- Page 1 AIG-502 Series Quick Installation Guide Version 1.0, September 2024 Technical Support Contact Information www.moxa.com/support 2024 Moxa Inc. All rights reserved. P/N: 1802005020000 *1802005020000*...
-
Page 2: Package Checklist
Overview The AIG-502 Series computers are built around a 7th Gen Intel® Core™ i7 processor and come with 1 HDMI display port, 3 USB 3.0 ports, 2 Gigabit LAN ports, and 2 3-in-1 RS-232/422/485 serial ports. The AIG-502 is also equipped with a 2.5” HDD/SSD slot and a built-in TPM 2.0 module. -
Page 3: Led Indicators
Top View Bottom View LED Indicators The following table describes the function of the LED indicators located on the front panel of the AIG-502: LED Name Status Description Power Power is on and computer is Green functioning normally Power is off Storage 1 (mSATA) Yellow Blinking: Data is being transmitted No data transmission. -
Page 4: Din Rail Mounting
Installing the AIG-502 DIN-rail Mounting The AIG-502 comes with a DIN-rail mounting kit. To install the DIN-rail mounting kit and mount the AIG-502 on to a DIN rail, do the following: STEP 1: Use the 4 screws included with the kit to attach the DIN-rail mounting bracket to the AIG-502’s rear panel and tighten the screws to secure the bracket. - Page 5 Wall Mounting The AIG-502 can be installed on a wall by using the optional wall- mounting kit. NOTE The wall-mounting kit is not included in the package and must be purchased separately. STEP 1: Use three screws for each bracket and attach the brackets to the rear of the AIG- 502.
-
Page 6: Connector Descriptions
Connector Descriptions Power Connector Use an Listed Power Supply (LPS, 9 to 36 VDC) or Class 2 power cord to connect to the AIG-502's terminal block to power jack converter and then turn on the power. The Power LED will light up to indicate that the power is supplied properly. - Page 7 Ethernet Ports The 10/100/1000 Mbps Ethernet ports use RJ45 connectors. The pin diagrams for the ports are shown below: 10/100 Mbps 1000 Mbps ETx+ TRD(0)+ ETx- TRD(0)- ERx+ TRD(1)+ – TRD(2)+ – TRD(2)- ERx- TRD(1)- – TRD(3)+ – TRD(3)- Serial Ports The serial ports use DB9 connectors.
- Page 8 Installing Communications Modules The AIG-502 Series comes with three sockets for installing various communications modules. Unfasten the screws on the right side of the computer and remove the cover to find the locations of these sockets as shown below: AIG-502-T-AZU-LX:...
-
Page 9: Installing The Wi-Fi Module
Installing the Wi-Fi Module You can install up to two Wi-Fi/cellular modules for wireless communication. Wi-Fi Module Package The contents of the Wi-Fi module package are shown below: Follow these steps to install the Wi-Fi module for your AIG-502. 1. Attach the Wi-Fi module to the mounting plate with two screws. - Page 10 3. Place the heat sink with the thermal pad at the center of the wireless module socket. 4. Insert the Wi-Fi module (with the mounting plate) into the socket and fasten the two black screws on the mounting plate to secure it. 5.
- Page 11 7. Connect the Wi-Fi antenna to the connector on the front panel. 8. Use the above method to connect another Wi-Fi antenna, if necessary. 9. 9eattach the right side cover on to the computer and fasten the screws to secure it. The pre-built cellular module comes with three SMA connectors for a GPS antenna (W4), a primary...
-
Page 12: Real-Time Clock
Switching Between the Wireless Module Sockets As there are two wireless module sockets and you can install a Wi-Fi module in both these sockets, a DIP switch is provided to enable selection of a Wi-Fi or cellular module. The DIP switch is located below the mSATA socket as shown in the following illustration. -
Page 13: Specific Conditions Of Use
ATTENTION There is a risk of explosion if the battery is replaced with an incorrect type of battery. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacture’s instructions. Hazardous Locations Specifications Model: AIG-502-T-AZU-LX AIG-502-T-US-AZU-LX... - Page 14 BSMI 限用物質含有情況標示聲明書 Declaration of the Presence Condition of the Restricted Substances Marking 型號（型式）: AIG-502-T-AZU-LX 設備名稱: 工業物聯網閘道器 Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 六價鉻 多溴聯苯 多溴二苯醚 單元 Unit 鉛 汞 鎘 Hexavalent Polybrominat Polybrominated Lead Mercury Cadmium chromium...
