Model No. PFEX52921-INT.0
Serial No.
USER'S MANUAL
Write the serial number in the space
above for reference.
Serial Number
Decal
MEMBER CARE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4, Westgate Court
Silkwood Park
OSSETT
WF5 9TT
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
iFIT Inc.
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
iconeurope.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO C10U and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pro-Form PRO C10U

Summary of Contents for Pro-Form PRO C10U

  • Page 1 Model No. PFEX52921-INT.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal MEMBER CARE UNITED KINGDOM Call: 0330 123 1045 From Ireland: 053 92 36102 Website: iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 4, Westgate Court Silkwood Park OSSETT...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your exercise bike before using your exercise bike. iFIT assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    The endurance, and toning the body. The PRO C10U exer- model number and the location of the serial number cise bike provides an impressive selection of features decal are shown on the front cover of this manual.

  • Page 5: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.

  • Page 6: Assembly

    ASSEMBLY • Assembly requires two persons. • In addition to the included tool(s), assembly requires the following tools: • Place all parts in a cleared area and remove the one Phillips screwdriver packing materials. Do not dispose of the packing materials until you fi...
  • Page 7 2. Using a standard screwdriver, carefully pry the Shield Cover (26) off the Left and Right Shields (37, 58). If there is a shipping tube (not shown) on the rear of the Frame (1), remove the screws from the shipping tube, and discard the screws and 37, 58 the shipping tube.
  • Page 8 4. Set the Seat Carriage (15) on the Seat Post (18) and hold it in place. Insert the Seat Knob (19) upward into the Seat Post (18), and tighten the Seat Knob into the Seat Bracket (14) inside the Seat Carriage (15). 5.
  • Page 9 6. Tip: Avoid pinching the Main Wire (25). Orient the Upright (27) as shown, and hold it on the Frame (1). Attach the Upright (27) with four M8 x 20mm Screws (29); start all the Screws, and then tighten them. Avoid pinching the Main Wire (25) 7.
  • Page 10 8. Orient the Shield Cover (26) as shown, and press it onto the Left and Right Shields (37, 58). 37, 58 9. Orient the Console Cover (3) as shown, and slide it onto the Upright (27). Tip: Avoid pinching the Main Wire (25). Insert the Handlebar (4) into the Upright (27).
  • Page 11 10. Untie and discard the wire tie on the Main Wire (25). Then, route the Main Wire upward through the Handlebar (4) as shown. While a second person holds the Console (7) near the Handlebar (4), connect the wire on the Console to the Main Wire (25).
  • Page 12 12. Slide the Console Cover (3) upward to the Handlebar (4). Attach the Console Cover to the Handlebar and to the Console (7) with two M4 x 16mm Screws (2). 13. Identify the Right Pedal (60). Using your fingers, turn the Right Pedal about halfway into the Right Crank Arm (59).
  • Page 13 14. Plug the Power Adapter (30) into the receptacle on the front of the exercise bike. Note: To plug the Power Adapter (30) into an outlet, see HOW TO PLUG IN THE POWER ADAPTER on page 14. 15. After the exercise bike is assembled, inspect it to make sure that it is assembled correctly, that it functions properly, and that all parts are properly tightened.

  • Page 14: How To Use The Exercise Bike

    HOW TO USE THE EXERCISE BIKE HOW TO PLUG IN THE POWER ADAPTER HOW TO ADJUST THE HEIGHT OF THE SEAT IMPORTANT: If the exercise bike has been exposed For effective exercise, the seat should be at the proper to cold temperatures, allow it to warm to room tem- height.
  • Page 15 HOW TO ADJUST THE PEDAL STRAPS THE OPTIONAL TABLET HOLDER To adjust the The optional tablet pedal straps, first holder (G) will pull the ends of hold your tablet the straps (E) off securely in place the tabs (F) on and enable you the pedals.

  • Page 16: How To Use The Console

    HOW TO USE THE CONSOLE CONSOLE DIAGRAM FEATURES OF THE CONSOLE When you use the manual mode of the console, you can change the resistance of the pedals with the touch The advanced console offers an array of features of a button. designed to make your workouts more effective and enjoyable.

