Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have
come loose inside the carton during shipment. Identify and count all items and compare with the parts list and/or hardware list
shown below.
PARTS LIST
NO
DESCRIPTION
1
TABLE TOP
2
TRIANGLE BLOCK
3
LEG (LEFT)
4
LEG (RIGHT)
5
DECORATION
IMPORTANT NOTE :
ASSEMBLY INSTRUCTIONS
D1902-10T, D1902-10B
GULLIVER DINING TABLE TOP AND BASE
SKETCH
QTY
1 PC
1 PC
2 PCS
2 PCS
2 PCS
HARDWARE LIST
NO
DESCRIPTION
A
HEX NUT
B
SPRING WASHER - M8
C
FLAT WASHER - M8
D
JCBC BOLT - M6 x 80mm
E
SPRING WASHER - M6
F
FLAT WASHER - M6
G
ALLEN KEY - M4
H
SPANNER
I
WOOD DOWEL
SKETCH
QTY
4 PCS
4 PCS
4 PCS
4 PCS
4 PCS
4 PCS
1 PC
1 PC
2 PCS
Advertisement
Related Manuals for New Classic Furniture GULLIVER D1902-10T
Summary of Contents for New Classic Furniture GULLIVER D1902-10T
- Page 1 ASSEMBLY INSTRUCTIONS D1902-10T, D1902-10B GULLIVER DINING TABLE TOP AND BASE Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose inside the carton during shipment. Identify and count all items and compare with the parts list and/or hardware list shown below.
- Page 2 ASSEMBLY INSTRUCTIONS D1902-10T, D1902-10B GULLIVER DINING TABLE TOP AND BASE Step 1. Step 2. Step 3. Step 4. Step 5. * Please take out the extension leaf top wood support (4pcs) from the bottom of table top. This wood support is use for packing purpose only.
- Page 3 ASSEMBLY INSTRUCTIONS D1902-10T, D1902-10B GULLIVER DINING TABLE TOP AND BASE Step 6. To avoid scratching the table top. To extend the extension tops “please first pull down on the bottom of the extension top so it shows a slight opening” Pull down Pull down from here...
