Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts,
which may have come loose inside the carton during shipment. Identify and count all items and compare with
the parts list and/or hardware list shown below.
Please read all instructions carefully. See the hardware and furniture part listing for guidance. Be sure you have
all parts listed before beginning assembly. Place all wooden parts on a clean, flat surface to protect the finish
from scratches. Follow the diagram to assemble.
CAUTION
1. Do not fully tighten the nuts or bolts until the table is fully assembled.
2. Please tighten by hand, not by a drill. Overtightening will damage threads. Do not overtighten.
3. Keep all hardware out of the reach of childen.
PARTS LIST
ITEM
DESCRIPTION
RIGHT SIDE FACING (RSF)
A
HEADBOARD PANEL
LEFT SIDE FACING (LSF)
B
HEADBOARD PANEL
C
LONG SUPPORT RAIL
D
SHORT SUPPORT RAIL
E
BED
HARDWARE DIMENSIONS
VERIFICATION TOOL
STEP 1:
Assemble the Long Support Rail (C) to RSF Headboard Panel (A) and LSF Headboard Panel (B) by
using Allen Key (2) with hardware (1), (3) and (4).
A
ASSEMBLY INSTRUCTIONS
EUROPA COLLECTION
MODEL : B1840-040P EUROPA NIGHTSTAND PANELS,
SKETCH
QTY
1PC
1PC
4PCS
2PCS
1PC
1
inches
B
(2 PCS PER SET)
HARDWARE LIST
ITEM
DESCRIPTION
BOLT M8 x 2"
1
2
ALLEN KEY M5
SPRING WASHER -
3
M8 x 1/2"
FLAT WASHER -
4
M8 x 7/8"
2
SKETCH
3
4
C
QTY
20PCS
1PC
20PCS
20PCS
2
1
3
4
