USER MANUAL
NORMSTAHL LS60AM
P1555828 2025-03 P1555828-001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Normstahl LS60AM and is the answer not in the manual?

Questions and answers

Summary of Contents for Assa Abloy Normstahl LS60AM

  • Page 1 USER MANUAL NORMSTAHL LS60AM P1555828 2025-03 P1555828-001...
  • Page 2: Copyright And Disclaimer Notice

    Although the contents of this publication have been compiled with the greatest possible care, ASSA ABLOY cannot accept liability for any damage that might arise from errors or omissions in this publication. We also reserve the right to make appropriate technical modifications/replacements without prior notice.
  • Page 3: Table Of Contents

    User Manual Normstahl LS60AM Contents Copyright and Disclaimer Notice........... 2 Introduction.
  • Page 4: Introduction

    User Manual Normstahl LS60AM Introduction The English user manual is the original user manual, all other languages are direct translations of this document General guidelines 1.1.1 Correct operating instructions Before you continue reading, please ensure that you have the correct operating instructions.
  • Page 5: Safety

    User Manual Normstahl LS60AM Safety General Safety Statement The dock leveler is designed to meet all safety requirements in the European Directives and the standards issued by the European Standardization Committee, CEN. The dock leveler is designed and constructed to operate at maximum safety levels.
  • Page 6: Safety Symbols And Marks On The Dock Leveler

    User Manual Normstahl LS60AM · Do not drive a fork-lift truck or other vehicle on the dock leveler if the vehicle is wider than the width of the dock leveler minus 70 cm. · Do not use the dock leveler to move persons.
  • Page 7: Safety Symbols Used In This Manual

    User Manual Normstahl LS60AM Safety symbols used in this manual Note: Additional tips and recommendations for the reader Caution: A caution identifies a condition where equipment can be damaged. Danger: Danger identifies a condition where special precautions must be used to prevent death.
  • Page 8: Misuse

    User Manual Normstahl LS60AM Misuse Any other use of the dock leveler other than described in paragraph "Correct use" is deemed to be misuse. Misuse refers in particular to: · Driving over the dock leveler carrying a load exceeding that stated on the specification plate, ·...
  • Page 9: Description

    User Manual Normstahl LS60AM Description General The Normstahl mini dock leveler meets the standard demands of most loading operations and fully complies with rules and regulations of the European Standard EN 1398. Safety relevant spare parts Platform Gas spring Chain...
  • Page 10: Mode Of Use

    User Manual Normstahl LS60AM Mode of use The dock levelers bridges the gap (height and distance) between the warehouse floor and the truck floor (trailer). It also adjusts to the variations in height of the vehicle bed during loading and unloading.
  • Page 11: Operation

    User Manual Normstahl LS60AM Operation General This section describes the complete operation of the dock leveler. In order to ensure safe operation of this equipment the following safety instructions must be observed. Caution! Make sure that the installation has been carried out by engineers from...
  • Page 12: Operation Of The Dock Leveler

    User Manual Normstahl LS60AM Operation of the dock leveler 4.4.1 Docking the vehicle Attention! Do not operate the leveler in combination with vehicle tail lifts unless the tail lift is explicitly designed for that purpose. Attention! Make sure that no one is between vehicle and loading dock when the truck is moving towards the leveler! Back up the vehicle with open tail-gate or lowered tail-lift.
  • Page 13 User Manual Normstahl LS60AM 4.4.2.2 Docking procedure Caution! The operator must be standing in a safe and secured position while operat- ing. 1) Remove the handle from its holder and plug it in the adaption hole in the plat- form.
  • Page 14: Releasing The Vehicle

    User Manual Normstahl LS60AM 4) Make sure the tail-gate or tail-lift of the vehicle is in the open position. 5) Remove the handle from the operating position and put it in the holder. 6) Loading/unloading can now take place. Releasing the vehicle 4.5.1...
  • Page 15: Releasing Procedure

    User Manual Normstahl LS60AM 4.5.2 Releasing procedure 1) Remove the handle from its holder and plug it in the adaption hole in the plat- form. 2) Raise the platform rapidly from the vehicle bed. The lip will swing in. 3) Lower the leveler before it reaches the upmost position to bring it in the cross traffic position.
  • Page 16: Daily Shut Down Procedure

    User Manual Normstahl LS60AM 5) Remove the handle from the operating position and put it in the holder. 6) The vehicle can leave the loading dock. Daily shut down procedure Move the dock leveler to the cross-traffic position. The dock leveler has now been taken out of commission.
  • Page 17: Maintenance

    User Manual Normstahl LS60AM Maintenance General remarks on maintenance work The dock leveler is designed to keep maintenance to a minimum. Safe operation is only ensured if maintenance work is carried out at regular intervals. Carry out a visual inspection every day.
  • Page 18: Maintenance By Service Engineer

    User Manual Normstahl LS60AM 5.2.1 Maintenance by service engineer Frequency Part Tasks Inspect for wear and tear Every year Safety Inspect the functionality Inspect the functioning of safety device Every 6 years Pneumatic system Replace the gas spring Depending on the cycles per day shorter frequencies may be applicable! Preventive maintenance procedures 5.3.1...
  • Page 19: Inspect The Platform, Lip And Support Frame For Damage

    User Manual Normstahl LS60AM 5.3.3 Inspect the platform, lip and support frame for damage Danger! Install the safety prop before you do maintenance on the dock leveler. Inspect the platform, swing lip and frame/dock edge for the following defects: ·...
  • Page 20: Lubricate The Dock Leveler

    User Manual Normstahl LS60AM 5.3.5 Lubricate the dock leveler Danger! Install the safety prop before you do maintenance on the dock leveler. Use a suitable grease gun and a clean cloth to apply grease to: · The hinges at the rear end of the platform. Use the lubrication holes in the bearings of the plateau hinges.
  • Page 21: Test And Adjustments

    User Manual Normstahl LS60AM Test and Adjustments General Caution! Make sure there are no persons or equipment in the working area of the dock leveler before you operate the dock leveler. Danger! Install the safety prop before you do maintenance on the dock leveler.
  • Page 22: Troubleshooting

    User Manual Normstahl LS60AM Troubleshooting This chapter contains troubleshooting information for users of this door. If a fault is not described in this chapter contact the local service centre for assistance. Introduction This chapter contains troubleshooting information for users of the Normstahl mini dock leveler.
  • Page 23 User Manual Normstahl LS60AM Troubleshooting...
  • Page 24 www.normstahl.com...