  • Page 17: How To Use The Touch Screen

    HOW TO TURN ON THE CONSOLE HOW TO SET UP THE CONSOLE The included power adapter must be used to operate Before you use the exercise bike for the first time, set the exercise bike. See HOW TO PLUG IN THE up the console.

  • Page 18: How To Use The Manual Mode

    HOW TO USE THE MANUAL MODE Touch the various workout information displays to view more options. Touch the more button 1. Touch the screen or press any button on the (+ symbol) to view statistics or charts. Touch the console to turn on the console. screen in any open space to view even more dis- play mode options.
  • Page 19 6. Turn on the fan if desired. THE OPTIONAL HEART RATE MONITOR The fan has several speed Whether your settings, including an auto goal is to mode. While the auto mode burn fat or to is selected, the speed of strengthen your the fan will automatically cardiovascular...
  • Page 20 HOW TO USE A FEATURED WORKOUT When you select a workout, the screen will show an overview of the workout that includes details To use a featured workout, the console must be con- such as the duration and distance of the workout nected to a wireless network (see HOW TO CONNECT and the approximate number of calories you will TO A WIRELESS NETWORK on page 26).
  • Page 21 IMPORTANT: The calorie goal shown in the 5. Wear headphones if desired. workout description is an estimate of the number of calories that you will burn during To connect your headphones to the console, first the workout. The actual number of calories that turn on your headphones, place them in pairing you burn will depend on various factors, such mode, and place them near the console.
  • Page 22 HOW TO CREATE A DRAW-YOUR-OWN-MAP If you make a mistake, touch Undo in the map WORKOUT options. 1. Touch the screen or press any button on the The screen will display the elevation and distance console to turn on the console. statistics for your workout.
  • Page 23 HOW TO USE AN IFIT WORKOUT 4. Select an iFIT workout from the home screen or the workout library. To use an iFIT workout, you must be logged into your iFIT account (see step 3 below) and the console Touch the buttons at the bottom of the screen to must be connected to a wireless network (see HOW select either the home screen (Home button) or the TO CONNECT TO A WIRELESS NETWORK on...
  • Page 24 6. Create a list of favorite iFIT workouts if desired. When your headphones and the console pair successfully, the audio from the console will play To mark an iFIT workout as a favorite, simply view through your headphones. the overview or workout summary of the desired iFIT workout and touch the favorites button (heart 9.
  • Page 25 HOW TO CHANGE CONSOLE SETTINGS Equipment • Equipment Info IMPORTANT: Firmware updates are always • Equipment Settings designed to improve your exercise experience. As a • Maintenance result, new settings and features may not be described • Wi-Fi in this manual. Take time to explore the console to learn how new settings and features work.
  • Page 26 The screen will show the progress of the update. 3. Enable Wi-Fi. When the update is complete, the console will turn off and then turn back on. If it does not, unplug the Make sure that Wi-Fi ® is enabled. If it is not power adapter, wait for several seconds, and then enabled, touch the Wi-Fi toggle to enable it.

  • Page 27: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE If a replacement power adapter is needed, call the telephone number on the cover of this manual. Regular maintenance is important for optimal IMPORTANT: To avoid damaging the console, use performance and to reduce wear. Inspect and properly only a manufacturer-supplied regulated power tighten all parts each time the exercise bike is used.
  • Page 28 HOW TO ADJUST THE REED SWITCH HOW TO ADJUST THE DRIVE BELT If the console does not display correct feedback, the If you can feel the pedals slip while you are pedaling, reed switch should be adjusted. even when the resistance is adjusted to the highest level, the drive belt may need to be adjusted.

  • Page 29: Exercise Guidelines

    EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.

  • Page 30: Part List

    PART LIST Model No. PFEX52921-INT.0 R0921A Key No. Qty. Description Key No. Qty. Description Frame Crank Cap M4 x 16mm Screw Crank Nut Console Cover Left Crank Arm Handlebar M4 x 19mm Self-tapping Screw Handlebar Cap Left Shield Wheel Snap Ring Console Bearing Front Stabilizer...

  • Page 31: Exploded Drawing

    EXPLODED DRAWING Model No. PFEX52921-INT.0 R0921A...

  • Page 32: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
