Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have
come loose inside the carton during shipment. Identify and count all items and compare with the parts list and/or hardware list
shown below.
PARTS LIST
NO
DESCRIPTION
1
BENCH SEAT
2
CROSS SUPPORT
3
STRETCHER
4
LEG (L/R)
IMPORTANT NOTE :
ASSEMBLY INSTRUCTIONS
D1903-25
MAISIE BENCH
SKETCH
QTY
1 PC
2 PCS
2 PCS
4 PCS
HARDWARE LIST
NO
DESCRIPTION
A
JCBC BOLT - M6 x 70mm
B
JCBC BOLT - M6 x 40mm
C
SPRING WASHER - M6
D
FLAT WASHER - M6
E
FLAT WASHER - M6
F
ALLEN KEY - M4
G
SCREW - M4 x 38mm
SKETCH
QTY
8 PCS
4 PCS
12 PCS
4 PCS
8 PCS
1 PC
4 PCS
