Chamberlain SECURITY+ WPB1LM3 Manual

®
Overview
The Wireless Single Pushbutton Control is designed
to be used with an existing Gate Access System. The
Pushbutton Control allows user to exit through gate
by pushing the button.
Carton Inventory
Pushbutton Control
Assembly
Install 4 AA Alkaline batteries (not provided). (Lithium
batteries recommended for colder environments.)
Keypad will beep.
Keypad will continuously beep indicating no Master
PIN Number has been programmed. Proceed to
Initial Setup.
Bolt (4)
Screw (4)
Washer (4)
Allen Wrench
Nut (4)
Wireless Single Pushbutton Control
Initial Setup
Program Pre-Installed LiftMaster Receiver
Step 1: Pry open the front panel of
the receiver case with a coin or a
screwdriver.
Step 2: Press and release the
Learn button on the receiver.
The Indicator Light will light for
30 seconds indicating that
receiver is in Learn Mode.
Step 3: Within 30 seconds, press
and hold the Learn button on the
single pushbutton control for 2 seconds.
Repeat Steps 2-3 for each remote, or control device
that will be used to access the Liftmaster door or gate
operator.
Erase All Control Codes
Press and hold the Learn button on the receiver until
the Indicator Light turns off indicating that the receiver
memory is clear (about 6 seconds).
Mount Pushbutton Control
It is recommended that Pushbutton Control be
mounted to a Gooseneck post or non-metallic
surface.
Step 1: Choose mounting location for Pushbutton
Control. Remove the back panel and attach it to a
solid surface or post.
Step 2: Mount the Pushbutton Control onto the back
panel with screws. Tighten screws with Allen wrench.
Operation
Push button on Pushbutton Control to exit.
Clear Memory: Press the Learn button until a beep is
heard.
1
Model WPB1LM3
Indicator Light
Learn Button
