGURATION GUIDE tick upTime1 file line level message emr_ main. c 7847 4 Send ACK message to 0x90009 , c8009325 result -1 , send 0 emr_ main.c 7764 4 EMR_ MSG_CFG_UNI_ PKT_ LIMIT c800932c emr_ main.c 7288 4 Config SLOT 14 PORT 1, c800932c uniP ktLimit.
  • Page 25 XGS-ONU-25-20NI CONFIGURATION GUIDE 4 ONU- ID= 0 x 3 ff, Type= Assign ONU- pmr_event_corti c7f42982 ID[0x03]: pmr_event_corti 00 00 46 54 52 30 20 21 07 14 c7f42982 01 00 pmr_event_corti c7f42982 00 00 00 00 00 00 00 00 00 00...

  • Page 26: Omci Log

    XGS-ONU-25-20NI CONFIGURATION GUIDE c7f43452 3d pmr_event_corti 422 04 01 01 00 00 00 00 00 00 00 00 00 c7f43452 3d pmr_event_corti 422 00 00 00 00 00 00 00 00 00 00 00 00 c7f43452 3d pmr_event_corti 422 00 00 00 00 00 00 00 00 00 00 00 00 2.5.6 OMCI log...
  • Page 27 XGS-ONU-25-20NI CONFIGURATION GUIDE c7f433ba omci_msg.c 551 4 Send out OMCI msg omci_msg.c 172 4 tick: 0x11 ea0ff6 PRI: 0, TI: 0x1359 , c7f433ba DID: 10, DB: 0, AR: 0, AK: 1, MT: 14, Class: 2, inst: 0x0 c7f433ba omci_msg.c 178...

  • Page 28: Mec Log

    XGS-ONU-25-20NI CONFIGURATION GUIDE 2 . 5 . 7 MEC log To check implement of OMCI message [ Command] / system/ log/ show mec Example: # ONT/ system/ log> show mec Log: mec tick upTime1 file line level message c7f3 bf0 b mec_ main.

  • Page 29: Omci Mib

    XGS-ONU-25-20NI CONFIGURATION GUIDE mec_ main.c 1334 4 Misc Manager is ready c7f3c2ae main. c 1285 4 Pon Manager is ready c7f3c6e1 main. c 1344 Net Manager is ready c7f3ca66 main. c 1305 4 Voip Manager is ready c7f3cb2c mec_ main.c 1295...

  • Page 30: Mib Show Cli

    XGS-ONU-25-20NI CONFIGURATION GUIDE 3 .3 MIB show CLI Usage: show CLASSID CLASSID: the class ID of the ME, defined in 983.2/ 984.4, currently the following MEs are supported: [ Command] / s/ m/ show ID Example: # ONT/ system/ mib>show 45...

  • Page 31: Check Detail Traffic Configure

    XGS-ONU-25-20NI CONFIGURATION GUIDE / traffic/ pon/ show link / traffic/ omci/debug/ show 0 / traffic/ eth/show connect all / traffic/ pon/ show link / traffic/ eth/show pack / s/ s/ifconfig / system/ misc/ eqsn get / system/ misc/ show trans state...

  • Page 32: Check Traffic Pm

    XGS-ONU-25-20NI CONFIGURATION GUIDE / system/ misc/ show trans state/ s/ log/ show omci / s/log/ show mec / s/log/ show emr / s/log/ show pmr / s/log/ show pmr_drv / s/log/ show mec_fm / s/log/ show us_ ploam / s/log/ show ds_ ploam...
