Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have
come loose inside the carton during shipment. Identify and count all items and compare with the parts list and/or hardware list
shown below.
PARTS LIST
NO
DESCRIPTION
1
TABLE TOP
2
LEG
3
LEG SUPPORT
IMPORTANT NOTE :
ASSEMBLY INSTRUCTIONS
D1903-10T, D1903-10B
MAISIE DINING TABLE TOP AND BASE
SKETCH
QTY
1 PC
2 PCS
2 PCS
HARDWARE LIST
NO
DESCRIPTION
A
JCBB BOLT - M8 x 70mm
B
SPRING WASHER - M8
C
FLAT WASHER - M8
D
SPANNER
E
HEX NUT
F
ALLEN KEY - M5
SKETCH
QTY
2 PCS
12 PCS
12 PCS
1 PC
10 PCS
1 PC
Advertisement
Table of Contents
Related Manuals for New Classic Furniture MAISIE D1903-10T
Summary of Contents for New Classic Furniture MAISIE D1903-10T
- Page 1 ASSEMBLY INSTRUCTIONS D1903-10T, D1903-10B MAISIE DINING TABLE TOP AND BASE Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose inside the carton during shipment. Identify and count all items and compare with the parts list and/or hardware list shown below.
